温度对焊接热模拟X80管线钢断裂韧性的影响
Effect of temperature on fracture toughness in weld thermal simulated X80 pipeline steels
-
摘要: 通过试验和3D有限元模拟相结合的方法分析了焊接热模拟X80管线钢在不同温度（-90，-60，-30和0℃）下的断裂韧度.文中选取标准三点弯曲试样在不同温度下进行断裂韧度测试，同时对测试件进行三维有限元实体建模与分析计算.结果表明，X80管线钢的断裂韧性随温度减低显著减小，并使其倾向于脆性断裂.材料在不同温度下的真实应力-应变曲线行为从光滑拉伸到断裂力学试样具有良好的可传递性，温度对材料的硬化行为没有明显影响，有限元计算的结果表明，应用该方法可以准确地计算X80钢焊接热影响区不同温度下的CTOD值.Abstract: The aim of this paper is to study the effect of temperature on cleavage fracture toughness of weld thermal simulated X80 pipeline steels in ductile-to-brittle transition (DBT) regime. A large number of fracture toughness (as denoted by crack tip opening displacement-CTOD) tests together with finite element analyses are carried out by using deep-cracked single edge notched bending (SENB with a/W=0.5) specimens at various temperatures (-90℃, -60℃, -30℃ and 0℃). 3D finite element models of tested specimens have been used for the numerical simulation in this study. Coarse-grained heat-affected zone (CGHAZ) is considered as the material microstructure in preparation of weld thermal simulated fracture mechanics specimens. It has been found that the transferability of the true stress-strain curves obtained from weld thermal simulated round tensile bar to the fracture mechanics specimens works very well. Temperature shows only a slight effect on the material hardening behavior. As compared with experimental results, the 3D model can precisely predict the fracture toughness (CTOD-values) at different temperatures considered in this study.
-
-
[1] 肖光春, 荆洪阳, 徐连勇, 等. 预应变下高强结构钢低温断裂性能[J]. 焊接学报, 2011, 32(3):41-44. Xiao Guangchun, Jing Hongyang, Xu Lianyong, et al. Research on fracture toughness of high-strength structural steel with prestrain at low temperature[J]. Transactions of the China Welding Institution, 2011, 32(3):41-44. [2] 肖晓华, 卢东华, 王丰, 等. X80钢低温焊接接头组织与性能研究[J]. 热加工工艺, 2014, 43(13):169-172. Xiao Xiaohua, Lu Donghua, Wang Feng, et al. Study of microstructure and properties of welded joint of X80 steel at low temperature[J]. Hot Working Technology, 2014, 43(13):169-172. [3] 陈延清, 杜则裕, 许良红. X80管线钢焊接热影响区组织和性能分析[J]. 焊接学报, 2010, 31(5):101-104. Chen Yanqing, Du Zeyu, Xu Lianghong. Microstructure and mechanical properties of heat affected zone for X80 pipeline steel[J]. Transactions of the China Welding Institution, 2010, 31(5):101-104. [4] 李青霞, 徐学利. X80管线钢粗晶区的模拟研究[J]. 内蒙古石油化工. 2008, 34(16):76-78. Li Qingxia, Xu Xueli. Research of welding coarse grain heat-affected zone of X80 pipeline steel[J]. Inner Mongolia Petrochemical, 2008, 34(16):76-78. [5] Sturel T, Fant M D, Carius H, et al. Coupling of metallurgical and mechanical models to predict the toughness properties of multipass welded joints[R]. Norway:the International Symposium on Safety in Application of High Strength Steel, 1997. [6] BSI. Part 1:1991, Fracture mechanics toughness tests. Part 1:Method for determination of KIc, critical CTOD and critical J values of metallic materials. BS 7448[S]. London:BSI Publication, 1991.
