金属激光直接成形最佳搭接率计算及试验验证

来佑彬, 张本华, 赵吉宾, 刘伟军, 赵宇辉

来佑彬, 张本华, 赵吉宾, 刘伟军, 赵宇辉. 金属激光直接成形最佳搭接率计算及试验验证[J]. 焊接学报, 2016, 37(12): 79-82.
引用本文: 来佑彬, 张本华, 赵吉宾, 刘伟军, 赵宇辉. 金属激光直接成形最佳搭接率计算及试验验证[J]. 焊接学报, 2016, 37(12): 79-82.
LAI Youbin, ZHANG Benhua, ZHAO Jibin, LIU Weijun, ZHAO Yuhui. Calculation and experimental verification of optimal overlapping ratio in laser metal direct manufacturing[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 79-82.
Citation: LAI Youbin, ZHANG Benhua, ZHAO Jibin, LIU Weijun, ZHAO Yuhui. Calculation and experimental verification of optimal overlapping ratio in laser metal direct manufacturing[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 79-82.

金属激光直接成形最佳搭接率计算及试验验证

基金项目: 中科院重点部署项目资助课题(KGZD-EW-T04-2);辽宁省教育厅科学技术研究重点课题(LSNZD201603)

Calculation and experimental verification of optimal overlapping ratio in laser metal direct manufacturing

  • 摘要: 为了提高金属激光直接成形零件的表面平整度,建立了搭接率数学模型,对最佳搭接率进行了理论求解、结果表明,最佳搭接率不受成形件特征尺寸的影响,即无论其它工艺参数如何设定,采用33.3%的搭接率均能得到理想的表面平整度.为了对理论模型进行验证,利用单因素的试验方法进行了12组不同搭接率试验,在显微镜下测量得到不同搭接率对于成形件表面平整度的影响.试验结果充分说明了理论模型的正确性,并发现搭接率在30%~45%时,成形件表面平整度均较为理想,因此在实际的金属激光直接成形过程中,可以根据具体的加工情况在该范围内灵活设定搭接率.
    Abstract: To improve the surface roughness of parts in laser metal direct manufacturing (LMDM), the mathematical model was established to calculate the optimal overlapping ratio. The result shows that the dimensions of parts have no influence on the optimal overlapping ratio, namely, the desired surface roughness always can be obtained with the overlapping ratio of 33.3%. In order to verify the theoretical model, 12 samples were prepared at different overlapping ratio, and their surface roughness was measured under the microscope. The measurement results fully demonstrate the validity of the theoretical model and show that the surface roughness is relatively good at the overlapping ratio in 30~45%. Therefore, in the actual LMDM process, the overlapping ratio can be set flexibly within the range according to the specific processing conditions.
  • [1] 杨小虎, 张安峰, 李涤尘, 等. 激光金属直接成形工艺参数对形貌自愈合能力的影响[J]. 中国激光, 2011, 38(6):212-218. Yang Xiaohu, Zhang Anfeng, Li Dichen, et al. Influence of process parameters on self-healing ability in laser metal direct forming[J]. Chinese Journal of Lasers, 2011, 38(6):212-218.
    [2] 葛江波, 张安峰, 李涤尘, 等. 激光金属直接成形DZ125L高温合金零件工艺的研究[J]. 中国激光, 2011, 38(7):119-125. Ge Jiangbo, Zhang Anfeng, Li Dichen, et al. Process research on DZ125L superalloy parts by laser metal direct forming[J]. Chinese Journal of Lasers, 2011, 38(7):119-125.
    [3] 侯慧鹏, 田象军, 刘栋, 等. 氩弧焊修复激光成形TC11钛合金组织及高周疲劳性能[J]. 焊接学报, 2016, 37(8):9-12. Hou Huipeng, Tian Xiangjun, Liu Dong, et al. Microstructure and high-cycle fatigue properties of laser melting deposited TC11 titanium alloy repaired by tungsten argon arc welding[J]. Transactions of the China Welding Institution, 2016, 37(8):9-12.
    [4] 朱刚贤, 张安峰, 李涤尘, 等. 激光金属制造薄壁零件z轴单层行程模型[J]. 焊接学报, 2010, 31(8):57-60. Zhu Gangxian, Zhang Anfeng, Li Dichen, et al. Model of layer thickness of thin-walled parts in laser metal direct manufacturing[J]. Transactions of the China Welding Institution, 2010, 31(8):57-60.
    [5] Li Yanxiang, Ma Jian. Study on overlapping in the laser cladding process[J]. Surface and Coating Technology, 1996, 90(1):1-5.
    [6] 张霜银, 林鑫, 陈静, 等. 工艺参数对激光快速成形TC4钛合金组织及成形质量的影响[J]. 稀有金属材料与工程, 2007, 36(10):1839-1843. Zhang Shuangyin, Lin Xin, Chen Jing, et al. Influence of processing parameter on the microstructure and forming characterizations of Ti-6Al-4V titanium alloy after laser rapid forming processing[J]. Rare Metal Materials and Engineering, 2007, 36(10):1839-1843.
    [7] 咸士玉, 杨爱萍, 颜羽, 等. 扫描路径和搭接率对激光平面熔覆基板变形的影响[J]. 航天制造技术, 2011(2):26-32. Xian Shiyu, Yang Aiping, Yan Yu, et al. Effect of scanning path and overlap rate on substrate deformation during Laser cladding[J]. Aerospace Manufacturing Technology, 2011(2):26-32.
    [8] 温鹏, 冯振华, 王罡, 等. 激光热丝焊表面修复成形质量分析和控制[J]. 焊接学报, 2015, 36(5):21-24. Wen Peng, Feng Zhenhua, Wang Gang, et al. Formation quality analysis and parameters optimization of laser hot wire repair welding[J]. Transactions of the China Welding Institution, 2015, 36(5):21-24.
    [9] Aiyiti W, Zhao Wanhua, Lu Bingheng, et al. Investigation of the overlapping parameters of MPAW-based rapid prototyping[J]. Rapid Prototyping Journal, 2006, 12(3):165-172.
    [10] 来佑彬, 刘伟军, 赵宇辉, 等. TA15粉末激光成形基板应力影响因素的试验研究[J]. 稀有金属材料与工程, 2014, 43(7):1605-1609. Lai Youbin, Liu Weijun, Zhao Yuhui, et al. Experimental research on influencing factors of the residual stress of substrate in Ti-6.5Al-1Mo-1V-2Zr powder laser shaping[J]. Rare Metal Materials and Engineering, 2014, 43(7):1605-1609.
