轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律

张津; 计鹏飞; 周俊; 连勇

留言板

尊敬的读者、作者、审稿人, 关于本刊的投稿、审稿、编辑和出版的任何问题, 您可以本页添加留言。我们将尽快给您答复。谢谢您的支持!

姓名
邮箱
手机号码
标题
留言内容
验证码

轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律

张津, 计鹏飞, 周俊, 连勇

文章导航 > 焊接学报 > 2016 > 37(11): 51-54

张津, 计鹏飞, 周俊, 连勇. 轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律[J]. 焊接学报, 2016, 37(11): 51-54.

引用本文:

张津, 计鹏飞, 周俊, 连勇. 轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律[J]. 焊接学报, 2016, 37(11): 51-54.

ZHANG Jin, JI Pengfei, ZHOU Jun, LIAN Yong. Effect of shoulder diameter on microstructure of dissimilar Al alloys friction stir welding joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(11): 51-54.

Citation:

ZHANG Jin, JI Pengfei, ZHOU Jun, LIAN Yong. Effect of shoulder diameter on microstructure of dissimilar Al alloys friction stir welding joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(11): 51-54.

轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律

北京科技大学新材料技术研究院, 北京 100083

基金项目: 国家自然科学基金资助项目（51275037）

Effect of shoulder diameter on microstructure of dissimilar Al alloys friction stir welding joint

Institute for Advanced Materials and Technology, University of Science and Technology Beijing, Beijing 100083, China

摘要: 对5083铝/6082铝异种材料搅拌摩擦焊（friction stir welding，FSW）进行研究，重点分析轴肩直径对横截面形貌、显微组织与显微硬度的影响规律.结果表明，FSW接头焊核区由致密细小的等轴晶组成；增加轴肩直径可增加焊核区沿垂直焊缝方向的宽度以及增大焊核区、热影响区与热力影响区的晶粒尺寸.与后退侧的6082铝合金不同，前进侧5083铝合金的热力影响区发生了动态再结晶.显微硬度呈W形分布，最小值出现在热影响区.显微硬度的测试结果与焊核区的横截面形貌结果吻合.
- 搅拌摩擦焊 /
- 5083/6082异种材料 /
- 显微组织 /
- 显微硬度
Abstract: Dissimilar 5083/6082 Al alloys friction stir welding (FSW) joint was experimentally investigated. Effects of the shoulder diameter on the cross section morphology, microstructure and microhardness are mainly discussed. The welded zone of FSW joint is characterized with fine and equiaxed grains. With the increase of shoulder diameter, the cross section of weld zone perpendicular to the weld is enlarged and all the grains size of the welded zone, heat affected zone and thermo-mechanically affected zone increases. The dynamic recrystallization happens in thermo-mechanically affected zone of 5083 Al alloy at advancing side, which is different to the 6082 Al alloy at retreating side. The microhardness distribution presents a W shape and the minimum value locates at the heat affected zone. The result of microhardness agrees with the cross-section morphology of the welded zone.
- friction stir welding /
- 5083/6082 dissimilar Al alloys /
- microstructure /
- microhardness

