底充胶叠层PBGA无铅焊点随机振动应力应变分析

黄春跃, 梁颖, 邵良滨, 黄伟, 李天明

黄春跃, 梁颖, 邵良滨, 黄伟, 李天明. 底充胶叠层PBGA无铅焊点随机振动应力应变分析[J]. 焊接学报, 2015, 36(10): 33-36.
引用本文: 黄春跃, 梁颖, 邵良滨, 黄伟, 李天明. 底充胶叠层PBGA无铅焊点随机振动应力应变分析[J]. 焊接学报, 2015, 36(10): 33-36.
HUANG Chunyue, LIANG Ying, SHAO Lingbin, HUANG Wei, LI Tianming. Stress and strain distribution of PBGA stacked lead-free solder joints with underfill with random vibration[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(10): 33-36.
Citation: HUANG Chunyue, LIANG Ying, SHAO Lingbin, HUANG Wei, LI Tianming. Stress and strain distribution of PBGA stacked lead-free solder joints with underfill with random vibration[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(10): 33-36.

底充胶叠层PBGA无铅焊点随机振动应力应变分析

基金项目: 国家自然科学基金资助项目(51465012);广西壮族自治区自然科学基金资助项目(2013GXNSFAA019322,2015GXNSFCA139006)

Stress and strain distribution of PBGA stacked lead-free solder joints with underfill with random vibration

  • 摘要: 建立了底充胶叠层塑料球栅阵列(plastic ball grid array, PBGA)无铅焊点三维有限元分析模型,研究了PBGA结构方式、焊点材料、底充胶弹性模量和密度对叠层无铅焊点随机振动应力应变的影响. 结果表明,底充胶可有效降低焊点内的随机振动应力应变;在其它条件相同下,对于Sn95.5Ag3.8Cu0.7,Sn96.5Ag3Cu0.5,Sn-3.5Ag和Sn63Pb37这四种焊料,采用Sn-3.5Ag的底充胶叠层焊点内的随机振动最大应力应变最小,采用Sn96.5Ag3Cu0.5的焊点内的最大应力应变最大;随着底充胶弹性模量的增大,叠层无铅内的随机振动应力应变值相应减小;随着底充胶密度的增大,叠层无铅内的随机振动应力应变值相应增大.
    Abstract: The 3D finite element analysis model of plastic ball grid array(PBGA) stacked lead-free solder joints with underfills was developed. By using ANSYS the finite element analysis was performed based on the model with random vibration. The influences of PBGA assembly structure, solder joint material, underfill elastic modulus and underfill density on PBGA stacked lead-free solder joint stress and strain under random vibration load were respectively studied. The results show that comparing to the no-underfill stacked solder joints the stress and strain in the stacked solder joint can be effectively reduced under random vibration load. When other conditions being equal, for Sn95.5Ag3.8Cu0.7, Sn96.5Ag3Cu0.5, Sn-3.5Ag and Sn63Pb37, the lead free Sn-3.5Ag stack solder joint has the minimum stress and strain while the lead-free SAC305 stack solder joint has the maximum stress and strain in the solder ball. The stress and strain in the lead-free stacked solder was reduced with the increase of underfill elasticity modulus. With the increase of the underfill density, the stress and strain in the stacked lead-free solder joint increased correspondingly.
  • [1] 叶 焕, 薛松柏, 张 亮,等. CSP器件无铅焊点可靠性的有限元分析[J]. 焊接学报, 2009, 30(11): 93-96. Ye Huan, Xue Songbai, Zhang Liang, et al. Finite element analysis on reliability of lead-free soldered joints for CSP device[J]. Transactions of the China Welding Institution, 2009, 30(11): 93-96.
    [2] 张 亮, 薛松柏, 韩宗杰, 等. FCBGA器件SnAgCu焊点疲劳寿命预测[J]. 焊接学报, 2008, 29(7): 85-88. Zhang Liang, Xue Songbai, Han Zongjie, et al. Fatigue life prediction of SnAgCu soldered joints of FCBGA device[J]. Transactions of the China Welding Institution, 2008, 29(7): 85-88.
    [3] Kathy Wei Yan, R Wayne Johnson. Double bump flip-chip assembly[J]. IEEE Transactions on Electronics Packaging Manufacturing, 2006, 29(2): 119-133.
    [4] 韦何耕, 黄春跃, 梁 颖, 等. 热循环加载条件下PBGA叠层无铅焊点可靠性分析[J]. 焊接学报, 2013, 34(10): 91-94. Wei Hegeng, Huang Chunyue, Liang Ying, et al. Reliability analysis of plastic ball grid array double-bump lead-free solder joint under thermal cycle[J]. Transactions of the China Welding Institution, 2013, 34(10): 91-94.
    [5] Ong J M G, Tay A A O, Zhang X, et al. Optimization of the thermomechanical reliability of a 65 nm Cu/low-k large-die flip chip package[J]. IEEE Transactions on Components and Packaging Technologies, 2009, 32(4): 838-848.
    [6] 郭 强, 赵 玫, 孟 光. 随机振动条件下SMT焊点半经验疲劳寿命累积模型[J]. 振动与冲击, 2005, 24(2): 24-26. Guo Qiang, Zhao Mei, Meng Guang. Random fatigue semi-empirical model of SMT solder joint[J]. Journal of Vibration and Shock, 2005, 24(2): 24-26.
    [7] Edward S Ibea, Karl I Loha, Jing-en Luan, et al. Effect of unfilled underfills on drop impact reliability performance of area array packages[A]. Proceedings of IEEE 56th Electronic Components and Technology Conference[C]// Piscataway: Institute of Electrical and Electronics Engineers Inc., 2006. 462-466.
    [8] Alfredo Genovese, Fulvio Fontana, Mario Cesana, et al. Solder extrusions and underfill delaminations: a remarkable flip chip qualification experience[J]. The International Journal of Microcircuits and Electronic Packaging, 2001, 24(1): 53-60.
计量
  • 文章访问数:  346
  • HTML全文浏览量:  6
  • PDF下载量:  215
  • 被引次数: 0
出版历程
  • 收稿日期:  2014-01-11
