杨淼森, 孙凤莲, 邹鹏飞. 低银SnAgCuBi-xNi/Cu焊点塑性及蠕变性能[J]. 焊接学报, 2014, 35(3): 31-34.
引用本文: 杨淼森, 孙凤莲, 邹鹏飞. 低银SnAgCuBi-xNi/Cu焊点塑性及蠕变性能[J]. 焊接学报, 2014, 35(3): 31-34.
YANG Miaosen, SUN Fenglian, ZOU Pengfei. Plasticity and creep performance of low-Ag SnAgCuBi-xNi/Cu solder joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2014, 35(3): 31-34.
Citation: YANG Miaosen, SUN Fenglian, ZOU Pengfei. Plasticity and creep performance of low-Ag SnAgCuBi-xNi/Cu solder joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2014, 35(3): 31-34.

低银SnAgCuBi-xNi/Cu焊点塑性及蠕变性能

Plasticity and creep performance of low-Ag SnAgCuBi-xNi/Cu solder joint

  • 摘要: 借助纳米压痕方法,基于压痕做功和压痕蠕变的原理,对SnAgCuBi-xNi/Cu(x=0,0.05,0.1,0.15,0.2)低银焊点的塑性和抗蠕变性能进行了研究.结果表明,在SnAgCuBi-xNi/Cu焊点中,Ni元素含量为0.05%和1%,焊点的硬度和塑性提高,抗蠕变性能变化不明显,Ni元素含量为0.15%和0.2%,焊点的硬度和抗蠕变性能提高,但焊点塑性下降.Ni元素的添加有利于提高SnAgCuBi/Cu焊点的高温稳定性.在150℃下经400 h老化,焊点的抗蠕变性能随着Ni元素含量的增加而增强,含镍焊点的硬度均高于SnAgCuBi/Cu焊点,Ni元素含量为0.1%的焊点塑性最好.



    Abstract: In order to study the effect of Ni on plasticity and creep performance of low-Ag SnAgCuBi-xNi/Cu(x=0,0.05,0.1,0.15,0.2) solder joint, the indentation work and indentation creep were measured and analyzed by nanoindentation method. The results show that adding Ni could improve the hardness of solder joint. Adding amounts of 0.05% and 0.1% Ni is helpful to improve the plasticity performance but produce almost no impacts on creep. A further Ni adding amount (0.15% and 0.2%) can improve the creep resistance at the expense of plasticity. It is found that Ni can improve high temperature stability of SnAgCuBi/Cu solder joints. The creep resisting performance of the solder joints is improved with Ni element increasing after 400 h aging at 150℃. The hardness of solder joints is improved with the Ni addition. The plasticity performance of solder joints with 0.1% Ni content is better than others.



/
