大型构件水下焊接机器人系统
System of underwater welding robot for large-scale structure
-
摘要: 针对水下焊接环境要求,设计了一种履带式水下焊接机器人系统,该系统由机器人本体机构、激光视觉传感器、控制系统和焊接系统组成. 机器人本体机构由履带式移动平台和焊枪调节机构构成,运动灵活可靠,满足水下焊接焊缝跟踪要求. 完成了视觉传感器部件选型及光路设计,实现水下环境的焊缝自动识别. 设计了基于PLC机器人控制系统和协调控制方法,实现水下环境的焊缝跟踪控制. 同时在水下焊接试验平台完成焊接跟踪试验. 结果表明,机器人运行稳定,焊缝成形较好,焊接质量满足要求.Abstract: An underwater welding robot system for large-scale structure is introduced for the environment of underwater welding and the system is composed of a robot mechanism, laser vision sensor, control system and welding system. The robot mechanism is composed of a pedrailed mobile platform and a torch adjustment mechanism and which can move flexibly for meeting the requirements of underwater welding. The components of sensor are selected and the optical path is also designed for the laser vision sensor to automatic welding seam identification. The PLC control system for the welding robot is designed and the coordinated control method is also adopted to achieve seam tracking accurately. And the underwater welding test platform is also completed. The results show that the robot operates steadily, reliably and the satisfactory welding quality is also obtained.
-
Keywords:
- underwater welding robot /
- laser vision sensor /
- seam tracking /
- coordinate control
-
-
[1] 林柏山. 国内外水下焊接研究概况[M]. 哈尔滨: 哈尔滨焊接研究所, 1986. [2] Pandey R K, Swetnam D. Dry hyperbaric MMA welding[J]. Welding and Metal Fabrication, 1985, 53(6): 230-238. [3] 管泰雄, 蓮井淳. 高圧ヘリウム雰囲気中におけるアークの特性について[J]. 溶接学会论文集, 1988, 6(1): 86-91. [4] 朱加雷, 焦向东, 周灿丰, 等. 304不锈钢局部干法自动水下焊接[J]. 焊接学报, 2009, 30(1): 29-32. Zhu Jialei, Jiao Xiangdong, Zhou Canfeng, et al. Local dry automatic underwater welding of 304 stainless steel[J]. Transactions of the China Welding Institution, 2009, 30(1): 29-32. [5] 蒋力培, 王中辉, 焦向东, 等. 水下焊接高压空气环境下GTAW电弧特性[J]. 焊接学报, 2007, 28(6): 1-4. Jiang Lipei, Wang Zhonghui, Jiao Xiangdong, et al. Characteristics of GTAW arc in underwater welding under high-pressure air condition[J]. Transactions of the China Welding Institution, 2007, 28(6): 1-4. [6] 李志刚, 张 华, 贾剑平, 等. 高压水环境模糊滑模焊缝跟踪[J]. 焊接学报, 2010, 31(6): 17-20, 24. Li Zhigang, Zhang Hua, Jia Jianping, et al. Weld seam tracking with fuzzy sliding mode controller in high-pressure water environment [J]. Transactions of the China Welding Institution, 2010, 31(6): 17-20, 24. -
