超声辅助水下湿法焊接工艺

吴来军, 刘一搏, 程文倩, 孙清洁, 王建峰

吴来军, 刘一搏, 程文倩, 孙清洁, 王建峰. 超声辅助水下湿法焊接工艺[J]. 焊接学报, 2016, 37(12): 33-36.
引用本文: 吴来军, 刘一搏, 程文倩, 孙清洁, 王建峰. 超声辅助水下湿法焊接工艺[J]. 焊接学报, 2016, 37(12): 33-36.
shu
WU Laijun, LIU Yibo, CHENG Wenqian, SUN Qingjie, WANG Jianfeng. Ultrasound-assisted underwater wet welding process[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 33-36.
Citation: WU Laijun, LIU Yibo, CHENG Wenqian, SUN Qingjie, WANG Jianfeng. Ultrasound-assisted underwater wet welding process[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 33-36.
shu

超声辅助水下湿法焊接工艺

  • 1.

    哈尔滨工业大学 先进焊接与连接国家重点实验室, 哈尔滨 150001;哈尔滨工业大学(威海) 山东省特种焊接技术重点实验室, 威海 264209

  • 2.

    哈尔滨工业大学(威海) 山东省特种焊接技术重点实验室, 威海 264209

基金项目: 国家自然科学基金资助项目（51475104，51435004）；国家“973”重点基础研究发展规划资助项目（2013CB035500）

Ultrasound-assisted underwater wet welding process

  • 1.

    State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China;Shandong Provincial Key Laboratory of Special Welding Technology, Harbin Institute of Technology at Welhai, Weihai 264209, China

  • 2.

    Shandong Provincial Key Laboratory of Special Welding Technology, Harbin Institute of Technology at Welhai, Weihai 264209, China

摘要

    摘要
  • 摘要: 水下湿法焊接过程电弧不稳定，常存在熄弧、焊缝成形不均匀等问题.针对这一问题，提出了超声辅助水下湿法焊接方法，其原理是将功率超声振动与常规水下湿法焊接相结合，通过超声振动作用改善焊接电弧稳定性、焊缝成形，进而提高水下焊接接头质量.超声辅助水下湿法焊接堆焊对比试验结果表明，超声辅助水下湿法焊接显著改善了焊缝成形，能够获得尺寸均一连续的焊缝；焊接过程稳定性提高，熄弧率明显减小，熔深增大，余高减小，焊缝中心区域的显微硬度减小.
    Abstract: Underwater wet welding usually accompanied poor arc stability, arc blowout, nonuniform weld appearance and other problems. Ultrasound-assisted underwater wet welding method was developed to solve these problems. Its principle is to use the ultrasound combined with common underwater wet welding to improve welding arc stability, weld appearance and the weld quality. Bead-on-plate welding experiments were carried out with the ultrasound-assisted underwater wet welding equipment. The results showed that ultrasonic can improve the weld appearance and stability of welding process. The arc blowout rate is obviously decreased, the weld penetration is increased, and the reinforcement is decreased. The micro-hardness of the central weld is also decreased.
    • HTML全文
    • 参考文献(10)
  • [1] 张洪涛, 钟诗胜, 冯吉才. 水下焊接技术现状及发展[J]. 焊接, 2011(10):18-22. Zhang Hongtao, Zhong Shisheng, Feng Jicai. Development and status of underwater welding technology[J]. Welding & Joining, 2011(10):18-22.
    [2] 叶建雄, 尹懿, 张晨曙. 湿法水下焊接及水下焊接机器人技术进展[J]. 焊接技术, 2009, 38(6):1-5. Ye Jianxiong, Yin Yi, Zhang Chenshu. Development of underwater wet welding and underwater welding robot[J]. Welding Technology, 2009, 38(6):1-5.
    [3] 周利, 刘一搏, 郭宁, 等. 水下焊接技术的研究发展现状[J]. 电焊机, 2012, 42(11):6-10. Zhou Li, Liu Yibo, Guo Ning, et al. Developments status of underwater welding technology[J]. Electric Welding Machine, 2012, 42(11):6-10.
    [4] 朱加雷, 焦向东, 蒋力培, 等. 水下焊接技术的研究与应用现状[J]. 焊接技术, 2009, 38(8):4-7. Zhu Jialei, Jiao Xiangdong, Jiang Lipei, et al. Research and application developments of underwater welding technology[J]. Welding Technology, 2009, 38(8):4-7.
    [5] 曹凤国, 张勤俭. 超声加工技术的研究现状及其发展趋势[J]. 电加工与模具, 2005(S1):25-31. Cao Fengguo, Zhang Qinjian. Research situation and development trends of the ultrasonic machining technology[J]. Electromachining & Mould, 2005(S1):25-31.
    [6] 范阳阳, 孙清洁, 杨春利, 等. 基于超声振动的304不锈钢TIG焊接[J]. 焊接学报, 2009, 30(2):91-94. Fan Yangyang, Sun Qingjie, Yang Chunli, et al. TIG welding of the stainless steel 304 based on the ultrasonic vibration[J]. Transactions of the China Welding Institution, 2009, 30(2):91-94.
    [7] 贺地求, 李剑, 李东辉, 等. 铝合金超声搅拌复合焊接[J]. 焊接学报, 2011, 32(12):70-72. He Diqiu, Li Jian, Li Donghui, et al. Study on ultrasonic stir hybrid welding of aluminum alloy[J]. Transactions of the China Welding Institution, 2011, 32(12):70-72.
    [8] 吴敏生, 何龙标, 李路明, 等. 电弧超声焊接技术[J]. 焊接学报, 2005, 26(6):40-44. Wu Minsheng, He Longbiao, Li Luming, et al. Arc-excited ultrasonic welding technology[J]. Transactions of the China Welding Institution, 2005, 26(6):40-44.
    [9] 马慧坤, 贺地求, 刘金书. 超声对不同铝合金搅拌摩擦焊接头性能的影响[J]. 焊接学报, 2012, 33(1):6-8. Ma Huikun, He Diqiu, Liu Jinshu. Effects of ultrasonic on properties of joints welded by friction stir welding process[J]. Transactions of the China Welding Institution, 2012, 33(1):6-8.
    [10] 赵君文, 戴光泽, 韩靖, 等. 功率超声在金属焊接中应用的研究进展[J]. 金属铸锻焊技术, 2012, 41(9):144-147. Zhao Wenjun, Dai Guangze, Han Jing, et al. Research progress of application of powder ultrasound in metal welding[J]. Casting Forging Welding, 2012, 41(9):144-147.