[1]	Mishra R S, Ma Z Y. Friction stir welding and processing[J]. Materials Science and Engineering:R, 2005, 50(1/2):1-78.
[2]	姬书得, 孟祥晨, 黄永宪, 等. 搅拌头旋转频率对静止轴肩搅拌摩擦焊接头力学性能的影响规律[J]. 焊接学报, 2015, 36(1):51-54. Ji Shude, Meng Xiangchen, Huang Yongxian, et al. Effect of rotational velocity of tool on mechanical properties of stationary shoulder friction stir welding. Transactions of the China Welding Institution, 2015,36(1):51-54.
[3]	Aval H J, Serajzadeh S, Sakharova N, et al. A study on microstructures and residual stress distributions in dissimilar friction-stir welding of AA5086-AA6061[J]. Journal of Materials Science, 2012, 47(14):5428-5437.
[4]	王凡, 房湛, 徐琛, 等. 异种高强铝合金间搅拌摩擦焊接头组织与性能研究[J]. 航空材料学报, 2015, 35(1):33-38. Wang Fan, Fang Zhan, Xu Chen, et al. Microstructure and mechanical properties of FSW joints between dissimilar high-strength aluminum alloys[J]. Journal of Aeronautical Materials, 2015, 35(1):33-38.
[5]	Ilangovan M, Boopathy S R, Balasubramanian V, et al. Microstructure and tensile properties of friction stir welded dissimilarAA6061-AA5086 aluminium alloy joints[J]. Transactions of Nonferrous Metals Society of China, 2015, 25:1080-1090.
[6]	刘鸽平, 黄春平, 邢丽, 等. LD31-LF6铝合金搅拌摩擦焊接头组织与性能[J]. 南昌航空大学学报(自然科学版), 2008, 22(1):15-19. Liu Geping, Huang Chunping, Xing Li, et al. The organization and performance of LD31-LF6 aluminum alloy friction stir welding[J]. Journal of Nanchang Hangkong University (Natural Science Edition), 2008, 22(1):15-19.
[7]	Jin H, Saimoto S, Ball M, et al. Characterisation of microstructure and texture in friction stir welded joints of 5754 and 5182 aluminium alloy sheets[J]. Materials Science and Technology, 2001, 17(12):1605-1614..
[8]	Agarwal S, Briant C L, Hector Jr L G, et al. Friction stir processed AA5182-O and AA6111-T4 aluminum alloys. Part 1:electron backscattered diffraction analysis[J]. Journal of materials engineering and performance, 2007, 16(4):391-403.
[9]	Yue Y M, Li Z W, Ji S D, et al. Effect of reverse-threaded pin on mechanical properties of friction stir lap welded alclad 2024 aluminum alloy[J]. Journal of Materials Science and Technology, 2016, 32(7):671-675.
[10]	张会杰, 王敏, 张骁, 等. 2A14-T6铝合金双轴肩搅拌摩擦焊特征及接头组织性能分析[J]. 焊接学报, 2015, 36(12):65-68. Zhang Huijie, Wang Min, Zhang Xiao, et al. Characteristics and joint microstructure-property analysis of bobbin tool friction stir welding of 2A14-T6 aluminum alloy[J]. Transactions of the China Welding Institution, 2015, 36(12):65-68.
[11]	张成聪, 常保华, 陶军, 等. 7050铝合金搅拌摩擦焊动态再结晶组织影响因素[J]. 焊接学报, 2012, 33(8):89-92. Zhang Chengcong, Chang Baohua, Tao Jun, et al. Influence factors of dynamic recrystallization of 7050 aluminium alloy friction stir weld[J]. Transactions of the China Welding Institution, 2012, 33(8):89-92.
[12]	Steuwer A, Peel M J, Withers P J. Dissimilar friction stir welds in AA5083-AA6082:The effect of process parameters on residual stress[J]. Materials Science and Engineering:A, 2006, 441(1/2):187-196.

