Ti3Al/Ti/Ti2AlNb扩散连接工艺及性能

魏红梅, 李万青, 何鹏, 高丽娇, 林铁松

魏红梅, 李万青, 何鹏, 高丽娇, 林铁松. Ti3Al/Ti/Ti2AlNb扩散连接工艺及性能[J]. 焊接学报, 2015, 36(4): 5-8,70.
引用本文: 魏红梅, 李万青, 何鹏, 高丽娇, 林铁松. Ti3Al/Ti/Ti2AlNb扩散连接工艺及性能[J]. 焊接学报, 2015, 36(4): 5-8,70.
shu
WEI Hongmei, LI Wanqing, HE Peng, GAO Lijiao, LIN Tiesong. Technology and properties of Ti3Al/Ti/Ti2AlNb diffusion welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(4): 5-8,70.
Citation: WEI Hongmei, LI Wanqing, HE Peng, GAO Lijiao, LIN Tiesong. Technology and properties of Ti3Al/Ti/Ti2AlNb diffusion welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(4): 5-8,70.
shu

Ti3Al/Ti/Ti2AlNb扩散连接工艺及性能

  • 1.

    哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001

  • 2.

    哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001;北京航空材料研究院, 北京 100095

  • 3.

    哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001;北京星航机电装备有限公司, 北京 100074

基金项目: 国家自然科学基金资助项目(51275135,51305102);高等学校博士学科点专项科研基金优先发展领域课题资助项目(20112302130005)

Technology and properties of Ti3Al/Ti/Ti2AlNb diffusion welding

  • 1.

    State Key Laboratory of Advanced Welding and Joining, Harbin institute of Technology, Harbin 150001, China

  • 2.

    State Key Laboratory of Advanced Welding and Joining, Harbin institute of Technology, Harbin 150001, China;Beijing Institute of Aeronautical Materials, Beijing 100095, China

  • 3.

    State Key Laboratory of Advanced Welding and Joining, Harbin institute of Technology, Harbin 150001, China;Beijing Xinghang Mechanical and Electrical Equipment Co., Ltd., Beijing 100074, China

