SUS301L不锈钢非熔透型激光搭接焊的疲劳特性分析

朱国仁, 陈松, 李蒙蒙

朱国仁, 陈松, 李蒙蒙. SUS301L不锈钢非熔透型激光搭接焊的疲劳特性分析[J]. 焊接学报, 2016, 37(4): 14-18.
引用本文: 朱国仁, 陈松, 李蒙蒙. SUS301L不锈钢非熔透型激光搭接焊的疲劳特性分析[J]. 焊接学报, 2016, 37(4): 14-18.
ZHU Guoren, CHEN Song, LI Mengmeng. Study on fatigue performance of stainless steel non-penetration laser lap welding of SUS301L stainless steel body[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(4): 14-18.
Citation: ZHU Guoren, CHEN Song, LI Mengmeng. Study on fatigue performance of stainless steel non-penetration laser lap welding of SUS301L stainless steel body[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(4): 14-18.

SUS301L不锈钢非熔透型激光搭接焊的疲劳特性分析

基金项目: 科技部国际合作资助项目(2009DFR80040)

Study on fatigue performance of stainless steel non-penetration laser lap welding of SUS301L stainless steel body

  • 摘要: 通过对轨道客车试验用不锈钢熔透型和非熔透型激光焊接头及电阻点焊接头不同的拉力和疲劳对比试验,疲劳试验采用阶梯法和成组法,并进行初步断裂力学和微观分析.结果表明,不锈钢车体非熔透型激光焊具有较熔透型激光焊和电阻点焊更高的疲劳强度,同时在相同激光焊接参数下,改变非熔透型激光焊工艺中非熔透板厚度,能直接影响其工艺的剪切拉伸强度和疲劳强度,加厚非熔透板,疲劳强度提高,剪切拉伸强度降低.
    Abstract: With shear tension and fatigue strength tests on penetration and non-penetration stainless steel laser welding head and resistance welding head that are used in rail train tests and a preliminary analysis of the microstructure and fracture mechanics, which fatigue tests use the staircase method and group method. It can concludd that non-penetration laser welding stainless steel body has higher fatigue strength than penetration laser welding and resistance spot welding. And under the same laser welding parameters it could directly affect craft shear and fatigue strength when changing the non-penetration plate's thickness of the non-penetration laser welding craft.
  • [1] 王洪潇, 史春元, 王春生, 等. 铁道客车用SUS30IL不锈钢非熔透型激光搭接焊工艺[J]. 热加工工艺, 2009, 38(19):136-139. Wang Hongxiao, Shi Chunyuan, Wang Chunsheng, et al. Study on laser welding process for stainless steel railway vehicle[J]. Casting·Forging·Welding Hot Working Technology 2009, 38(19):136-139.
    [2] 师文庆, 杨永强, 王迪, 等. 脉冲激光焊接H62黄铜[J]. 焊接学报, 2010(7):101-104. Shi Wenqing, Yang Yongqiang, Wang Di, et al. Study on pulse laser welding of H62 brass[J]. Transactions of the China Welding Institution, 2010(7):101-104.
    [3] 机械工业部哈尔滨焊接研究所. GB/T15111-94, 点焊接头剪切拉伸疲劳试验方法[S]. 哈尔滨:中国国家标准; 1995.
    [4] 南车集团, 北车集团. EN15085-3, 轨道应用-轨道车辆及其部件焊接-第三部分. 设计要求[S]. 北京:中国国家标准, 2011.
    [5] ISO/TC44. ISO13920, 焊接-焊接结构的一般公差-长度和角度的尺寸-形状和位置[S]. 布鲁塞尔:国际标准化组织标准, 1996.
    [6] 朱国仁, 陈松, 王振宝. 不锈钢点焊接头S-N曲线转折点的优化过渡[J]. 焊接学报, 2014, 35(8):009. Zhu Guoren, Chen Song, Wang Zhenbao, et al. Optimization of transition in stainless steel welding joints S-N curve breaking point[J]. Transactions of the China Welding Institution, 2014, 35(8):009.
    [7] 商镇同. 疲劳应用统计学[M]. 北京:国防工业出版社, 1886.
    [8] 陈雪艳, 岳译新, 苏柯. 城轨车辆不锈钢激光焊侧墙搭接接头的研究[J]. 技术与市场, 2012, 19(6):134-135. Chen Xueyan, Yue Yixin, Su Ke, et al. Study on laser welding process for stain less steel rail way vehicle[J]. Technology and Market, 2012, 19(6):134-135.
    [9] 朱小刚, 王联凤, 乔凤斌, 等. 6061-T6铝合金回填式搅拌摩擦点焊疲劳性能分析[J]. 焊接学报, 2014, 35(4):91-94. Zhu Xiaogang, Wang Lianfeng, Qiao Fengbin, et al. Fatigue failure analysis of 6061-T6 aluminum alloy refilled friction stir spot welding[J]. Transactions of the China Welding Institution, 2014, 35(4):91-94.
    [10] BSI BS7608. Code of practice for fatigue design and assessment of steel structures[S]. London:British Standards Institution, 1993.
    [11] 史耀武. 焊接技术手册[M]. 北京:化学工业出版社, 2009.
