ABS塑料与6082铝合金搅拌摩擦点焊工艺及机理

王希靖, 王小龙, 张忠科, 邓向斌

王希靖, 王小龙, 张忠科, 邓向斌. ABS塑料与6082铝合金搅拌摩擦点焊工艺及机理[J]. 焊接学报, 2016, 37(4): 107-110.
引用本文: 王希靖, 王小龙, 张忠科, 邓向斌. ABS塑料与6082铝合金搅拌摩擦点焊工艺及机理[J]. 焊接学报, 2016, 37(4): 107-110.
WANG Xijing, WANG Xiaolong, ZHANG Zhongke, DENG Xiangbin. Process and mechanism of friction stir spot welding between ABS plastic and 6082 aluminum alloy[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(4): 107-110.
Citation: WANG Xijing, WANG Xiaolong, ZHANG Zhongke, DENG Xiangbin. Process and mechanism of friction stir spot welding between ABS plastic and 6082 aluminum alloy[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(4): 107-110.

ABS塑料与6082铝合金搅拌摩擦点焊工艺及机理

Process and mechanism of friction stir spot welding between ABS plastic and 6082 aluminum alloy

  • 摘要: 针对2 mm厚的ABS塑料板和6082-T6铝合金进行搅拌摩擦点焊可焊性试验,并将成形较好的试件的横截面的形貌进行了观察分析,并对其进行力学性能的测试.结果表明,将铝合金板放在上,塑料板放在下的搭接方式可以实现良好的连接;最优工艺参数为搅拌头旋转速度为400 r/min,焊接时间为30 s,所得焊接接头的抗拉剪载荷最大为3.31 kN;点焊接头有两种断裂模式.
    Abstract: Weldability test on 2 mm thick ABS plastic and 6082-T6 aluminum alloy sheets were conducted by friction stir spot welding. The cross-section of resultant specimen was observed and analyzed, and the mechanical properties of the joint were measured. It is found that good connection could be obtained with aluminum alloy on the top and plastic at the bottom. The optimal welding parameters were rotation speed of 400 r/min and welding time of 30 s. The maximum tensile shear load of the welded joints reached 3.31 kN. The spot joints failed with two fracture modes.
  • [1] 李永斌. 李亚庭. 桥车车身轻量化及其对连接技术的挑战[J]. 机械工程学报, 2012, 48(18):45-51. Li Yongbing, Li Yating. Lightweighting of car body and its challenges to joining technologies[J]. Joural of Mechanal Engineering, 2012, 48(18):45-51.
    [2] Dorn Lutz, Moniatis Georgios. Effects of joining component material and adhesive on the strength behaviour of plastics-to-metal adhesive-bonded joints[J]. Welding and Cutting, 1990, 42(3):50-52.
    [3] Liu Liming, Xie Long. Adhesive bonding between between Mg alloys and polypropylene[J]. Materials Technology, 2007, 22(2):76-100.
    [4] Flock Dustin, Haberstroh Edmund, Bobzin Kirsten. Ultrasonic welding of hybrid metal-plastic components with flame spraying of adhesion layer[J]. Journal of Plastics Technology, 2011, 25(5):160-177.
    [5] 张宗波, 王晓东, 罗怡. 超声波塑料焊接机理[J].焊接学报, 2010, 31(11):29-32. Zhang Zhongbo, Wang Xiaodong, Luo Yi. Ultrasonic welding mechanism of thermoplastics and its thermal process[J]. Transactions of the China Welding Institution, 2010, 31(11):29-32.
    [6] 龚飞, 胡席远, 谭赟. 热塑性塑料PP半导体激光焊接工艺[J]. 焊接学报, 2013, 34(4):109-112. Gong Fei, Hu Xiyuan, Tai Yun. Semiconductor laser transmission welding of thermoplastic polypropylene[J]. Transactions of the China Welding Institution, 2013, 34(4):109-112.
    [7] 王霄, 杨昆, 张惠中. 两种不同热塑性塑料之间的激光透射焊接试验[J]. 焊接学报, 2009, 30(5):97-100. Wang Xiao, Yang Kun, Zhang Huizhong. Experiment research on laser transmission welding of two different thermoplastics[J]. Transactions of the China Welding Institution, 2009, 30(5):97-100.
    [8] Spinella D J, Brockenbrough. Trends in aluminum resistance spot welding for the automotive industry[J]. Welding Journal, 2005, 84(1):34-40.
    [9] Liu F C, Liao J, Nakata K. Joining of metal to plastic using friction lap welding[J]. Materials and Design, 2014, 54(2):236-244.
    [10] Yusof F, Miyashita Y, Seo N, et al. Utilising friction spot joining for dissimilar joint between aluminium alloy (A5052) and polyethylene terephthalate[J]. Sci. Tech. Weld Join 2012, 17(7):544-559.
