主管旋转式相贯曲线自动焊接模型与仿真
Model and simulation of automatic intersecting curve welding with main pipe rotating welding scheme
-
摘要: 相贯管道的主管旋转式焊接方式能够实现相贯焊缝的全过程平角焊,降低工艺复杂度并提高焊接质量. 为了实现相贯管道的自动化焊接,建立了主管旋转式相贯曲线自动焊接模型. 以一般性相贯管道几何模型为基础,用齐次变换矩阵分析了焊缝特征和焊枪姿态,得出了主管旋转角的变化规律及焊枪与世界坐标系的空间位置关系. 利用MATLAB和OpenGL对相贯管道的几何模型和焊接过程的运动模型进行了仿真. 结果表明,该自动焊接模型是可行的,可以用于主管旋转式相贯曲线自动焊接的实时插补或离线编程.Abstract: The main pipe rotating welding scheme for intersecting pipes can reduce technology complexity and improve welding quality by achieving whole process of horizontal vertical position welding. In order to realize the automatic welding for intersecting pipes, the automatic welding model of intersecting curve with main pipe rotating welding scheme is established. On the basis of the geometrical model of the intersecting pipes, the welding seam feature and the welding torch pose are analyzed with homogeneous transformation matrix. After that, the main pipe rotation angle and the welding torch's position and posture relative to the world frame are formulated. The geometrical model of the intersecting pipes and the kinematic model of the welding process are simulated by MATLAB and OpenGL respectively. The simulation results show that the automatic welding model is feasible and can be used for the real-time interpolation and the off-line programming of automatic intersecting curve welding.
-
Keywords:
- main pipe rotating /
- intersecting curve /
- automatic welding
-
-
[1] 亓化振, 田新诚, 张雪伊, 等. 基于角度逼近的马鞍形曲线自动焊接插补算法[J]. 焊接学报, 2007, 28(3): 93-96. Qi Huazhen, Tian Xincheng, Zhang Xueyi, et al. Interpolation algorithm for saddle-shaped curve auto-welding based on angle approaching[J]. Transactions of the China Welding Institution, 2007, 28(3): 93-96. [2] 霍孟友, 王新刚, 尹 萍. 自动焊接相贯线接缝的实时插补控制算法与仿真[J]. 焊接学报, 2006, 27(11): 37-40. Huo Mengyou, Wang Xingang, Yin Ping. Real-time interpolation algorithm and simulation of seam of intersection line for automatic welding[J]. Transactions of the China Welding Institution, 2006, 27(11): 37-40. [3] 吕 燕, 田新诚, 徐 青, 等. 马鞍形曲线自动焊接四轴联动插补算法[J]. 焊接学报, 2009, 30(5): 81-84. Lü Yan, Tian Xincheng, Xu Qing, et al. Four-axis interpolation algorithm for automatic welding of saddle type curve weld[J]. Transactions of the China Welding Institution, 2009, 30(5): 81-84. [4] 李晓辉, 汪 苏. 骑座相贯线焊接机器人运动学分析及仿真[J]. 北京航空航天大学学报, 2008, 34(8): 964-968. Li Xiaohui, Wang Su. Kinematic analysis and simulation of saddle-back coping welding robot[J]. Journal of Beijing University of Aeronautics and Astronautics, 2008, 34(8): 964-968. [5] 任福深, 陈树君, 管新勇, 等. 管道插接相贯线专用焊接机器人[J]. 焊接学报, 2009, 30(6): 59-62. Ren Fushen, Chen Shujun, Guan Xinyong, et al. Special-purpose welding robot for intersection welding seam[J]. Transactions of the China Welding Institution, 2009, 30(6): 59-62. [6] Liu Yu, Zhao Jing, Lu Zhenyang, et al. Pose planning for the end-effector of robot in the welding of intersecting pipes[J]. Chinese Journal of Mechanical Engineering, 2011, 24(2): 264-270. [7] Wright R S, Haemel N, Sellers G M, et al. OpenGL superbible: comprehensive tutorial and reference[M]. 5th edition. Boston: Addison-Wesley, 2010. -
