DP600/AZ31无匙孔搅拌摩擦点焊塑性金属流动特性及断裂行为研究

王希靖, 许有伟, 张亮亮, 魏万奎

王希靖, 许有伟, 张亮亮, 魏万奎. DP600/AZ31无匙孔搅拌摩擦点焊塑性金属流动特性及断裂行为研究[J]. 焊接学报, 2016, 37(12): 57-60,70.
引用本文: 王希靖, 许有伟, 张亮亮, 魏万奎. DP600/AZ31无匙孔搅拌摩擦点焊塑性金属流动特性及断裂行为研究[J]. 焊接学报, 2016, 37(12): 57-60,70.
shu
WANG Xijing, XU Youwei, ZHANG Liangliang, WEI Wankui. Plastic metal flow characteristic and fracture behaviors of DP600/AZ31 with non-keyhole friction stir spot welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 57-60,70.
Citation: WANG Xijing, XU Youwei, ZHANG Liangliang, WEI Wankui. Plastic metal flow characteristic and fracture behaviors of DP600/AZ31 with non-keyhole friction stir spot welding[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(12): 57-60,70.
shu

DP600/AZ31无匙孔搅拌摩擦点焊塑性金属流动特性及断裂行为研究

  • 兰州理工大学 有色金属先进加工与再利用省部共建国家重点实验室, 兰州 730050

基金项目: 国家自然科学基金资助项目（51265030）

Plastic metal flow characteristic and fracture behaviors of DP600/AZ31 with non-keyhole friction stir spot welding

  • State Key Laboratory of Gansu Advanced Nonferrous Metal Materials, Lanzhou University of Technology, Lanzhou 730050, China

摘要

    摘要
  • 摘要: 在最优焊接参数下，对1 mm DP600镀锌钢板和3 mm AZ31镁板进行无匙孔搅拌摩擦点焊试验，焊后对接头分别进行横切、纵切及层切，采用扫描电镜（SEM）分析焊接接头显微组织和断口形貌.结果表明，镁钢间的混合主要发生在搅拌针作用区域，形成“机械互锁”的组织形貌，有利于增加两种材料的有效接触，形成复相强化；轴肩作用区镁钢间搅拌不明显，界面较平滑，镁钢界面形成了金属化合物以及氧化镁，降低了接头的塑性和韧性.对DP600/AZ31无匙孔搅拌摩擦点焊焊接接头进行拉伸试验，发现焊接接头从搭接界面上断裂，断口呈“脉状花样”，为延性断裂.
    Abstract: With the optimum welding parameters, 1mm DP600 galvanized steel plateand 3mm AZ31 magnesium plate were welded by non-keyhole friction stir spot welding and transverse, longitudinal and level cutting sample were prepared, respectively, then microstructure and fracture morphology of joint were analyzed with SEM. The results show that magnesium and steel are mixed mainly in the pin stirring zone, and the "mechanical interlock" microstructure forms to increase the effective contact of the two materials to form composite enhancement.The interface of magnesium and steel at shoulder active region is smooth. In shoulder active region, intermetallic compounds and oxide form, which reduces the ductility and toughness of joint? Tensile tests of joint show the joints break away from the lap interface and fracture is ductile fracture with "vein pattern".
    • HTML全文
    • 参考文献(10)
  • [1] 曾荣吕, 柯伟, 徐永波, 等. Mg合金的最新发展及应用前景. 金属学报, 2001, 37(7):672-685. Zeng Ronglv, Ke Wei, Xu Yongbo. Recent development and application of magnesium alloys[J]. Acta Metallurgica Sinica. 2001, 37(7):672-685.
    [2] 马明图. 先进汽车用钢[M]. 北京:化学工业出版社, 2007.
    [3] 王希靖, 赵钢, 张忠科, 等. 镁-钢异种金属无匙孔搅拌摩擦点焊工艺的研究[J]. 热加工工艺, 2012, (17):153-155. Wang Xijing, Zhao Gang, Zhang Zhongke, et al. Process research on friction stir spot welding without keyhole between magnesium and steel dissimilar alloys[J]. Hot Working Technology, 2012, 41(17):153-155.
    [4] 王希靖, 赵刚, 刘骁, 等. 一种轻质合金-钢无匙孔搅拌摩擦点焊焊接方法及装置中国, CN102319952A[P]. 2012-01-18.
    [5] 鄢东洋, 史清宇, 吴爱萍, 等. 搅拌摩擦焊接过程的试验测量及分析[J]. 焊接学报, 2010, 32(2):67-70. Yan Dongyang, Shi Qingyu, Wu Aiping, et al. Measurement andanalysis of friction stir welding[J]. Transactions of the China Welding Institution, 2010, 32(2):67-70.
    [6] Li Y, Murrl E, Clure J C M. Solid-state flow visualization in the fricition-stir welding of 2024 Al to 6061 Al. Scripta Materialia, 1999, 40(9):1041-1046.
    [7] 李继忠, 马正斌, 董春林. 异种铝合金搅拌摩擦焊材料流动行为研究[J]. 材料工程, 2014(6):1-4. Li Jizhong, Ma Zhengbin, Dong Chunlin. Material flowing behaviors of friction stir welsing by dissimilar aluminum alloys[J]. Journal of Materials Engineering, 2014(6):1-4.
    [8] Beygi R, Kazeminehad M, Kokabi A H. Microstructural evolution and fracture behavior of friction-stir-welded Al-Cu laminated composites[J]. The Minerals, Metals & Materials Society and ASM International, 2013, (45):361-370.
    [9] 杜岩峰, 白景彬, 田志杰, 等. 2219铝合金搅拌摩擦焊温度场的三维实体耦合数值模拟[J]. 焊接学报, 2014, 35(8):57-60. Du Yanfeng, Bai Jingbin, Tian Zhijie, et al. Investigation on three-dimensional real coupling numerical simulation of temperature field of friction stir welding of 2219 aluminum alloy[J]. Transactions of the China Welding Institution, 2014, 35(8):57-60.
    [10] 张洪武, 张照, 陈金涛, 等. 搅拌摩擦焊接过程的有限元模[J]. 焊接学报, 2005, 26(9):13-18. Zhang Hongwu, Zhang Zhao, Chen Jintao, et al. Finite element analysis of friction stir welding process[J]. Transactions of the China Welding Institution, 2005, 26(9):13-18.
