陶瓷硬质相对铁基复合材料组织和性能的影响

贾华, 刘政军, 李萌, 张琨

贾华, 刘政军, 李萌, 张琨. 陶瓷硬质相对铁基复合材料组织和性能的影响[J]. 焊接学报, 2019, 40(9): 122-127. DOI: 10.12073/j.hjxb.2019400247
引用本文: 贾华, 刘政军, 李萌, 张琨. 陶瓷硬质相对铁基复合材料组织和性能的影响[J]. 焊接学报, 2019, 40(9): 122-127. DOI: 10.12073/j.hjxb.2019400247
JIA Hua, LIU Zhengjun, LI Meng, ZHANG Kun. Effect of ceramic phase on microstructure and mechanical properties of ferrous matrix composite[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 122-127. DOI: 10.12073/j.hjxb.2019400247
Citation: JIA Hua, LIU Zhengjun, LI Meng, ZHANG Kun. Effect of ceramic phase on microstructure and mechanical properties of ferrous matrix composite[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(9): 122-127. DOI: 10.12073/j.hjxb.2019400247

陶瓷硬质相对铁基复合材料组织和性能的影响

基金项目: 辽宁省教育厅一般科研项目资助(L2015075)

Effect of ceramic phase on microstructure and mechanical properties of ferrous matrix composite

  • 摘要: 采用明弧堆焊技术在Q235基体金属表面制备Fe-Cr-C-B-N-Ti系铁基复合材料. 借助金相显微镜、扫描电子显微镜、X射线衍射仪、洛氏硬度计和磨料磨损试验机对铁基复合材料的组织和性能进行分析与测试. 结果表明,铁基复合材料的基体组织由马氏体(M)和少量残余奥氏体(A)组成,硬质相由TiB2,TiN,TiC,M23(C,B)6,M3(C,B)和M2B组成. 随着钛添加量的增多,初生陶瓷硬质相颗粒(TiB2,TiN和TiC)和共晶硬质相(M23(C,B)6,M3(C,B)和M2B)增多,基体组织减少并细化. 当钛添加量为4%时,铁基复合材料的耐磨性达到最佳,此时硬度为66 HRC,磨损量为0.042 9 g.
    Abstract: In order to improve the wear resistance of the material surface, the Fe-Cr-C-B-N-Ti-based iron matrix composite was prepared on the Q235 matrix metal surface by using the bright arc surfacing technology. Metallographic microscope, scanning electron microscope, X ray diffractometer, Rockwell hardness tester and abrasive wear tester were used to analyze and test the microstructure and properties of iron-based composites. The results show that the matrix structure of iron-based composites is composed of martensite (M) and a small amount of retained austenite (A), and the hard phase is composed of TiB2, TiN, TiC, M23 (C, B)6, M3 (C, B) and M2B. With the increase of titanium addition, the hardness phase particles (TiB 2, TiN and TiC) and eutectic hard phase (M23 (C, B)6, M3 (C, B) and M2B) increase, and the matrix structure decreases and refine. When the amount of titanium is 4%, the wear resistance of the iron matrix composite is the best, at this time the hardness is 66HRC and the wear amount is 0.042 9 g.
  • [1] Jiang M, Li Z X, Wang Y J, et al. Effect of vanadium on microstructures and properties of Fe-Cr-C self-shielded metal cored hardfacing alloys[J]. Science and Technology of Welding and Joining, 2008, 13(2):114-117.
    [2] 邵荷生,张清.金属的磨料磨损与耐磨材料[M].北京:机械工业出版社, 1988.
    [3] Liu Z J, Su J G, Liu D, et al. Influence of magnetic field on microstructure and properties of Ni60 plasma surfacing layer[J]. China Welding, 2005, 14(2):145-148.
    [4] 杜宝帅,李清明,王新洪,等.激光熔覆原位自生TiC-VC颗粒增强Fe基金属陶瓷涂层[J].焊接学报, 2007, 28(4):65-68 Du Baoshuai, Li Qingming, Wang Xinhong, et al. In situ synthesis of TiC-VC particles reinforced Fe-based metal matrix composite coating by laser cladding[J]. Transactions of the China Welding Institution, 2007, 28(4):65-68
    [5] 邹黎明,刘辛,王蕾,等.铸造碳化钨粉末物性对激光熔覆陶瓷颗粒增强Fe基复合材料耐磨性能的影响[J].稀有金属材料与工程, 2017, 46(4):1126-1131 Zou Liming, Liu Xin, Wang Lei, et al. Effects of cast tungsten carbide powder on wear resistance of laser cladding ceramic particle reinforced iron matrix composite[J]. Rare Metal Materials and Engineering, 2017, 46(4):1126-1131
    [6] 汪新衡,刘安民,钱书琨,等.激光熔覆Fe基TiB2+TiC金属陶瓷层的组织及摩擦磨损性能[J].材料保护, 2014, 47(1):52-54 Wang Xinheng, Liu Anmin, Qian Shukun, et al. Microstructure as well as friction and wear behavior of la-ser cladding Fe/TiB2-TiC iron-based cermet coating[J]. Journal of Materials Protection, 2014, 47(1):52-54
    [7] 耿振.氮弧熔覆TiN-TiB2/Fe基复合涂层组织与耐磨性研究[D].保定:河北农业大学, 2015.
    [8] 孟君晟,吉泽升.氩弧熔覆原位合成TiC-TiB2/Ti基复合涂层组织及性能分析[J].焊接学报, 2013, 34(9):67-70 Meng Junsheng, Ji Zesheng. Microstructure and properties of in-situ TiC-TiB2/Ti composite coating by argon arc cladding[J]. Transactions of the China Welding Institution, 2013, 34(9):67-70
    [9] 马世榜,夏振伟,徐杨,等.激光熔覆原位自生TiC颗粒增强镍基复合涂层的组织与耐磨性[J].材料工程, 2017, 45(6):24-30 Ma Shibang, Xia Zhenwei, Xu Yang, et al. Microstructure and abrasion resistance of in-situ TiC particles reinforced Ni-based composite coatings by laser cladding[J]. Journal of Materials Engineering, 2017, 45(6):24-30
    [10] 乔虹,李庆棠,符寒光,等.激光熔覆原位合成陶瓷相增强铁基熔覆层的组织和性能[J].焊接学报, 2015, 36(1):67-69 Qiao Hong, Li Qingtang, Fu Hanguang, et al. Microstructure and properties of in-situ synthesized ceramic phase reinforced Fe-based coating by laser cladding[J]. Transactions of the China Welding Institution, 2015, 36(1):67-69
    [11] Wang X H, Zhang M, Du B S, et al. Microstructure and wear properties of in situ multiple carbides reinforced Fe based surface composite coating produced by laser cladding[J]. Materials Science and Technology, 2010, 26(8):935-939.
    [12] 梁英教,车荫昌.无机物热力学数据手册[D].沈阳:东北大学出版社, 1993.
