铝合金LB-VPPA复合热源焊焊缝成形机理
Mechanism of weld formation in laser beam-variable polarity plasma arc hybrid heating source welding of aluminum alloys
-
摘要: 以Al-Zn系铝合金LB-VPPA（激光-变极性等离子弧）复合焊接焊缝成形机理为研究对象，分析了LB与VPPA耦合效应对复合热源特性及其焊缝成形的影响规律.结果表明，LB与VPPA相互耦合不仅提高了激光吸收率，在变极性等离子弧根部形成一烁亮区，并且在VPPA反极性期间此效应更为显著.适当减小VPPA电流幅值，增加离子气流量，匹配合适的激光功率，可获得总热输入小，穿透力更强的热源，从而能够克服单VPPA平焊位置不易形成穿孔熔池的难点.8 mm厚Al-Zn系铝合金LB-VPPA复合热源焊在Iz=115 A、If=155 A、离子气流量q=3.0 L/min、激光功率P=1 000 W时可获得良好的焊缝成形.
-
关键词:
- LB-VPPA复合热源 /
- 铝合金 /
- 焊接 /
- 阴极清理
Abstract: By being taken weld formation mechanism as research object, and the influence of LB(Laser Beam) and VPPA(Variable Polarity Plasma Arc) coupling effects on heat source characteristics and weld formation mechanism were analyzed in LB-VPPA hybrid welding of Al-Zn aluminum alloys. The results show that laser absorptivity is increased by the coupling effects of LB and VPPA. A shining zone exists at the root of VPPA, especially during direct current electrode positive period. The heat source with the advantage of smaller heat input and higher penetration depth can be achieved by combining slightly smaller VPPA current, higher orifice gas flow rate and suitable laser power, which can overcome the difficulty of keyhole weld formation on flat position in VPPA welding. Better welded joints are achieved by LB-VPPA hybrid heating source welding on Al-Zn aluminum alloys with thickness of 8 mm at VPPA direct current electrode negative current of 115 A, VPPA direct current electrode positive current of 155 A, orifice gas flow rate of 3.0 L/min and laser power of 1 000 W.-
Key words:
- LB-VPPA hybrid heat source /
- aluminum alloys /
- welding /
- cathode cleaning
-
[1] Steen W M, Eboo M. Arc augmented laser welding[J]. Metal Construction, 1979, 11(6):332-333. [2] Walduck R P, Bimn J. Plasma arc augmented laser welding[J]. Welding Research Abroad, 1995, 41(11):2-4. [3] Page C J, Deve T, Bin J, et al. Plasma augmented laser welding and its applications[J]. Science and Technology of Welding and Joining, 2002, 7(1):1-10. [4] ClausB, lemming O O. Review of laser hybrid welding[J]. Journal of Laser Application, 2005, 17(1):2-14. [5] 姚伟, 巩水利, 陈俐. 激光/等离子电弧复合热源能量参数对钛合金焊缝成型的影响[J]. 焊接学报, 2006, 27(9):81-84. Yao Wei, Gong Shuili, Chen Li. Effect of energy parameters on weld shaping for hybrid laser/plasma welding of titanium alloy[J]. Transactions of the China Welding institution, 2006, 27(9):81-84. [6] Wang S C, Lefebvre F, Yan J L. VPPA welds of Al-2024 alloys:Analysis and modeling of local microstructure and strength[J]. Materials Science and Engineering, 2006, 24(5):123-136. [7] Wang H X, Wei Y H, Yang C L. Numerical simulation of variable polarity vertical-up plasma arc welding process[J]. Computational Materials Science, 2007, 38(4):571-587. [8] 韩永全, 洪海涛, 郭龙, 等. 交直流混合VPPA特性及铝合金立焊工艺[J]. 焊接学报, 2013, 34(9):59-62. Han Yongquan, Hong Haitao, Guo Long, et al.Vertical welding of aluminum alloy during variable polarity plasma arc welding process with AC-DC mixing output current[J]. Transactions of the China Welding institution, 2013, 34(9):59-62. [9] 安腾弘平. 焊接电弧现象[M]. 北京:机械工业出版社, 1985. [10] 韩永全, 吕耀辉, 陈树君, 等. 变极性等离子电弧形态对电弧力的影响[J]. 焊接学报, 2005, 26(5):49-52. Han Yongquan, LV Yaohui, Chen Shujun,et al. Influence of variable polarity plasma arc shape on arc force[J]. Transactions of the China Welding institution, 2005, 26(5):49-52. -
