2A14铝合金激光-MIG复合填丝焊特性分析

常云峰,雷振,王旭友,滕彬

常云峰,雷振,王旭友,滕彬. 2A14铝合金激光-MIG复合填丝焊特性分析[J]. 焊接学报, 2017, 38(7): 40-44. DOI: 10.12073/j.hjxb.20161121004
引用本文: 常云峰,雷振,王旭友,滕彬. 2A14铝合金激光-MIG复合填丝焊特性分析[J]. 焊接学报, 2017, 38(7): 40-44. DOI: 10.12073/j.hjxb.20161121004
CHANG Yunfeng, LEI Zhen, WANG Xuyou, TENG Bin. Process of laser-MIG hybrid welding of 2A14 aluminum alloy with filler wire[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(7): 40-44. DOI: 10.12073/j.hjxb.20161121004
Citation: CHANG Yunfeng, LEI Zhen, WANG Xuyou, TENG Bin. Process of laser-MIG hybrid welding of 2A14 aluminum alloy with filler wire[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(7): 40-44. DOI: 10.12073/j.hjxb.20161121004

2A14铝合金激光-MIG复合填丝焊特性分析

Process of laser-MIG hybrid welding of 2A14 aluminum alloy with filler wire

  • 摘要: 针对2A14铝合金同时进行了激光-MIG复合焊和激光-MIG复合填丝焊试验,对比分析了激光功率、离焦量、焊接速度、焊接电流、光丝间距、填丝速度等工艺参数对两种焊接方法焊缝成形的影响规律.结果表明,铝合金激光-MIG复合填丝焊方法切实可行,工艺适应性良好,与铝合金激光-MIG复合焊相比,均能在较宽的工艺参数范围内实现良好的焊缝成形;相同试验参数条件下,铝合金激光-MIG复合填丝焊的焊缝成形特征与激光-MIG复合焊基本相同,但其熔敷速度明显大于激光-MIG复合焊,焊缝余高明显增加.
    Abstract: The effect of main parameters on the weld appearance of 2A14 aluminum alloy was investigated by using a laser-MIG hybrid welding process with filler wire, including the laser power, defocus distance, welding speed, welding current, laser-arc distance and wire filling speed. The results were also compared to those with conventional laser-MIG hybrid welding process. It was found that the laser-MIG hybrid welding process with filler wire was feasible and it could achieve good weld appearance in a wide range of process parameters. Compared to the conventional laser-MIG hybrid welding process, during this new welding process, the weld appearance was similar, but deposition rate and reinforcement were biqger than the laser-MIG hybrid welding, with the same parameters.
  • [1] 周万盛,姚君山.铝及其合金的焊接[M].北京: 机械工业出版社,2006.[2] 肖荣诗,陈 铠,左铁钏,等.高强铝合金激光焊接新进展[J].应用激光,2002,22(2): 206-208.Xiao Rongshi,Chen Kai,Zuo Tiechuan,etal.Laser welding recent development of high strength aluminum alloy[J].Applied Laser,2002,22(2): 206-208.[3] Bunaziv I,Akselsen O M,Salminen A,etal.Fiber laser-MIG hybrid welding of 5mm 5083 aluminum alloy[J].Journal of Materials Processing Technology,2016,233: 107-114.[4] 吴圣川,朱宗涛.铝合金的激光焊接及性能评价[M].北京: 国防工业出版社,2014.[5] Xu Lianghong,Tian Zhiling,Peng Yun,etal.Microstructure and mechanical properties of high strength aluminum alloy laser welds[J].Chinese Joumal of Lasers,2008,35(3): 456-461.[6] 丁 灏,马云霞,白培康,等.铝合金激光焊新技术[J].热加工工艺,2012,41(3): 111-113.Ding Hao,Ma Yunxia,Bai Peikang,etal.The new laser welding technology of aluminum alloy[J].Hot Working Technology,2012,41(3): 111-113.[7] 雷正龙,陈彦宾,李 颖,等.铝合金CO2激光-TIG电弧复合焊接试验研究[J].航天制造技术,2012,8(4): 35-37.Lei Zhenglong,Chen Yanbin,Li Ying,etal.CO2laser-TIG hybrid welding of aluminum alloy[J].Aerospace Manufacturing Technology,2012,8(4): 35-37.[8] 王 威,王旭友,秦国梁,等.铝合金激光-小功率脉冲MIG电弧复合热源焊接特性分析[J].焊接学报,2007,28(8): 37-40.Wang Wei,Wang Xuyou,Qin Guoliang,etal.Welding characteristics of laser-low power pulse MIG hybrid welding aluminum allou[J].Transactions of the China Welding Institution,2007,28(8): 37-40.[9] 王旭友,王 威,林尚扬.焊接参数对铝合金激光-MIG电弧复合焊缝熔深的影响[J].焊接学报,2008,29(6):13-16.Wang Xuyou,Wang Wei,Lin Shangyang.Effect of welding parameter on weld penetration in laser-MIG hybrid welding of aluminum alloy[J].Transactions of the China Welding Institution,2008,29(6): 13-16.[10] 王旭友,雷 振,张 健,等.高速列车6005A-T6铝合金型材激光-双丝MIG复合焊[J].焊接学报,2012,33(7):9-12.Wang Xuyou,Lei Zhen,Zhang Jian,etal.Laser-tandem MIG hybrid welding for 6005A-T6 aluminum alloy profile of high-speed train[J].Transactions of the China Welding Institution,2012,33(7): 9-12.
计量
  • 文章访问数:  350
  • HTML全文浏览量:  2
  • PDF下载量:  148
  • 被引次数: 0
出版历程
  • 收稿日期:  2016-11-20
