搅拌摩擦加工制备镁基铝覆层材料的组织与性能

赵亚东, 丁志敏, 沈长斌, 陈影

赵亚东, 丁志敏, 沈长斌, 陈影. 搅拌摩擦加工制备镁基铝覆层材料的组织与性能[J]. 焊接学报, 2017, 38(1): 82-86.
引用本文: 赵亚东, 丁志敏, 沈长斌, 陈影. 搅拌摩擦加工制备镁基铝覆层材料的组织与性能[J]. 焊接学报, 2017, 38(1): 82-86.
ZHAO Yadong, DING Zhimin, SHEN Changbin, CHEN Ying. Microstructure and properties of surface aluminizing on magnesium by friction stir processing[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 82-86.
Citation: ZHAO Yadong, DING Zhimin, SHEN Changbin, CHEN Ying. Microstructure and properties of surface aluminizing on magnesium by friction stir processing[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 82-86.

搅拌摩擦加工制备镁基铝覆层材料的组织与性能

基金项目: 教育部高等学校博士学科点专项科研基金(20132124120003);辽宁省教育厅科学研究一般项目(L2014185)

Microstructure and properties of surface aluminizing on magnesium by friction stir processing

  • 摘要: 在采用多道次搅拌摩擦加工成功地在镁合金表面覆合一层铝层的基础上,利用光学显微镜、透射电子显微镜、扫描电子显微镜、能谱分析和电子万能材料试验机对界面组织、元素成分分布、界面结合力和断口形貌进行了分析,并分析了不同焊接速度对重叠区界面组织和性能的影响规律.结果表明,界面由N道次区、重叠区和N+1道次区组成,重叠区界面过渡层的厚度随着焊接速度的降低而增加.其过渡层由Al+Al3Mg2相和Mg+Al12Mg17相组成.重叠区界面的剪切力随着速度的降低而增加,断裂方式为塑性断裂.
    Abstract: Surface aluminizing on magnesium was successfully farbricated by multi-pass friction stir processing (MP-FSP). The interface microstructure, mechanical properties, fractured surface and components were investigated by using optical microscopy (OM), electron probe microanalysis (EPMA), transmission electron microscopy (TEM), scanning electron microscopy (SEM), energy disperse spectroscopy (EDS) and electromechanical testing machine. In addition, the effect of different welding speed on the overlapping area (OA) interface microstructre and properites were also analyzed. The results showed that the interfacial macrostructure was consisted of N pass, OA and N+1 pass. A conversion zone containing Al+Al3Mg2 and Mg+Al12Mg17 was formed in the interfacial macrostructure. The thickness of OA conversion zone was increased with the welding speed decreased. Shear tensile test results showed that the shear force of the OA interface was increased with the welding speed decreased. The fracture mode was plastic fracture.
  • [1] 沈长斌, 杨野, 陈影. AZ31镁合金搅拌摩擦焊焊缝电化学性能的分析[J]. 焊接学报, 2014, 35(9):101-104. Shen Changbin, Yang Ye, Chen Ying. Analysis of electrochemical property of AZ31 magnesium alloy friction stir weld[J]. Transactions of the China Welding Institution, 2014, 35(9):101-104.
    [2] Paital S R., Bhattacharya A, Moncayo M, et al. Improved corrosion and wear resistance of Mg alloys via laser modification of Al on AZ31B[J]. Surface and Coatings Technology, 2012, 206(8):2308-2315.
    [3] Wu K, Chang H,Maawad E, et al. Microstructure and mechanical properties of the Mg/Al laminated composite fabricated by accumulative roll bonding(ARB)[J]. Materials Science and Engineering A, 2010, 527(13):3073-3078.
    [4] Yan Y B, Zhang Z W, Shen W, et al. Microstructure and properties of magnesium AZ31B-aluminum 7075 explosively welded composite plate[J]. Materials Science and Engineering A, 2010, 527(9):2241-2245.
    [5] Wu Y, Feng B, Xin Y C, et al. Microstructure and mechanical behavior of a MgAZ31/Al 7050 laminate composite fabricated by extrusion[J]. Materials Science and Engineering A, 2015, 640:454-459.
    [6] 黄永宪, 王天昊, 吕世雄, 等. 镁合金表面搅拌摩擦原位复合材料化的新方法[J]. 焊接学报, 2013, 34(12):25-28. Huang Yongxian, Wang Tianhao, Lv Shixiong, et al. A novel method of in-situ fabrication of Mg surface composites by friction stir process[J]. Transactions of the China Welding Institution, 2013, 34(12):25-28.
    [7] Zhang D T,Xiong F, Zhang W W, et al. Superplasticity of AZ31 magnesium alloy prepared by friction stir processing[J]. Transactions of Nonferrous Metals Society of China, 2011, 21(9):1911-1916.
    [8] Parviz A, Ghader F, Mohammad K B. Producing of AZ91/SiC composite by frictionstir processing (FSP)[J]. International Journal of Advanced Manufacturing Technology, 2010, 51(1):247-260.
    [9] Zhao Y D, Ding Z M, Shen C B, et al. Interfacial microstructure and properties of aluminum-magnesium AZ31B multi-pass friction stir processed composite plate[J]. Materials and Design, 2016, 94:240-252.
    [10] 郭立杰, 封小松, 苗玉刚, 等. 旋转频率对镁/铝异种金属填充式摩擦点焊接头组织及力学性能的影响[J]. 焊接学报, 2013, 34(11):9-12. Guo Lijie, Feng Xiaosong, Miao Yugang, et al. Effect of rotation frequency on microstructure and mechanical properties of refill friction spot welded Mg/Al dissimilar metals[J]. Transactions of the China Welding Institution, 2013, 34(11):9-12.
    [11] Sato Y S, Park S H C, Michiuchi M, et al. Constitutional liquation during dissimilar friction stir welding of Al and Mg alloys[J]. Scripta Materialia, 2004, 50(9):1233-1236.
计量
  • 文章访问数:  555
  • HTML全文浏览量:  1
  • PDF下载量:  526
  • 被引次数: 0
出版历程
  • 收稿日期:  2016-06-22
