锆元素对Zn-15Al钎料组织和性能的影响
Effect of zirconium on microstructure and properties of Zn-15Al filler metal
-
摘要: 通过扫描电镜、X射线衍射和纳米压痕等方法研究了微量Zr元素对铝合金/不锈钢异种金属钎焊用Zn-15Al钎料显微组织和性能的影响.结果表明，微量Zr元素的添加对钎料的熔点没有明显影响.Zr元素对Zn-15Al钎料基体中η-Zn相有明显细化作用，当Zr元素的质量分数为0.2%时，细化效果最佳；Zr元素的添加量过多时，钎料中形成块状的Al2ZnZr化合物.当Zr元素的质量分数为0.2%时，Zn-15Al-0.2Zr钎料在不锈钢和铝合金母材上的铺展面积较Zn-15Al钎料分别提高了15.9%和10.2%，钎焊接头抗剪强度达到最大值143 MPa.Zn-15Al，Zn-15Al-0.2Zr，Zn-15Al-0.3Zr 3种钎料的蠕变应力指数分别为6.64，7.35，8.07.Abstract: The microstructure and properties of Zn-15Al filler metal used for brazingof aluminum/stainless steel were investigated by means of scanning electron microscope, X-ray diffraction and nanoindentation. The results indicate that Zr addition hasfew influences on the melting point of the Zn-15Al filler metal. Moreover, the addition ofthe appropriate amount of Zr appears to refine the η-Zn dendrites in the filler metal. However, the excessive amount of Zr leads to the formation of Al2ZnZr compounds. The spreadability of the Zn-15Al-xZr filler metal is improved especially at the Zrcontent of 0.2 wt.%, which the spreading areason stainless steel and aluminum alloy are increased by 15.9% and 10.2%, respectively. The shear strength of the Zn-15Al-0.2Zr brazed joint achieves the peak value of 143 MPa. The creep stress exponents of Zn-15Al, Zn-15Al-0.2Zr and Zn-15Al-0.3Zr are 6.64, 7.35 and 8.07, respectively.
-
Keywords:
- zirconium /
- Zn-Al filler metal /
- microstructure /
- spreading ability
-
-
[1] 陈舟苗, 何国平, 章小剑. 一种换热器的铜铝接头结构:中国, 201220682721.1[P]. 2013-06-12. [2] 葛佳棋, 蒋勇, 王克鸿. 包覆钎料铝-钢螺柱焊接头组织及性能[J]. 焊接学报, 2012, 33(7):97-100. Ge Jiaqi, Jiang Yong, Wang Kehong. Microstructure characteristics and properties of steel to aluminum alloy made by covering filler metal brazing[J]. Transactions of the China Welding Institution, 2012, 33(7):97-100. [3] 杨金龙, 薛松柏, 薛鹏, 等. 铝/钢异种金属火焰钎焊接头组织和性能[J]. 焊接学报, 2015, 36(1):63-65. Yang Jinlong, Xue Songbai, Xue Peng, et al. Microstructure and mechanical properties of aluminum/stainless steel brazed joint with torch brazing[J]. Transactions of the China Welding Institution, 2015, 36(1):63-65. [4] Xu Zhiwu, Yan Jiuchun, Wang Cheng, et al. Substrate oxide undermining by a Zn-Al alloy during wetting of alumina reinforced 6061 Al matrix composite[J]. Materials Chemistry and Physics, 2008, 112(3):831-837. [5] Ji Feng, Xue Songbai. Growth behaviors of intermetallic compound layers in Cu/Al joints brazed with Zn-22Al and Zn-22Al-0.05 Ce filler metals[J]. Materials & Design, 2013, 51:907-915. [6] 刘洋. 锌铝合金的组织性能优化及相关基础研究[D]. 长沙:中南大学, 2013. [7] 刘生发, 黄尚宇, 徐萍. Ce对AZ91镁合金铸态组织细化的影响[J]. 金属学报, 2006, 42(4):443-448. Liu Shengfa, Huang shangyu, Xu Ping. Microstructure refinement of AZ91 magnesium alloy[J]. Acta Metallurgica Sinica, 2006, 42(4):443-448. [8] 姬峰, 薛松柏, 刘霜, 等, 纳米压痕法测量锌铝钎料的室温蠕变应力指数[J]. 焊接学报, 2013, 34(2):75-78. Ji Feng, Xue Songbai, Liu Shuang, et al. Measurement of creep exponent of Zn-Al filler metal at room temperature by using nanoindentation[J]. Transactions of the China Welding Institution, 2013, 34(2):75-78. -
