新型9Cr-1Mo钢搅拌摩擦焊接头组织及性能

李胜利,  杨新岐,  唐文珅,  李会军

downloadPDF
文章导航 > 焊接学报  > 2019 >  40(4): 28-35
李胜利, 杨新岐, 唐文珅, 李会军. 新型9Cr-1Mo钢搅拌摩擦焊接头组织及性能[J]. 焊接学报, 2019, 40(4): 28-35. doi: 10.12073/j.hjxb.2019400095
引用本文: 李胜利, 杨新岐, 唐文珅, 李会军. 新型9Cr-1Mo钢搅拌摩擦焊接头组织及性能[J]. 焊接学报, 2019, 40(4): 28-35. doi: 10.12073/j.hjxb.2019400095
shu
LI Shengli, YANG Xinqi, TANG Wenshen, LI Huijun. Microstructure and mechanical properties of friction stir welded novel 9Cr-1Mo steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(4): 28-35. doi: 10.12073/j.hjxb.2019400095
Citation: LI Shengli, YANG Xinqi, TANG Wenshen, LI Huijun. Microstructure and mechanical properties of friction stir welded novel 9Cr-1Mo steel[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2019, 40(4): 28-35. doi: 10.12073/j.hjxb.2019400095
shu

新型9Cr-1Mo钢搅拌摩擦焊接头组织及性能

doi: 10.12073/j.hjxb.2019400095

  • 天津大学 天津市现代连接技术重点实验室，天津　300350

基金项目:

国际热核聚变实验堆(ITER)计划专项(2015GB119001)

详细信息
    作者简介:

    李胜利，男，1991年出生，博士. 主要从事耐热钢的搅拌摩擦焊工艺研究. Email: lishengli@tju.edu.cn

    通讯作者: 杨新岐，男，博士，教授，博士研究生导师. Email: xqyang@tju.edu.cn

  • 中图分类号: TG 453.9

Microstructure and mechanical properties of friction stir welded novel 9Cr-1Mo steel

  • Tianjin Key Laboratory of Advanced Joining Technology，Tianjin University, Tianjin 300350, China

