高速列车框架焊接的双椭圆柱高斯分布热源模型

卫亮, 张乐乐, 王鹏

卫亮, 张乐乐, 王鹏. 高速列车框架焊接的双椭圆柱高斯分布热源模型[J]. 焊接学报, 2016, 37(12): 95-100.
引用本文: 卫亮, 张乐乐, 王鹏. 高速列车框架焊接的双椭圆柱高斯分布热源模型[J]. 焊接学报, 2016, 37(12): 95-100.
shu
WEI Liang, ZHANG Lele, WANG Peng. Numerical simulation on welding process of high-speed train's frame structure based on double elliptical cylinder Gaussian distribution heat source model[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 95-100.
Citation: WEI Liang, ZHANG Lele, WANG Peng. Numerical simulation on welding process of high-speed train's frame structure based on double elliptical cylinder Gaussian distribution heat source model[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 95-100.
shu

高速列车框架焊接的双椭圆柱高斯分布热源模型

  • 1.

    北京交通大学 机械与电子控制工程学院, 北京 100044

  • 2.

    北京交通大学 机械与电子控制工程学院, 北京 100044;中国铁道科学研究院 铁道建筑研究所, 北京 100081

基金项目: 国家自然科学基金面上项目（51475036）；中央高校基本科研业务费重点项目（2012JBZ004）

Numerical simulation on welding process of high-speed train's frame structure based on double elliptical cylinder Gaussian distribution heat source model

  • 1.

    School of Mechanical, Electronic and Control Engineering, Beijing Jiaotong University, Beijing 100044, China

  • 2.

    School of Mechanical, Electronic and Control Engineering, Beijing Jiaotong University, Beijing 100044, China;Railway Engineering Research Institute, Academy of Railway Sciences, Beijing 100081, China

摘要

    摘要
  • 摘要: 根据高速列车车体结构焊接工艺特点，分析并改进常用高斯热源，提出适用于铝合金惰性气体保护焊接（MIG）的双椭圆柱-高斯分布热源模型.该热源模型基于焊接速度移动，形成的熔池表面为双椭圆形状，热流密度沿厚度方向均匀分布，在径向呈高斯-双椭圆分布.基于热源模型的数学表达，以有限元方法实现了热机耦合的焊接过程仿真，与薄板试验结果比较，温度场分布与降低趋势较好地吻合；拉应力峰值出现在熔合线和热影响区，仿真值、试验值分别为88.8，85 MPa.结果表明，该热源模型有效地模拟焊接温度场时域上的变化过程，准确地预测结构变形、残余应力分布规律，应用于高速列车头车框架结构焊接工艺优化及残余应力评估，为高速列车焊接质量控制及焊接工艺参数选择提供理论指导.
    Abstract: According to the metal inert-gas (MIG) welding characteristics of the typical structure of high-speed train,the double elliptical cylinder Gaussian distribution heat source model was proposed, which is suitable for welding of the aluminum alloy sheet. The heat source model based on the shape of weld pool was double elliptical, and the distribution of heat flux was uniform and Gaussian in the thickness and radial,respectively. The welding process was simulated through thermo-mechanical coupling method by finite element method. A comparison between simulation and experimental distribution of the temperature field shows the tendency of evolutionary processes compatibly. The peak value of stress by simulation and experiment are 88.8 MPa and 85 MPa,respectively. The results show that the heat source model can simulate both the temperature and the stress field during the welding process. This method is using to predict welding residual stress and strain for the high-speed train's frame structure and can help to choose appropriate MIG welding parameters of aluminum alloy in the industry.
    • HTML全文
    • 参考文献(12)
  • [1] 王炎金. 铝合金车体焊接工艺[M]. 北京:机械工业出版社, 2011.
    [2] Fanous I F Z, Younan M Y A, Wifi A S. Introduction of the element interaction technique for welding analysis and simulation[J]. Journal of Pressure Vessel Technology, 2005, 127(4):487-494.
    [3] 上田幸雄, 村川英一, 麻宁绪. 焊接变形和残余应力的数值计算方法与程序[M]. 成都四川大学出版社, 2008.
    [4] 王宗茂, 王建平, 吴飞, 等. 6061铝合金焊接变形的数值分析[J]. 山东机械, 2004(6):36-38. Wang Zongmao, Wang Jianping, Wu Fe, et al. Numerical analysis on welding deformation of 6061 aluminum alloy[J]. Shandong Machinery, 2004(6):36-38.
    [5] 祝金丹, 陈虎, 巩建鸣, 等. 壳单元应用于薄板多道焊焊接数值模拟的方法探讨[J]. 焊接学报, 2008, 29(11):105-108. Zhu Jindan, Chen Hu, Gong Jianming, et al. Discussion on numerical simulation of mult pass welding of thin-plate based on shell element[J]. Transactions of the China Welding Institution, 2008, 29(11):105-108.
    [6] 鄢东洋, 史清宇, 吴爱萍, 等. 焊接数值模拟中以温度为控制变量的高效算法[J]. 焊接学报, 2009, 30(8):77-80. Yan Dongyang, Shi Qingyu, Wu Aiping, et al. A high-efficiency welding simulation method based on welding temperature[J]. Transactions of the China Welding Institution, 2009, 30(8):77-80..
    [7] 赵明, 武传松, 胡庆贤. TIG焊接熔透熔池形状和表面变形的数值模拟[J]. 机械工程学报, 2006, 42(10):203-214. Zhao Ming, Wu Chuansong, Hu Qingxian. Numerical simulation of penetrated weld pool geometry and surface deformation in TIG welding[J]. Chinese Journal of Mechanical Engineering, 2006, 42(10):203-214.
    [8] 莫春立, 钱百年, 国旭明, 等. 焊接热源计算模式的研究进展[J]. 焊接学报, 2001, 22(3):93-96. Mo Chunli, Qian Bainian, Guo Xuming, et al. The development of models about welding heat sources calculation[J]. Transactions of the China Welding Institution, 2001, 22(3):93-96.
    [9] 路登平, 李义丹, 司树恒, 等. 正态分布焊接热源集中系数的确定和研究[J]. 焊接学报, 1986, 7(1):47-54. Lu Dengping, Li Yidan, Si Shuheng, et al. The determination of normal distribution concentration factor for heat source of welding[J]. Transactions of the China Welding Institution, 1986, 7(1):47-54.
    [10] D. 达拉伊. 焊接热效应、温度场、残余应力、变形[M]. 北京:机械工业出版社, 1997, 07.
    [11] Abid M, Siddique M. Numerical simulation to study the effect of tack welds and root gap on welding deformations and residual stresses of a pipe-flange joint[J]. International Journal of Pressure Vessels and Piping, 82(2005):860-871.
    [12] 中国航空材料手册. 铝合金镁合金第3卷[M]. 第2版. 北京:中国标准出版社, 2002.
