焊接电流和药皮厚度对水下湿法焊接熔渣物相及微观组织的影响

李海新, 张琳琳, 杨振林, 殷子强

李海新, 张琳琳, 杨振林, 殷子强. 焊接电流和药皮厚度对水下湿法焊接熔渣物相及微观组织的影响[J]. 焊接学报, 2017, 38(1): 77-81.
引用本文: 李海新, 张琳琳, 杨振林, 殷子强. 焊接电流和药皮厚度对水下湿法焊接熔渣物相及微观组织的影响[J]. 焊接学报, 2017, 38(1): 77-81.
LI Haixin, ZHANG Linlin, YANG Zhenlin, YIN Ziqiang. Effect of welding current and thickness of electrode coating on phase and microstructure of slag during underwater wet welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 77-81.
Citation: LI Haixin, ZHANG Linlin, YANG Zhenlin, YIN Ziqiang. Effect of welding current and thickness of electrode coating on phase and microstructure of slag during underwater wet welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2017, 38(1): 77-81.

焊接电流和药皮厚度对水下湿法焊接熔渣物相及微观组织的影响

基金项目: 国家自然科学基金资助项目(51305245,51505267);山东省自然科学基金资助项目(ZR2014EEP016);山东省科学院青年基金资助项目(2013QN043);青岛市应用基础研究计划资助项目(15-9-1-53-JCH);青岛市市南区科技发展资金资助项目(2015-6-029-ZH)

Effect of welding current and thickness of electrode coating on phase and microstructure of slag during underwater wet welding

  • 摘要: 文中采用自制的金红石型药皮焊条进行水下湿法焊接,重点分析了焊接电流和药皮厚度对熔渣物相及微观组织的影响.对熔渣的宏观形貌分析发现,当药皮厚度较薄时,焊后熔渣稀薄,覆盖不均匀,此外,焊接电流对焊接飞溅有重要影响,当焊接电流较大时,焊接过程中有大量飞溅产生.通过对熔渣的碱度系数及物相分析得出,熔渣的主要组成相为FeTiO3和CaTiO3,还有少量的MnTiO3,FeF3和Ca-Si-O相,药皮厚度和焊接电流对熔渣的碱度系数和组成相影响均较小.熔渣的微观组织分析发现,减小药皮厚度和增大焊接电流,熔渣中生成大量的树枝状组织,熔渣微观组织的方向性增强,有利于脱渣.
    Abstract: In this article, the autonomousrutile type carbon steel electrode was used for underwater wet welding. It focused on the effect of the welding current and thickness of electrode coating on phase and microstructure of slag during underwater wet welding. By macro-morphology analysis, it found that when the thickness of electrode coating was thin, the slag was thin and uneven coverage. Furthermore, welding current had an important effect on welding spatter. When the welding current was large, there was a large amount of splashing in the welding process. By the analysis of basicity coefficient and phase of slag, there was a little effect of thickness of electrode coating and welding current on the basicity coefficient of slag. The main composed phase of slag was FeTiO3 and CaTiO3, also contained a small amount of MnTiO3, FeF3 and Ca-Si-O phase. By the microstructure analysis of slag, with the decreasing of the electrode coating and increasing of the welding current, there was a large amount of dendritic structure was formed, the direction of the microstructure of slag was enhanced, which was advantageous to the detachability of slag.
  • [1] 何银水. 水下焊接焊缝的识别与跟踪[D]. 江西:南昌大学, 2006.
    [2] 孙咸.不锈钢焊条焊接熔渣及与焊条工艺质量的关系[J]. 焊接, 2008(10):5-10. Sun Xian. Correlation between welding slag and usability quality of stainless steel electrode[J]. Welding&Joining, 2008(10):5-10.
    [3] Mitra U, Eagar T W. Slag-metal reactions during welding:Part Ⅰ. Evaluation and reassessment of existing theories[J]. Metallurgical Transantions B, 1991, 22B:65-71.
    [4] Mitra U, Eagar T W. Slag-metal reactions during welding:Part Ⅱ. Theory[J]. Metallurgical Transantions B, 1991, 22B:73-81.
    [5] Mitra U, Eagar T W. Slag-metal reactions during welding:Part Ⅲ. Verification of the theory[J]. Metallurgical Transantions B, 1991, 22B:83-100.
    [6] Coley K S. Progress in the kinetics of slag-metal-gas-reactions, past, present and future[J]. Journal of Mining and Metallurgy B:Metallurgy, 2013, 49(2):191-199.
    [7] 李晓泉, 杨旭光, 方臣富. 活性SiO2在焊接熔渣-金属界面化学反应的热动力学分析[J]. 焊接学报, 2005, 26(10):43-46. Li Xiaoquan, Yang Xuguang, Fang Chenfu. The chemical reaction of thermal dynamics analysis of activated SiO2 on the welding slag-metal interface[J]. Transactions of the China Welding Institution, 2005, 26(10):43-46.
    [8] 李平, 孟工戈. TiO2对不锈钢焊条脱渣性的影响[J]. 焊接学报, 2006, 27(4):69-72. Li Ping, Meng Gongge. Effect of TiO2 on detachability of stainless steel electrode[J]. Transactions of the China Welding Institution, 2006, 27(4):69-72.
    [9] 孟庆森, 王宝. 熔渣的微观组织结构对焊条脱渣的影响[J]. 焊接学报, 1993, 14(3):202-206. Meng Qingsen, Wang Bao. Influence of microstructural appearanc-es of slag on detachability of electrode[J]. Transactions of the China Welding Institution, 2006, 27(4):69-72.
    [10] Wang H, Qin R Y, He G. SiO2 and CaF2 behavior during shielded metal arc welding and their effect on slag detachability of the CaO-CaF2-SiO2 type ENiCrFe-7-covered electrode[J]. Metallurgi-cal and Materials Transactions A, 2016, 47(9):4530-4542.
    [11] Agnieszka B, Patrick J M. High temperature diffusion processes at the metal/slag interface[J]. Defect and Diffusion Forum, 2012, 323/325:115-120.
    [12] 张凯. 焊接熔渣微观结构及对焊条工艺性能的影响[D]. 济南:山东建筑大学, 2011.
