低温管线K65热煨弯管用埋弧焊丝研制

董利明, 杨莉, 戴军, 潘鑫, 张宇

董利明, 杨莉, 戴军, 潘鑫, 张宇. 低温管线K65热煨弯管用埋弧焊丝研制[J]. 焊接学报, 2016, 37(12): 120-124.
引用本文: 董利明, 杨莉, 戴军, 潘鑫, 张宇. 低温管线K65热煨弯管用埋弧焊丝研制[J]. 焊接学报, 2016, 37(12): 120-124.
shu
DONG Liming, YANG Li, DAI Jun, PAN Xin, ZHANG Yu. Development of submerged arc welding wire for fabrication of hot bend low-temperature pipeline steel K65 pipe[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 120-124.
Citation: DONG Liming, YANG Li, DAI Jun, PAN Xin, ZHANG Yu. Development of submerged arc welding wire for fabrication of hot bend low-temperature pipeline steel K65 pipe[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 120-124.
shu

低温管线K65热煨弯管用埋弧焊丝研制

  • 1.

    汽车工程学院, 常熟理工学院, 常熟 215500;江苏省(沙钢)钢铁研究院, 张家港 215625

  • 2.

    汽车工程学院, 常熟理工学院, 常熟 215500

  • 3.

    江苏省(沙钢)钢铁研究院, 张家港 215625

Development of submerged arc welding wire for fabrication of hot bend low-temperature pipeline steel K65 pipe

  • 1.

    College of Automotive Engineering, Changshu Institute of Technology, Changshu 215500, China;Iron & Steel Research Institute of Sha Steel of Jiangsu Province, Zhangjiagang 215625, China

  • 2.

    College of Automotive Engineering, Changshu Institute of Technology, Changshu 215500, China

  • 3.

    Iron & Steel Research Institute of Sha Steel of Jiangsu Province, Zhangjiagang 215625, China

摘要

    摘要
  • 摘要: 设计了NiMoTiB体系实芯焊丝用于低温管线K65热煨弯管的埋弧焊接，并采用φ4.0 mm焊丝、双面四丝埋弧焊开展了壁厚30.8 mm直缝管试制，然后利用热煨弯制工艺制成弯管，并分别测试了直缝管和弯管的焊缝金属微观组织及力学性能.结果表明，焊态直缝管焊缝组织以针状铁素体为主，以及少量贝氏体及马氏体-奥氏体岛（M-A）；焊缝金属抗拉强度670 MPa，-40℃冲击吸收功为162 J.经过淬火+回火处理的热煨弯管焊缝主要由块状铁素体和尺寸1~5 μm的退化珠光体组成；焊缝金属抗拉强度665 MPa，-40℃冲击吸收功84 J，能够满足低温管线钢K65的标准要求.
    Abstract: A NiMoTiB type solid wire was developed for submerged arc welding of hot bended K65 linepipe, and microstructure and mechanical property of the fabricated pipe with a wall thickness of 30.8 mm welded by two-sided four wire submerged arc welding were analyzed and tested. The results shows that the weld metal of as-welded pipe consists of acicular ferrite, a few bainite and M-A constituents, which has a tensile strength of 670 MPa and the impact absorbed energy is no less than 162 J at -40℃. Hot bending process changed the weld metal microstructure into a mix of blocky ferrite and pearlite, while possesses the tensile strength of 665 MPa and impact absorbed energy of no less than 84 J at -40℃.
    • HTML全文
    • 参考文献(11)
  • [1] 高惠临. 管道工程面临的挑战与管线钢的发展趋势[J]. 焊管, 2010, 33(10):5-18. Gao Huilin. The challenges for pipeline projects & development trend of pipeline steel[J]. Welded Pipe and Tube, 2010, 33(10):5-18.
    [2] Hillenbrand H G,Kalwa C, Schröder J, et al. Challenges to a pipe manufacturer driven by worldwide pipe projects[C]. The proceedings of the 18th Joint Technical Meeting on Pipeline Research, 2011, 13:1-12.
    [3] 严春妍, 李午申, 冯灵芝, 等. X100级管线钢及其焊接性[J]. 焊接学报, 2007, 28(10):105-108. Yan Chunyan, Li Wushen, Feng Lingzhi, et al. Review of X100 pipeline steel and its field weldability[J]. Transactions of the China Welding Institution, 2007, 28(10):105-108.
    [4] 张帅, 任毅, 王爽, 等. 热处理工艺对X80热煨弯管用钢组织性能的影响[J]. 钢铁, 2011, 46(5):81-84. Zhang Shuai, Ren Yi, Wang Shuang, et al. Effect of heat treatment parameters on performance and microstructure of X80 hot bended pipe steels[J]. Iron & Steel, 2011, 46(5):81-84.
    [5] Farber V M,Pyshmintsev I Y, Arabei A B, et al. Contributions of structural factors to the strength of k65 steels[J]. Steel in Translation, 2012, 42(9):687-690.
    [6] 张敏, 姚成武, 付狲. X80管线钢埋弧焊匹配焊丝研制[J]. 焊接学报, 2006, 27(4):64-68. Zhang Min, Yao Chengwu, Fu Sun. Development of welding welding wire for submerged arc welding of X80 pipeline steel[J]. Transactions of the China Welding Institution, 2006, 27(4):64-68.
    [7] 李冉, 魏金山, 彭云, 等. X80管线钢气体保护焊用焊丝的研制[J]. 焊接学报, 2007, 28(7):97-100. Li Ran, Wei Jinshan, Peng Yun, et al. Development of welding wire for gas shielded arc welding of X80 pipeline steel[J]. Transactions of the China Welding Institution, 2007, 28(7):97-100.
    [8] 杨炜炜, 赵晶, 焦斌, 等. K65钢级标准的分析和对比[J]. 焊管, 2013, 36(7):67-71. Yang Weiwei, Zhao Jing, Jiao Bin, et al. Analysis and comparision of the K65 steel grade standards[J]. Welded Pipe and Tube, 2013, 36(7):67-71.
    [9] Sindo Kou. Welding metallurgy (2nd edition)[M]. John Wiley & Sons, New Jersey, 2003.
    [10] Zhang Yu,Pan Xin, Guo Huiying. Effect of hot rolling practice on microstructure and mechanical properties of fire-resistant steel[J]. Journal of Iron and Steel Research, 2011, 18(s):590-594.
    [11] Hwang B, Kim Y G, Lee S, et al. Effective grain size and charpy impact properties of high-toughness X70 pipeline steels[J]. Metallurgical and Materials Transactions A, 2005, 36(8):2107-2114.
