电流作用下Cu/Sn-15Bi/Cu焊点的组织演变

郭沁涵,赵振江,沈春龙

郭沁涵,赵振江,沈春龙. 电流作用下Cu/Sn-15Bi/Cu焊点的组织演变[J]. 焊接学报, 2017, 38(10): 103-106. DOI: 10.12073/j.hjxb.20170730003
引用本文: 郭沁涵,赵振江,沈春龙. 电流作用下Cu/Sn-15Bi/Cu焊点的组织演变[J]. 焊接学报, 2017, 38(10): 103-106. DOI: 10.12073/j.hjxb.20170730003

电流作用下Cu/Sn-15Bi/Cu焊点的组织演变

  • 摘要: 对Cu/Sn-15Bi/Cu焊点在150℃下的电迁移组织演变进行了研究. 结果表明,焊点阳极侧出现了近共晶相的偏聚,近共晶相厚度随电迁移时间的延长而逐渐增加;受“电子风”力的影响,钎料中Cu6Sn5金属间化合物逐渐向阳极侧偏聚,此外,由于阴极侧Cu6Sn5界面金属间化合物的脱落,钎料中的Cu6Sn5金属间化合物体积分数逐渐增加;焊点阴极侧界面金属间化合物厚度随电迁移时间延长逐渐增加,阳极侧界面金属间化合物厚度随电迁移时间延长先增加,后降低,当电迁移时间超过5 h后,界面金属间化合物厚度迅速增加.
  • [1] Xu J, Xue S, Xue P,et al. Study on microstructure and properties of Sn-0.3Ag-0.7Cu solder bearing Nd[J]. Journal of Materials Science: Materials in Electronics, 2016, 27(8): 8771-8777.[2] 韩翼龙, 薛松柏, 薛 鹏, 等. Pr,Nd对Sn-0.3Ag-0.7Cu-0.5Ga无铅钎料显微组织的影响[J]. 焊接学报, 2017, 38(1): 103-106.Han Yilong, Xue Songbai, Xue Peng,et al. Effects of rare earth element Pr and Nd on microstructure of Sn-0.3Ag-0.7Cu-0.5Ga lead-free solder[J]. Transactions of the China Welding Institution, 2017, 38(1): 103-106.[3] 徐佳琛, 薛松柏, 薛 鹏, 等. Sn-0.3Ag-0.7Cu-xNd钎料显微组织及性能[J]. 焊接学报, 2015, 36(1): 83-86.Xu Jiachen, Xue Songbai, Xue Peng,et al. Effect of Nd on properties and microstructure of Sn-0.3Ag-0.7Cu-xNd lead-free solder[J]. Transactions of the China Welding Institution, 2015, 36(1): 83-86.[4] 邱希亮, 郝成丽, 修子扬, 等. Y2O3/Sn-58Bi复合钎料制备及其性能分析[J]. 焊接学报, 2017, 38(1): 91-94.Qiu Xiliang, Hao Chengli, Xiu Ziyang,et al. Preparation and properties of Y2O3/Sn-58Bi composite solders[J]. Transactions of the China Welding Institution, 2017, 38(1): 91-94.[5] 邱希亮, 魏红梅, 王 倩, 等. 多次重熔过程中La2O3对Sn-58Bi钎料组织及性能的影响[J]. 材料科学与工艺, 2015, 23(1): 20-24.Qiu Xiliang, Wei Hongmei, Wang Qian,et al. Effect of La2O3particles on structure and properties of Sn-58Bi solder after multi-remelting[J]. Materials Science and Technology, 2015, 23(1): 20-24.[6] 邱希亮, 王 倩, 林铁松, 等. 硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物层演变及剪切行为的影响[J]. 焊接学报, 2015, 36(8): 35-38.Qiu Xiliang, Wang Qian, Lin Tiesong,et al. Effect of Al18B4O33whiskers on microstructure evolution of intermetallic compound layer and shear behavior of soldered joint[J]. Transactions of the China Welding Institution, 2015, 36(8): 35-38.[7] Ye H, Xue S, Luo J,et al. Properties and interfacial microstructure of Sn-Zn-Ga solder joint with rare earth Pr addition[J]. Materials & Design, 2013, 46(4): 816-823.[8] Zhang J, Xue S, Xue P,et al. Thermodynamic reaction mechanism of the intermetallic compounds of SnxNdy, and GaxNdy, in soldered joint of Sn-9Zn-1Ga-0.5Nd[J]. Journal of Materials Science: Materials in Electronics, 2015, 26(5):1-5.[9] Kim D G, Moon W C, Jung S B. Effects of electromigration on microstructural evolution of eutectic SnPb flip chip solder bumps[J]. Microelectronic Engineering, 2006, 83(11): 2391-2395.[10] Liang S B, Ke C B, Ma W J,et al. Phase field simulation of Segregation of the bi-riched phase in Cu/Sn-Bi/Cu solder interconnects under electric current stressing[C]∥IEEE Electronic Components and Technology Conference, 2016: 264-270.[11] 何洪文, 徐广臣, 郭 福. 电迁移促进Cu/Sn-58Bi/Cu焊点阳极界面Bi层形成的机理分析[J]. 焊接学报, 2010, 31(10): 35-38.He Hongwen, Xu Guangchen, Guo Fu. Mechanism investigation of Bi layer formation at anode interface in Cu/Sn-58Bi/Cu solder joint induced by electro-migration[J]. Transactions of the China Welding Institution, 2010, 31(10): 35-38.[12] Li Y, Lim A B Y, Luo K,et al. Phase segregation, interfacial intermetallic growth and electromigration-induced failure in Cu/In-48Sn/Cu solder interconnects under current stressing[J]. Journal of Alloys and Compounds, 2016, 673:372-382.[13] Li Y, Wu F, Chan Y C. Electromigration in eutectic In-48Sn ball grid array (BGA) solder interconnections with Au/Ni/Cu pads[J]. Journal of Materials Science: Materials in Electronics, 2015, 26(11): 8522-8533.[14] 王 凯. 无铅软钎料焊点界面Cu6Sn5相的电迁移行为研究[D]. 哈尔滨: 哈尔滨工业大学, 2013.[15] Lai Z, Ye D. Microstructure and properties of Sn-10Bi-xCu solder alloy/joint[J]. Journal of Electronic Materials, 2016, 45(7): 3702-3711.[16] Lai Z, Ye D. Effect of cooling method and aging treatment on the microstructure and mechanical properties of Sn-10Bi solder alloy[J]. Journal of Materials Science-Materials in Electronics, 2015, 27(2): 1-10.