摘要

    摘要
  • 摘要: 采用钛箔作为中间层扩散连接Ti3Al与Ti2AlNb,利用SEM,EDS和XRD等分析方法发现,接头界面组织结构为Ti3Al/α+β双相组织/富B2相/Ti2AlNb.分别研究了中间层厚度,连接温度,保温时间等工艺参数对接头界面组织形貌以及力学性能的影响.结果表明,当钛箔厚度10μm,T=900℃,t=120 min,p=5 MPa时,接头组织性能最佳.钛箔厚度增加会导致Ti,Al,Nb等元素扩散不均匀;Ti3Al/Ti2AlNb直接固相扩散连接温度为1000℃,加入钛中间层可将其降低至900℃,减小了高温热循环对母材性能的损伤,接头整体抗拉强度从795 MPa提升至906 MPa;保温时间90~120 min可保证扩散充分连接可靠.
    Abstract: Ti3Al and Ti2AlNb alloy were connected by diffusion bonding with Ti foil as interlayer. Through a number of analysis methods such as SEM, EDS and XRD, it was discovered that the typical interface structure of Ti3Al/Ti/Ti2AlNb joint was Ti3Al/α-phase +β-phase/B2-rich phase/Ti2AlNb. The effect of process parameters, including thickness of interface layer, bonding temperature and holding time, on the interface morphology and property of the joint was investigated. The results show that when the thickness of Ti foil was 10μm, bonding temperature was 900℃ and holding time was 120 min, the resultant Ti3Al/Ti/Ti2AlNb joint had the optimized microstructure and properties. Increasing the foil thickness caused uneven diffusion of Ti, Al and Nb. The direct bonding temperature of Ti3Al/Ti2AlNb was 1000℃, the addition of Ti foil interlayer could reduce the bonding temperature to 900℃. So the damage of high temperature thermal cycling to Ti3Al alloy was decreased. The tensile strength of the joint increased from 795 MPa to 906 MPa. The holding time from 90 min to 120 min could ensure sufficient diffusion and reliable connection.
    • HTML全文
    • 参考文献(12)
  • [1] 刘会杰,冯吉才. TiAl基合金连接技术的研究进展[J].焊接, 2001(4):6-10. Liu Huijie, Feng Jicai. Research progress in bonding technology of TiAl-based alloys[J]. Welding & Joining, 2001(4):6-10.
    [2] 司玉锋,陈子勇,孟丽华,等. Ti3Al基金属间化合物的研究进展[J].特种铸造及有色合金, 2003, 23(4):33-35. Si Yufeng, Chen Ziyong, Meng Lihua, et al. Research progress in Ti3Al base intermetallic compound[J]. Special Casting and Nonferrous Alloys, 2003, 23(4):33-35.
    [3] 吴爱萍,邹贵生,任家烈. Ti3Al合金的发展现状及其连接技术[J].航空制造技术, 2007(6):30-35. Wu Aiping, Zou Guisheng, Ren Jialie. Development and connecting technology of Ti3Al alloys[J]. Aeronautical Manufacturing Technology, 2007(6):30-35.
    [4] Banerjee D, Gogia A K, Nandi T K, et al. A new ordered orthorhombic phase in a Ti3AlNb alloy[J]. Acta Metallurgica, 1988, 36(4):871-882.
    [5] 张建伟,李世琼,梁晓波,等. Ti3Al和Ti2AlNb基合金的研究与应用[J].中国有色金属学报, 2010, 20(s1):336-341. Zhang Jianwei, Li Shiqiong, Liang Xiaobo, et al. Research and application of Ti3Al and Ti2AlNb based alloy[J]. The Chinese Journal of Nonferrous Metals, 2010, 20(s1):336-341.
    [6] Janarthany S D, Viala J C, Bouix J. An overview of monolithic titanium aluminide based on Ti3Al and TiAl[J]. Materials Chemistry and Physics, 2001, 72(3):301-319.
    [7] Gogia A K, Nandy T K, Banerjee D, et al. Microstructure and mechanical properties of orthorhombic alloys in the Ti-Al-Nb system[J]. Intermetallics, 1998, 6(7/8):741-748.
    [8] Chu F, Mitchell T E, Majumdar B, et al. Elastic properties of the O phase in Ti-Al-Nb alloys[J]. Intermetallics, 1997, 5(2):147-156.
    [9] Mao Y, Li S Q, Zhang J W, et al. Microstructure and tensile properties of orthorhombic Ti-Al-Nb-Ta alloys[J]. Intermetallics, 2000, 8(5):659-662.[10] Rowe R G. Ti2AlNb based alloys outperform conventional titanium aluminides[J]. Advanced Materials and Processes, 1992(3):33-35.
    [10] Li S Q, Cheng Y J, Liang X B, et al. Recent work on alloy and process development of Ti2AlNb based alloys[J]. Materials Science Forum, 2005, 475/479:559-562.
    [11] 钱锦文,侯金保,李京龙,等. Ti2AlNb/GH4169真空扩散连接初步研究[J].热加工工艺, 2008, 37(13):90-93. Qian Jinwen, Hou Jinbao, Li Jinglong, et al. Study on vacuum diffusion bonding of Ti2AlNb/GH4169[J]. Hot Working Technology, 2008, 37(13):90-93.
    [12] 邹贵生,白海林,谢二虎,等. O相合金Ti-22Al-25Nb固态扩散连接[J].中国有色金属学报, 2008, 18(4):577-582. Zou Guisheng, Bai Hailin, Xie Erhu, et al. Solid diffusion bonding of Ti-22Al-25Nb O phase alloy[J]. The Chinese Journal of Nonferrous Metals, 2008, 18(4):577-582