[1]	张振, 薛鹏, 王东, 王全兆, 倪丁瑞, 肖伯律, 马宗义. SiCp/2009Al复合材料搅拌摩擦焊T形接头组织与力学性能 . 焊接学报, 2022, 43(6): 75-81. doi: 10.12073/j.hjxb.20220104002
[2]	尹燕, 康平, 路超, 张圆, 张瑞华. 激光焊接异种钢组织及显微硬度分析 . 焊接学报, 2020, 41(7): 71-77. doi: 10.12073/j.hjxb.20191227002
[3]	王海燕, 牛春菊, 崔国涛, 翟海舟. 焊接工艺对TP304/SS400异种钢焊接接头组织和性能的影响 . 焊接学报, 2019, 40(5): 131-136. doi: 10.12073/j.hjxb.2019400140
[4]	尹燕, 潘存良, 赵超, 张瑞华, 屈岳波. 激光熔覆高铬铁基合金的组织形成机制及对显微硬度的影响 . 焊接学报, 2019, 40(7): 114-120. doi: 10.12073/j.hjxb.2019400192
[5]	常川川, 张田仓, 李菊. Ti-22Al-27Nb合金线性摩擦焊接头组织与显微硬度分析 . 焊接学报, 2019, 40(3): 140-144. doi: 10.12073/j.hjxb.2019400087
[6]	张铁浩1,刘雪松2,邢艳双1. 搅拌摩擦焊修复ZL210铸造铝合金组织与性能分析 . 焊接学报, 2018, 39(4): 115-118. doi: 10.12073/j.hjxb.2018390107
[7]	卜文德1,2,3,刘容光1,宋锋涛1,柯黎明1,钱鲁泓3,董文宁3,何鹏2. 电子束局部热处理工艺对TC4钛合金焊接接头组织及硬度的影响 . 焊接学报, 2017, 38(9): 102-106. doi: 10.12073/j.hjxb.20151114001
[8]	刘伟, 熊华平, 唐思熠. Si元素含量对激光快速成形制备Nb-Si二元合金显微组织演变的影响 . 焊接学报, 2017, 38(3): 53-56,61.
[9]	尹燕, 栗子林, 许广伟, 张瑞华, 屈岳波. 3Cr13厨刀碟片激光同轴送粉熔覆层的显微硬度与组织 . 焊接学报, 2016, 37(10): 85-88.
[10]	张静, 韩文妥, 常永勤, 万发荣. ODS钢搅拌摩擦焊接头的微观组织及其高温力学性能 . 焊接学报, 2015, 36(10): 9-11,40.
[11]	姚磊, 沈以赴, 李博, 胡伟叶. Cu/Ti异种金属搅拌摩擦焊搭接接头组织与性能 . 焊接学报, 2014, 35(2): 109-112.
[12]	陈益平, 邵景辉, 胡德安, 程东海. 镁/钢异种材料点焊接头力学性能及显微组织分析 . 焊接学报, 2013, (4): 101-104.
[13]	陈影, 付宁宁, 沈长斌, 葛继平. 镁铝异种金属搅拌摩擦焊搭接接头组织与性能分析 . 焊接学报, 2012, (7): 93-96.
[14]	张传臣, 黄继华, 张田仓, 季亚娟. 异质钛合金线性摩擦焊接头微观组织与显微硬度分析 . 焊接学报, 2012, (4): 97-100.
[15]	陈玉华, 倪泉, 黄春平, 柯黎明. 钛/铝异种金属搅拌摩擦焊搭接接头的组织结构 . 焊接学报, 2011, (9): 73-76.
[16]	崔占全, 李达, 孙明辉, 郭宇星. 7075铝合金与H68黄铜的搅拌摩擦焊组织分析 . 焊接学报, 2011, (7): 91-94.
[17]	刘鹏, 史清宇, 霍玉双, 张元彬, 李阳. 采用搅拌摩擦焊方法制备的非晶增强铝基复合材料的微观组织分析 . 焊接学报, 2010, (11): 53-56.
[18]	邢丽, 李磊, 柯黎明. 低碳钢与紫铜搅拌摩擦焊接头显微组织分析 . 焊接学报, 2007, (2): 17-20.
[19]	张保奇, 王德和, 李晓杰, 杨文彬. 321-15CrMoR爆炸焊接复合板结合界面区的显微组织分析 . 焊接学报, 2006, (2): 108-112.
[20]	刘鹏, 李亚江, 王娟, 耿浩然. Mg/Al异种材料真空扩散焊界面区域的显微组织 . 焊接学报, 2004, (5): 5-8.

点击查看大图

计量

文章访问数: 357
HTML全文浏览量: 2
PDF下载量: 424
被引次数: 0

轴肩尺寸对异种铝合金材料搅拌摩擦焊接头显微组织的影响规律

北京科技大学新材料技术研究院, 北京 100083

基金项目: 国家自然科学基金资助项目（51275037）

收稿日期: 2016-07-18

关键词:

摘要: 对5083铝/6082铝异种材料搅拌摩擦焊（friction stir welding，FSW）进行研究，重点分析轴肩直径对横截面形貌、显微组织与显微硬度的影响规律.结果表明，FSW接头焊核区由致密细小的等轴晶组成；增加轴肩直径可增加焊核区沿垂直焊缝方向的宽度以及增大焊核区、热影响区与热力影响区的晶粒尺寸.与后退侧的6082铝合金不同，前进侧5083铝合金的热力影响区发生了动态再结晶.显微硬度呈W形分布，最小值出现在热影响区.显微硬度的测试结果与焊核区的横截面形貌结果吻合.
