复杂结构薄壁件电弧增材制造离线编程技术

王天琪, 李天旭, 李亮玉, 杨壮

王天琪, 李天旭, 李亮玉, 杨壮. 复杂结构薄壁件电弧增材制造离线编程技术[J]. 焊接学报, 2019, 40(5): 42-47. DOI: 10.12073/j.hjxb.2019400125
引用本文: 王天琪, 李天旭, 李亮玉, 杨壮. 复杂结构薄壁件电弧增材制造离线编程技术[J]. 焊接学报, 2019, 40(5): 42-47. DOI: 10.12073/j.hjxb.2019400125
shu
WANG Tianqi, LI Tianxu, LI Liangyu, YANG Zhuang. Off-line programming technology for arc additive manufacturing of thin-walled components with complex structures[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 42-47. DOI: 10.12073/j.hjxb.2019400125
Citation: WANG Tianqi, LI Tianxu, LI Liangyu, YANG Zhuang. Off-line programming technology for arc additive manufacturing of thin-walled components with complex structures[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(5): 42-47. DOI: 10.12073/j.hjxb.2019400125
shu

复杂结构薄壁件电弧增材制造离线编程技术

  • 天津工业大学 天津市现代机电装备技术重点实验室, 天 津 300387

基金项目: 国家自然科学基金资助项目（U1733125）；天津市自然科学基金资助项目（17JCZDJC38700）；天津市自然科学基金面上资助项目（18JCYBJC18700）

Off-line programming technology for arc additive manufacturing of thin-walled components with complex structures

  • Advanced Mechatronics Equipment Technology Tianjin Area Laboratory, Tianjin Polytechnic University, Tianjin 300387, China

摘要

    摘要
  • 摘要: 将增材制造技术和弧焊机器人技术相结合，对复杂薄壁件进行电弧增材制造技术研究. 首先在传统的分层方法的基础上，对成形过程中高度变化的几何模型进行预测并分析，再通过机器人的离线编程与轨迹规划技术，实现成形轨迹的自动提取. 进一步利用圆弧离散局部逼近算法，对复杂薄壁件的切片截面进行微分，计算出四元数矩阵，实现焊枪位姿自动调整；并对焊接工艺进行改良，保证成形质量. 最后通过焊制部分薄壁件进行试验验证. 结果表明，薄壁件成形质量良好，预测尺寸与实际成形尺寸误差不超过1 mm.
    Abstract: The welding technology of complex thin-walled parts was studied using the combination of the technology of additive manufacturing and arc welding robot. Firstly, on the basis of the traditional stratification method the geometric model of high variation in the forming process is predicted and analyzed. And then through the robot's off-line programming and trajectory planning technology, the automatic extraction of the forming trajectory is realized. The circular discrete local approximation algorithm is used to differentiate the serial sections of complex thin-walled parts, and the quaternion matrix is calculated to achieve the automatic adjustment of welding torch position and pose. And the welding process is improved to ensure the forming quality. Finally, some thin walled parts were welded for experimental verification. The results show that the forming of thin-walled parts is of good quality, and the error between the predicted size and the actual forming size is not more than 1 mm.
    • HTML全文
    • 参考文献(10)
  • [1] Spencer J D, Dickens P M, Wykes C M. Rapid prototyping of metal parts by three-dimensional welding[J]. Journal of Engineering Manufacture, 1998, 212(3):175-182.
    [2] 杨建华,张定华,吴宝海.考虑加工过程的复杂薄壁件加工综合误差补偿方法[J].航空学报, 2014, 35(11):3174-3181 Yang Jianhua, Zhang Dinghua, Wu Baohai. A comprehensive error compensation approach considering machining process for complex thin-wall parts machining[J]. Acta Aeronautica et Astronauica Sinica, 2014, 35(11):3174-3181
    [3] Feng J, Zhang H, He P. The CMT short-circuiting metal transfer process and its use in thin aluminium sheets welding[J]. Materials&Design, 2009, 30(5):1850-1852.
    [4] 柏久阳,王计辉,林三宝,等.铝合金电弧增材制造焊道宽度尺寸预测[J].焊接学报, 2015, 36(9):87-90 Bai Jiuyang, Wang Jihui, Lin Sanbao, et al. Width prediction of aluminium alloy weld additively manufactured by TIG arc[J]. Transactions of the China Welding Institution, 2015, 36(9):87-90
    [5] 李玉龙,张华,张光云,等.基于TIG堆焊技术的低碳钢零件精密增材制造[J].焊接学报, 2009, 30(9):37-40 Li Yulong, Zhang Hua, Zhang Guangyun, et al. Precision rapid prototyping of steel parts using TIG depositision technology[J]. Transactions of the China Welding Institution, 2009, 30(9):37-40
    [6] Kazanas P, Deherkar P, Almeida P, et al. Fabrication of geometrical features using wire and arc additive manufacture[J]. Journal of Engineering Manufacture, 2012, 226(6):1042-1051.
    [7] Panchagnula J S, Simhambhatla S. Manufacture of complex thin-walled metallic objects using weld-deposition based additive manufacturing[J]. Robotics and Computer-Integrated Manufacturing, 2018, 49:194-203.
    [8] 刘一搏,孙清洁,姜云禄,等.基于冷金属过渡技术增材制造工艺[J].焊接学报, 2014, 35(7):1-4 Liu Yibo, Sun Qingjie, Jiang Yunlu, et al. Rapid prototyping process based on cold metal transfer arc welding technology[J]. Transactions of the China Welding Institution, 2014, 35(7):1-4
    [9] 宋月娥,吴林,田劲松,等.用于机器人离线编程的作业标定算法[J].焊接学报, 2002, 23(3):32-36 Song Yuee, Wu Lin, Tian Jinsong, et al. Operation object calibration algorithm used for robotic offline programming[J]. Transactions of the China Welding Institution, 2002, 23(3):32-36
    [10] Zhang Y M, Chen Y, Li P, et al. Weld deposition-based rapid prototyping:a preliminary study[J]. Journal of Materials Processing Technology, 2003, 135(2-3):347-357.
