2219铝合金焊接接头晶间腐蚀行为

章淑芳, 郝云飞, 王晓敏, 陈辉, 廖潇垚, 李明星

章淑芳, 郝云飞, 王晓敏, 陈辉, 廖潇垚, 李明星. 2219铝合金焊接接头晶间腐蚀行为[J]. 焊接学报, 2017, 38(4): 22-26. DOI: 10.12073/j.hjxb.20170405
引用本文: 章淑芳, 郝云飞, 王晓敏, 陈辉, 廖潇垚, 李明星. 2219铝合金焊接接头晶间腐蚀行为[J]. 焊接学报, 2017, 38(4): 22-26. DOI: 10.12073/j.hjxb.20170405
shu
ZHANG Shufang, HAO Yunfei, WANG Xiaomin, CHEN Hui, LIAO Xiaoyao, LI Mingxing. Intergranular corrosion behavior of 2219 aluminum alloy's welding join[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 22-26. DOI: 10.12073/j.hjxb.20170405
Citation: ZHANG Shufang, HAO Yunfei, WANG Xiaomin, CHEN Hui, LIAO Xiaoyao, LI Mingxing. Intergranular corrosion behavior of 2219 aluminum alloy's welding join[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(4): 22-26. DOI: 10.12073/j.hjxb.20170405
shu

2219铝合金焊接接头晶间腐蚀行为

  • 1.

    西南交通大学 四川省先进焊接及表面工程技术研究中心, 成都 610031;西南交通大学 生命科学与工程学院, 成都 610031

  • 2.

    首都航天机械公司, 北京 100076

  • 3.

    西南交通大学 生命科学与工程学院, 成都 610031

  • 4.

    西南交通大学 四川省先进焊接及表面工程技术研究中心, 成都 610031

基金项目: 国家重点研发计划资助项目（2016YFB0700505）

Intergranular corrosion behavior of 2219 aluminum alloy's welding join

  • 1.

    Research Center of Sichuan Advanced Welding and Surface Engineering, Southwest Jiaotong University, Chengdu 610031, China;School of Life Science and Engineering, Southwest Jiaotong University, Chengdu 610031, China

  • 2.

    Capital Spaceflight Machinery Company, Beijing, 100076, China

  • 3.

    School of Life Science and Engineering, Southwest Jiaotong University, Chengdu 610031, China

  • 4.

    Research Center of Sichuan Advanced Welding and Surface Engineering, Southwest Jiaotong University, Chengdu 610031, China

摘要

    摘要
  • 摘要: 采用晶间腐蚀试验及极化曲线测试方法对2219铝合金母材、搅拌摩擦焊（FSW）及钨极氩弧焊（TIG）接头的腐蚀行为进行分析，借助金相显微镜、激光共聚焦显微镜、体视显微镜、扫描电镜及能谱仪分析腐蚀形貌及腐蚀产物.结果表明，2219铝合金母材及焊接接头的腐蚀行为主要与析出相有关，Al2Cu的析出导致贫铜的无沉淀带作为阳极优先溶解.母材的抗晶间腐蚀能力最差，由表面点蚀开始，沿轧制方向逐渐发展为剥落腐蚀；TIG焊次之，表现为网状晶间腐蚀；FSW焊最低，焊核表现为点蚀，散落分布于表面.
    Abstract: The corrosion behavior of 2219 aluminum alloy and its welding joints (made by FSW and TIG welding) were investigated through intergranular corrosion test and polarization curve measurement. Metalloscope, laser scanning confocal microscope and scanning electron microscopy were employed to analyze the corrosion morphology, and corrosion products were measured by energy spectrometer. The results show that the corrosion behavior of 2219 aluminum alloy and its welding joints are related to precipitated phase, and the precipitation of Al2Cu phase leads to the dissolution of poor Cu zone as the anode. The base metal shows the worst corrosion resistance ability, whose pitting corrosion develops to exfoliation corrosion along the rolling direction in corrosion media (NaCl+H2O2). The corrosion resistance of FSW joint is superior to that of TIG joint. TIG joint shows intergranular corrosion with network cracks, and FSW joint shows corrosion pits distributing scatteringly on the surface.
    • HTML全文
    • 参考文献(11)
  • [1] Mendez P F, Eagar T W. Welding processes for aeronautics[J]. Advanced Materials Process, 2001, 159(5): 39-42.
    [2] 贺地求, 邓 航, 周鹏展. 2219厚板搅拌摩擦焊组织及性能分析[J]. 焊接学报, 2007, 28(9): 14-16. He Diqiu, Deng Hang, Zhou Pengzhan. Analysis of microstructure and properties in friction-stir welding of 2219 thick plate[J]. Transactions of the China Welding Institution, 2007, 28(9): 13-16.
    [3] Bousquet E, Poulon-Quintin N, Puiggali M, et al. Relationship between microstructure, microhardness and corrosion sensitivity of an AA 2024-T3 friction stir welded joint[J]. Corrosion Science, 2011, 53(9): 3026-3034.
    [4] Srinivasan P B, Arora K S, Dietzel W, et al. Characterisation of microstructure, mechanical properties and corrosion behaviour of an AA2219 friction stir welding[J]. Journal of Alloy and Compounds, 2010, 492(1-2): 631-637.
    [5] 张 华, 孙大同, 张 贺, 等. 2219铝合金搅拌摩擦焊接头腐蚀行为[J]. 焊接学报, 2014, 35(7): 39-42. Zhang Hua, Sun Datong, Zhang He, et al.Corrosion behavior of friction stir welded 2219 aluminumalloy[J]. Transactions of the China Welding Institution, 2014, 35(7): 39-42.
    [6] Mahmoud T S. Effect of friction stir processing on electrical conductivity and corrosion resistance of AA6063-T6 Al alloy[J]. Journal of Mechanical Engeering Science, 2008, 222(7): 1117-1123.
    [7] Wei F X, Jin H L. Microstructure and pitting corrosion of friction stir welded joints in 2219-O aluminum alloy thick plate[J]. Corrosion Science, 2009, 51(11): 2743-2751.
    [8] Rossana G, Mark A B, James E Castle, et al. Localized corrosion of a 2219 aluminium alloy exposed to a 3.5% NaCl solution[J]. Corrosion Science, 2010, 52(9): 2855-2866.
    [9] Paglia C S, Buchheit R G. Microstructure, microchemistry and environmental cracking susceptibility of frictrion stir welded 2219-T87[J]. Materials Science and Engineering A, 2006, 429(1-2): 107-114.
    [10] 何 跃, 郑玉贵, 国旭明. 高强Al-Cu合金2219及其熔敷金属的点蚀行为[J]. 腐蚀科学与防护技术, 2005, 17(6): 387-390. He Yue, Zheng Yugui, Guo Xuming. Pitting corrosion of high strength Al-Cu alloy 2219 and its overlayers[J]. Corrosion Science and Protection Technology, 2005,17(6): 387-390.
    [11] 李劲风, 郑子樵, 任文达. 第二相在铝合金局部腐蚀中的作用机制[J]. 材料导报, 2005, 19(2): 81-83. Li Jinfeng, Zheng Zhiqiao, Ren Wenda. Function mechanism of secondary phase on localized corrosion of Al alloy[J]. Materials Review, 2005, 19(2): 81-83.
