根部螺纹搅拌针对搭接接头钩状缺陷和性能的影响

吴双连, 毛镇东, 刘雪松

吴双连, 毛镇东, 刘雪松. 根部螺纹搅拌针对搭接接头钩状缺陷和性能的影响[J]. 焊接学报, 2019, 40(3): 37-40. DOI: 10.12073/j.hjxb.2019400068
引用本文: 吴双连, 毛镇东, 刘雪松. 根部螺纹搅拌针对搭接接头钩状缺陷和性能的影响[J]. 焊接学报, 2019, 40(3): 37-40. DOI: 10.12073/j.hjxb.2019400068
shu
WU Shuanglian, MAO Zhendong, LIU Xuesong. Influence of bottom-threaded pin on hook morphology and mechanical properties of lap welded joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(3): 37-40. DOI: 10.12073/j.hjxb.2019400068
Citation: WU Shuanglian, MAO Zhendong, LIU Xuesong. Influence of bottom-threaded pin on hook morphology and mechanical properties of lap welded joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(3): 37-40. DOI: 10.12073/j.hjxb.2019400068
shu

根部螺纹搅拌针对搭接接头钩状缺陷和性能的影响

  • 1. 中车青岛四方机车车辆股份有限公司，青岛　266111;

  • 2. 哈尔滨工业大学 先进焊接与连接国家重点实验室，哈尔滨　150001

基金项目:

国家自然科学基金资助项目（51075102）

详细信息
    作者简介:

    吴双连，男，1984年出生，硕士．主要从事高速列车车体设计、焊接制造技术及工艺研究．Email: wulianshuang2018@126.com

    通讯作者:

    刘雪松，男，教授. Email: liuxuesong@hit.edu.cn

  • 中图分类号: TG 453

Influence of bottom-threaded pin on hook morphology and mechanical properties of lap welded joint

  • 1. CSR Qingdao Sifang Co., Ltd., Qingdao 266111, China;

  • 2. State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要

    摘要
  • 摘要: 选用3 mm厚的7075–T6铝合金为研究对象，研究了根部带有螺纹的搅拌针对搅拌摩擦焊搭接接头钩状缺陷及拉剪载荷的影响. 结果表明，搅拌针上的螺纹可明显改变焊接过程中的材料流动；塑性材料在搭接面上部集中，挤压搭接界面，焊后搭接接头的钩状缺陷向下弯曲；搭接面处焊核区的宽度较搅拌针的直径明显增大. 因搅拌针端部无螺纹，焊接速度较大时接头底部会由于材料无法及时填充而产生孔洞缺陷. 随着搅拌头焊接速度的升高，搭接接头的拉剪载荷先上升后下降，最高载荷在焊接速度为40 mm/min时取得，为23.333 kN.
    Abstract: Using 3 mm thick 7075-T6 aluminum alloys as the research objects, this work studied the effect of a bottom-threaded pin on hook morphology and mechanical properties of friction stir lap welded joint. The results showed that the thread on the pin could significantly affect the material flow behavior during welding. The plastic material accumulated at the lap interface, squeezing the lap interface, So the hook bended downwards after welding. The width of the stir zone was obviously wider than the diameter of the pin. Because there was on thread on the tip of the pin, void easily appears at the bottom of the stir zone due to incomplete refilling of the plastic material. With increasing the welding speed, the lap shear failure load first increased and then decreased. The maximum failure load of 23.333 kN was obtained at a welding speed of 40 mm/min.
    • HTML全文
    • 参考文献(13)
  • [1]

    Yue Yumei, Zhou Zhenlu, Ji Shude, et al. Effect of half-threaded pin on mechanical properties of friction stir lap welded alclad 2024 aluminum alloy[J]. Transactions of the China Welding Institution, 2016, 37(10): 69 − 72
    [2] 岳玉梅, 周振鲁, 姬书得, 等. 半螺纹搅拌针对2024铝合金搅拌摩擦搭接焊力学性能的影响[J]. 焊接学报, 2016, 37(10): 69 − 72
    [3]

    Liu Jian, Liu Xuesong, Xing Yanshuang. Influence of pin length on formation and shear failure load of dissimilar Al alloys FSLW joint[J]. Transactions of the China Welding Institution, 2018, 39(6): 91 − 95
    [4]

    Li Z, Yue Y, Ma L, et al. Effects of pin geometry on the material flow behavior of friction stir spot welded 2A12 aluminum alloy[J]. China Welding, 2015, 24(2): 25 − 29.
    [5]

    Wang Chungui, Zhao Yunqiang, Dong Chunlin, et al. Analysis on microstructure and mechanical properties of 6063-T6 self-reacting friction stir welding[J]. Transactions of the China Welding Institution, 2018, 39(10): 108 − 112
    [6]

    Cantin G, David S, Thomas W, et al. Friction Skew-stir welding of lap joints in 5083-O aluminum[J]. Science and Technology of Welding and Joining, 2005, 10(3): 268 − 280.
    [7]

    Salari E, Jahazi M, Khodabandeh A, et al. Influence of tool geometry and rotational speed on mechanical properties and defect formation in friction stir lap welded 5456 aluminum alloy sheets[J]. Materials & Design, 2014, 58: 381 − 389.
    [8]

    Yue Y, Li Z, Ji S, et al. Effect of reverse-threaded pin on mechanical properties of friction stir lap welded alclad 2024 aluminum alloy[J]. Journal of Materials Science and Technology, 2016, 32(7): 671 − 675.
    [9] 刘 建, 刘雪松, 邢艳双. 针长对异种铝合金FSLW 接头成形及力学性能影[J]. 焊接学报, 2018, 39(6): 91 − 95
    [10] 王春桂, 赵运强, 董春林, 等. 6063-T6铝合金双轴肩搅拌摩擦焊接头组织及力学性能分析[J]. 焊接学报, 2018, 39(10): 108 − 112
    [11]

    Yin Y H, Sun N, North T H, et al. Hook formation and mechanical properties in AZ31 friction stir spot welds[J]. Journal of Materials Processing Technology, 2010, 210: 2062 − 2070.
    [12]

    Yin Y H, Sun N, North T H, et al. Microstructures and mechanical properties in dissimilar AZ91/AZ31 spot welds[J]. Materials Characterization, 2010, 61: 1018 − 1028.
    [13]

    Li Z, Yue Y, Ji S, et al. Optimal design of thread geometry and its performance in friction stir spot welding[J]. Materials & Design, 2016, 94(15): 368 − 376.
