焊后热处理对CLAM钢焊接接头耐液态铅铋合金空泡腐蚀性能的影响
Effect of PWHT on cavitation erosion resistance of CLAM weld joint in liquid Lead-bismuth eutectic alloy
-
摘要: 加速器驱动次临界系统的冷却剂液态铅铋共晶合金在循环管道中高速流动时会对主泵叶轮及第一壁包层材料造成空泡腐蚀.焊接接头是整个循环管道中的薄弱环节，但合理的焊后热处理是提高循环管道中焊缝区域性能最有效的方法.自主设计一套装置用于金属溶液空泡腐蚀试验.对各组试样不同时间空泡腐蚀后的表面形貌、粗糙度、空蚀坑平均深度进行分析，再结合焊后热处理后的焊缝微观组织及力学性能，对空泡腐蚀行为及耐空蚀性能提高机制进行分析.结果表明，调质后焊缝耐空蚀性能最好；760℃回火后耐空蚀性能也比较好；710℃与810℃回火后耐空蚀性能稍差；未焊后热处理焊缝耐空蚀性能最差.Abstract: The coolant liquid lead-bismuth eutectic alloy (LBE) of the accelerator driven subcritical reactor system (ADS) would lead to serious cavitation erosion on the main pump impeller and the first wall cladding material when the liquid LBE flows at a high speed. Welding joint is the weak area in the whole circulation pipeline, and the reasonable heat treatment is the most effective method to improve the performance of the weld area. A suit of ultrasonic cavitation facility was self-designed to the cavitation erosion test. By analyzing the surface topography, roughness and mean pit depth of specimens after being eroded for different time, and combining these erosion results with the microstructure and mechanical properties of weld bead after PWHT, the cavitation behavior of weld bead of CLAM steel after PWHT and the influence of PWHT to the cavitation behavior of weld bead were studied. The results show that the weld bead being quenched and tempered showed the best cavitation erosion resistance. The cavitation erosion resistance of weld bead after being tempered at 760℃ were better than that of weld bead after being tempered at 710℃ or 810℃. The weld bead without PWHT exhibited the poorest cavitation erosion resistance.
-
-
[1] 吴宜灿, 黄群英, 柏云清, 等. 液态铅铋回路设计研制与材料腐蚀实验初步研究[J]. 核科学与工程, 2010,30(3):238-243. Wu Yican, Huang Qunying, Bai Yunqing, et al. Preliminary experimental study on the corrosion of structural steels in liquid lead bismuth loop[J].Chinese Journal of Nuclear Science and Enginee ring, 2010,30(3):238-243. [2] Chen X, Shen Z, Li P, et al. Compatibility of CLAM steel weldments with static LiPb alloy at 500℃[J]. Fusion Engineering and Design, 2012, 87(9):1565-1569.[DOI: 10.1016/j.fusengdes.2012.04.012] [3] Huang Q. Development status of CLAM steel for fusion application, Journal of Nuclear Materials, 2014(455):649-654. [4] Zhu Q, Lei Y, Chen X, et al. Microstructure and mechanical properties in TIG welding of CLAM steel[J], Fusion Engineering And Design,2011(86):407-411. [5] 张小彬. CrNiMo不锈钢表面激光熔覆与合金化抗空蚀涂层研究[D]. 沈阳:东北大学, 2007. [6] 骆素珍, 敬和民, 郑玉贵, 等. CrMnN双相不锈钢的空泡腐蚀行为研究[J].中国腐蚀与防护学报, 2003, 23(5):276-281. Luo Suzhen, Jing Hemin, Zheng Yugui, et al. Cavitation-corrosion behavior of CrMnN duplex stainless steel[J]. Journal of Chinese Society For Corrosion and Protection, 2003, 23(5):276-281.[DOI: 10.3969/j.issn.1005-4537.2003.05.005] [7] 雷玉成, 顾康家, 朱强, 等. 中国低活马氏体钢熔化焊接头硬度与微观组织[J].焊接学报, 2009,30(11):9-12. Lei Yucheng, Gu Kangjia, Zhu Qiang, et al. Hardness and microstructure of China low activation martensitic steel fusion welded joint[J]. Transactions of the China Welding Institution, 2009,30(11):9-12.[DOI: 10.3321/j.issn:0253-360X.2009.11.003] -