  • 摘要: 采用钨铼合金搅拌工具对新型9Cr-1Mo钢进行搅拌摩擦焊工艺试验，探讨焊缝成形、组织及性能变化规律. 结果表明，在300和400 r/min的转速，50 mm/min的焊接速度下可获得无缺陷接头；焊缝主要由搅拌区和热力影响区组成，具有明显的马氏体淬硬组织特征；高温热影响区为淬硬马氏体和回火马氏体混合组织，低温热影响区为过回火马氏体组织. 焊缝区具有晶粒细化特征，其晶粒尺寸约为母材69.2%. 焊缝区产生明显硬化，最高硬度约为母材硬度值的2.0倍. 焊接接头抗拉强度达到母材98%以上，搅拌区和热影响区冲击吸收能量分别达到母材的77.8%和87.4%，表明搅拌摩擦焊接头仍具有较好强韧匹配.
    Abstract: The novel 9Cr-1Mo ferritic heat-resistant steel was selected to conduct friction stir welding experiment adopted tungsten-rhenium alloy tools, and the variation laws of weld formation, microstructure and mechanical properties were discussed. The results indicated that no defect welded joints could be obtained with the rotation speed of 300 and 400 r/min, and welding speed of 50 mm/min; the weld zone was mainly composed of stir zone and thermomechanical affected zone, which had obvious characteristics of hardened martensite microstructure; the high temperature heat affected zone presented mixed microstructures of hardened martensite and tempered martensite, and the low temperature heat affected zone showed over tempered martensite. The grains in the stir zone were refined and the average grain size of the stir zone was about 69.2% of that of the base metal. The weld zone had been significantly hardened, and the maximum hardness in the weld zone was more than 2.0 times of that of the base metal. The ultimate tensile strength of the welded joint reached about 98% of that of the base metal, and the V-shaped notched impact absorbed energy of the stir zone and heat affected zone reached 77.8% and 87.4% of that of the base metal respectively. Those results indicated that the friction stir welded joint still has the better matching between strength and toughness.
  • [1] Wu Guangfeng, Liu Hong, Ma Zhifei. Study on raising impact toughness of welded joint of P91 heat resistant steel[J]. Hot Working Technology, 2007, 36(11): 30 − 32
    [2] Zhou X, Liu C, Yu L, et al. Phase transformation behavior and microstructural control of high-Cr martensitic/ferritic heat-resistant steels for power and nuclear plants: a review[J]. Journal of Materials Science & Technology, 2015, 31(3): 235 − 42.
    [3] Klueh R L. Elevated temperature ferritic and martensitic steels and their application to future nuclear reactors[J]. International Materials Reviews, 2013, 50(5): 287 − 310.
    [4] Zhang Jing, Han Wentuo, Chang Yongqin, et al. Microstructure and mechanical properties in friction stir welded nanostructured oxide dispersion strengthened steel joint[J]. Transactions of the China Welding Institution, 2015, 36(10): 9 − 11
    [5] Murty K L, Charit I. Structural materials for Gen-IV nuclear reactors: challenges and opportunities[J]. Journal of Nuclear Materials, 2008, 383(1): 189 − 195.
    [6] Masuyama F. Creep degradation in welds of Mod. 9Cr-1Mo steel[J]. International Journal of Pressure Vessels and Piping, 2006, 83(11): 819 − 825.
    [7] 伍光凤, 刘 洪, 马志飞. 提高P91耐热钢焊接接头冲击韧度的研究[J]. 热加工工艺, 2007, 36(11): 30 − 32
    [8] Mishra R S, Ma Z Y. Friction stir welding and processing[J]. Materials Science and Engineering: R: Reports, 2005, 50(1): 1 − 78.
    [9] Han W T, Wan F R, Leng B, et al. Grain characteristic and texture evolution in friction stir welds of nanostructured oxide dispersion strengthened ferritic steel[J]. Science and Technology of Welding and Joining, 2011, 16(8): 690 − 696.
    [10] 张 静, 韩文妥, 常永勤, 等. ODS钢搅拌摩擦焊接头的微观组织及其高温力学性能[J]. 焊接学报, 2015, 36(10): 9 − 11
    [11] Du D, Fu R, Li Y, et al. Gradient characteristics and strength matching in friction stir welded joints of Fe-18Cr-16Mn-2Mo-0.85N austenitic stainless stee[J]. Materials Science and Engineering: A, 2016, 616: 246 − 251.
    [12] Wang D, Ni D R, Xiao B L, et al. Microstructural evolution and mechanical properties of friction stir welded joint of Fe-Cr-Mn-Mo-N austenite stainless steel[J]. Materials & Design, 2014, 64: 355 − 359.
    [13] Xie G M, Cui H B, Luo Z A, et al. Asymmetric distribution of microstructure and impact toughness in stir zone during friction stir processed a high strength pipeline steel[J]. Materials Science and Engineering: A, 2017, 704: 401 − 411.
    [14] Yano Y, Sato Y S, Sekio Y, et al. Mechanical properties of friction stir welded 11Cr-ferritic/martensitic steel[J]. Journal of Nuclear Materials, 2013, 442(1): S524 − S528.
    [15] Manugula V L, Rajulapati K V, Reddy G M, et al. A critical assessment of the microstructure and mechanical properties of friction stir welded reduced activation ferritic-martensitic steel[J]. Materials & Design, 2016, 92: 200 − 212.
    [16] Noh S, Ando M, Tanigawa H, et al. Friction stir welding of F82H steel for fusion applications[J]. Journal of Nuclear Materials, 2016, 478: 1 − 6.
    [17] Arbegast W J. Modeling friction stir joining as a metal working process[C]//San Diego, USA: Hot Deformation of Aluminum Alloys Ⅲ, 2003: 313–317.
