氟化物ATIG焊接Ti6Al4V的焊缝成形和组织
Weld shape and microstructure of Ti6Al4V alloy fluoride A-TIG weld
-
摘要: 试验选用MF型氟盐(LiF,NaF,KF)、MF2型氟盐(MgF2,CaF2,BaF2)和KN型钾盐(KF,KCl,KBr)对Ti6Al4V进行ATIG焊接，焊后研究了焊缝的成形、熔深和组织.结果表明,除MgF2焊道成形稍有曲折外，其它活性剂ATIG焊接接头均成形良好、无缺陷；氟化物能起到阻止熔池金属氧化的作用；KF和MF2型氟盐可显著减小焊缝熔宽；同阳离子的氟化物相比其氯化物和溴化物可显著增加Ti6Al4V焊缝熔深；MF型氟盐中KF活性剂获得的焊缝熔深最大，MF2型氟盐中MgF2活性剂获得的焊缝熔深最大，且熔深MgF2>KF；TIG和ATIG的焊缝组织均为粗大的柱状晶，活性剂ATIG焊可细化焊缝晶粒尺寸，但不会对焊缝的相结构组成造成影响.
-
关键词:
- ATIG焊 /
- Ti6Al4V钛合金 /
- 成形 /
- 熔深 /
- 组织
Abstract: Three types of compounds, i.e. MF type fluorides (including LiF, NaF, KF), MF2 type fluorides (including MgF2, CaF2, BaF2) and KN type potassium (including KF, KCl, KBr), were chosen as activated fluxes to evaluate the effect of weld shape, penetration and microstructure on the A-TIG Ti6Al4V alloy weld. The results show that good appearance and defect-free welded joints could be obtained with fluoride fluxes, except MgF2. Fluorides might act as antioxidants, which could keep weld bead from oxidation. In addition, bead width was significantly decreased in A-TIG with KF flux and MF2 type fluxes. Fluoride could effectively increase weld penetration than other halides (chloride and bromide) under the condition of same cationic. The KF fluoride in MF type had the greatest impact in increasing penetration, while MgF2 fluoride in MF2 type had the highest impact with larger penetration than that with KF fluoride. Furthermore, the solidification microstructure consisted of coarse and columnar grains throughout the complete fusion zone in both TIG and A-TIG welds. And the grains exhibited obvious refining effect in A-TIG weld, but it did not change the phase structure of weld bead.-
Keywords:
- A-TIG /
- Ti6Al4V alloy /
- weld shape /
- penetration /
- microstructure
-
-
[1] 高福样，廖志谦，熊进辉，等.船用钛合金焊接接头精细组织表征[J].焊接学报，2016，37(4)：124-128.Gao fuyang，Liao Zhiqian，Xiong Jinhui，etal.Microstructure of TIG welded Joint of marine titanium alloy[J].Transactions of the China Welding Institution，2016，37(4)：124-128.[2] Niagaj J.The use of activating fluxes for the welding of high-alloy steels by A-TIG method[J].Welding International，2003，17：257-261.[3] Nayee S G，Badheka V J.Effect of oxide-based fluxes on mechanical and metallurgical properties of dissimilar activating flux assisted-tungsten inert gas welds[J].Journal of Manufacturing Processes，2014，16：137-143.[4] Li D，Lu S，Li D，etal.Principles giving high penetration under the double shielded TIG process[J].Journal of Materials Science & Technology，2014，30(2)：172-178.[5] Tanaka M，Shimizu T，Terasaki T，etal.Effects of activating flux on arc phenomena in gas tungsten arc welding[J].Science and Technology of Welding and Joining，2000，5(6)：397-402.[6] 黄 勇，樊 丁，张 涵.表面活性剂对钛合金A-TIG焊熔深的影响[J].稀有金属材料与工程，2006，35(10)：1586-1588.Huang Yong，Fan Ding，Zhang Han.Effect of surface activating flux on weld penetration of A-TIG welding for titanium alloy[J].Rare Metal Materials and Engineering，2006，35(10)：1586-1588.[7] 刘凤尧，林三宝，杨春利，等.TIG焊活性剂对焊缝成形的影响[J].焊接学报，2002，23(1)：1-4.Liu Fengyao，Lin Sanbao，Yang Chunli，etal.Effect of activating fluxes on weld form in TIG welding of Stainless Steel an titanium alloy[J].Transactions of the China Welding Institution，2002，23(1)：1-4.[8] 黄 勇，樊 丁，樊清华，等.表面活性剂对铝合金直流正接A-TIG焊熔深的影响[J].焊接学报，2004，25(5)：60-66.Huang Yong，Fan Ding，Fan Qinghua.Effect of surface activating flux on welding penetration of A-TIG welding with DCSP mode of aluminum alloy[J].Transactions of the China Welding Institution，2004，25(5)：60-66.[9] Bang K S，Chirieleison G，Liu S.GTAW of titanium flux-cored wire with magnesium fluoride[J].Science and Technology of Welding & Joining，2005，10(5)：617-623.[10] 张兆栋，刘黎明，沈 勇，等.镁合金的活性电弧焊接[J].中国有色金属学报，2005，15(6)：912-916.Zhang Zhaodong，Liu Liming，Shen Yong，etal.Activating flux for arc welding of magnesium alloy[J].The Chinese Journal of Nonferrous Metals,2005，15(6)：912-916.
