超声振动辅助A7N01铝合金激光-MIG复合焊接组织及力学性能

朱宗涛, 祝全超, 李远星, 陈辉

朱宗涛, 祝全超, 李远星, 陈辉. 超声振动辅助A7N01铝合金激光-MIG复合焊接组织及力学性能[J]. 焊接学报, 2016, 37(6): 80-84.
引用本文: 朱宗涛, 祝全超, 李远星, 陈辉. 超声振动辅助A7N01铝合金激光-MIG复合焊接组织及力学性能[J]. 焊接学报, 2016, 37(6): 80-84.
ZHU Zongtao, ZHU Quanchao, LI Yuanxing, CHEN Hui. Microstructure and mechanical property of A7N01 aluminum alloy welded by laser-MIG hybrid method with assisting ultrasonic vibration[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(6): 80-84.
Citation: ZHU Zongtao, ZHU Quanchao, LI Yuanxing, CHEN Hui. Microstructure and mechanical property of A7N01 aluminum alloy welded by laser-MIG hybrid method with assisting ultrasonic vibration[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(6): 80-84.

超声振动辅助A7N01铝合金激光-MIG复合焊接组织及力学性能

基金项目: 国家自然科学基金资助项目(51405398);中央高校基本科研业务费专项资金资助(2682015CX007)

Microstructure and mechanical property of A7N01 aluminum alloy welded by laser-MIG hybrid method with assisting ultrasonic vibration

  • 摘要: 文中针对铝合金激光-MIG复合深熔焊过程易出现气孔缺陷问题,设计了超声振动辅助的焊接方法。通过对堆焊试样的X射线探伤和截面的宏观金相观察,对比了超声振动对气孔的数量、大小以及分布位置的影响。同时研究了超声振动作用对A7N01铝合金激光-MIG复合熔覆层的成形、组织及力学性能的影响。结果表明,在超声振动作用下,激光-MIG复合堆焊熔覆层气孔的数量明显减少,小尺寸气孔发生聚集并有上浮趋势;熔合线附近的柱状晶组织宽度明显小于无超声辅助的熔覆层;超声振动辅助激光-MIG复合焊接接头各区的冲击吸收功和抗拉强度都有一定程度的提高,具有一定的应用优势。
    Abstract: To solve the porosity defects in aluminum alloy joints obtained by laser-MIG hybrid deep-penetration welding, this article presents a novel laser-MIG hybrid welding method through applying ultrasonic vibration to the work piece. The number, size and distribution position of porosities in building-up layer on A7N01 aluminum alloy are investigated by X-ray detection and cross-section observation in stereo microscope. The effects of ultrasonic vibration on the morphology, microstructure and mechanical properties of the joints are also studied. The results show that the number and size of the porosities in building-up layer by laser-MIG hybrid welding significantly decrease, due to ultrasonic vibration accelerating the gathering and rising of small size porosities. The belt of columnar grains along fusion line near the building-up layer becomes thinner with the effects of ultrasonic vibration. The impact toughness and tensile strength are improved in some extent due to the introduced ultrasonic vibration in the laser-MIG hybrid welding method, so that it is supposed to be a good way for aluminum alloy welding.
  • [1] Ema M, Sasabe S. Joint strength of Al-Mg-Si alloys for automobiles by advanced welding technologies[J]. Welding International, 2004, 18(1): 11-15.
    [2] Fukami K, Setoda K. Development of high-efficiency MIG-laser hybrid welding technology[J]. Light Metal Welding and Construction, 2010, 48(11): 413-418.
    [3] 许良红, 田志凌, 彭 云, 等. 高强铝合金的MIG以及激光-MIG焊接工艺对比[J]. 焊接学报, 2007, 28(2): 38-43. Xu Lianghong, Tian Zhiling, Peng Yun, et al. Comparison of MIG welding and laser-MIG welding of high strength aluminum alloy[J]. Transactions of the China Welding Institution, 2007, 28(2): 38-43.
    [4] 严 军. 光纤激光-电弧复合焊接高强铝合金工艺、 缺陷产生与质量控制[D]. 武汉: 华中科技大学, 2011.
    [5] 杨 璟. 铝合金激光深溶焊接过程行为及缺陷控制研究[D]. 北京: 北京工业大学, 2011.
    [6] Katayama S, Nagayama H, Mizutani M, et al. Fibre laser welding of aluminium alloy[J]. Welding International, 2009, 23(10): 744-752.
    [7] 雷正龙, 李 颖, 陈彦宾, 等. 双光束激光填丝焊工艺对铝合金焊接气孔率的影响[J]. 焊接学报, 2013, 34(2): 40-44. Lei Zhenglong, Li Ying, Chen Yanbin, et al. Effect of process parameters on porosity formation ratio in dual-beam laser welding of aluminum alloys with filler wire[J]. Transactions of the China Welding Institution, 2013, 34(2): 40-44.
    [8] 许志武, 闫久春, 钟 利, 等. 铝合金超声波钎焊过程中液态钎料的填缝及界面润湿行为[J]. 材料工程, 2010(10): 1-5. Xu Zhiwu, Yan Jiuchun, Zhong Li, et al. Filling and wetting behaviors of liquid filler metal in the process of ultrasonic Soldering of aluminum alloy[J]. Journal of Materials Engineering, 2010(10): 1-5.
    [9] 孙清洁. 超声-TIG电弧复合焊接方法及电弧行为研究[D]. 哈尔滨:哈尔滨工业大学, 2010.
    [10] Kim J S, Watanabe T, Yoshida Y. Ultrasonic vibration aided laser welding of Al alloys: improvement of laser welding-quality[J]. Journal of Laser Applications, 1995(7): 38-46.
    [11] Eskin G I. Principles of ultrasonic treatment: application for light alloy melts[J]. Advanced Performance Materials, 1997, 4(2): 223-232.
    [12] Xu H B, Jian X G, T, Meek T, et al. Degassing of molten aluminium A356 alloy using ultrasonic vibration[J]. Materials Letters, 2004, 58: 3669-3673.
    [13] 李军文, 付 莹, 桃野正. 超声波处理时间对铝合金铸锭内的气孔生成及细化的影响[J]. 铸造技术, 2006, 27(10): 1063-1066. Li Junwen, Fu Ying, Momono Tadaashi. Effect of ultrasonic treating time on the formation of blowhole and refinement in the aluminum ingot[J]. Foundry Technology, 2006, 27(10): 1063-1066.
    [14] 李军文, 桃野正, 付 莹. 超声波功率对铸锭内的气孔及组织细化的影响[J]. 铸造, 2007, 56(2): 152-157. Li Junwen, Momono Tadaashi, Fu Ying. Effect of ultrasonic power on density and refinement in aluminum ingot[J]. Foundry, 2007, 56(2): 152-157.
