采用Au基钎料真空钎焊Al2O3陶瓷
Vacuum brazing of Al2O3 ceramic using Au-based brazing filler
-
摘要: 首先选用AgCuTi活性钎料在880℃/10 min参数下对A12O3陶瓷表面进行金属化处理，之后尽量去除金属化层中的AgCu共晶组织，然后选用两种Au基高温钎料在980℃/10 min参数下对金属化后的A12O3进行了钎焊连接.结果表明，在Al2O3/Au-Ni/Al2O3接头中靠近Al2O3母材的界面处生成一层薄薄的扩散反应层，该反应层主要由TiO2和Al2O3组成；在Al2O3/Au-Cu/Al2O3接头中同样存在扩散反应层，与前者不同的是，接头中检测到Ti-Au相的存在.分别对Au-Ni和Au-Cu两种钎料获得的Al2O3接头进行了抗剪强度测试，前者对应接头强度为95.5 MPa，后者对应接头强度达到102.3 MPa.Abstract: First, surface metallization of Al2O3 ceramic was carried out at 880℃ heat treatment for 10 min using AgCuTi as active brazing filler, and then, vacuum brazing of the ceramic was performed at 980℃ for 10 min using two Au-based brazing fillers. The results showed that a thin diffusion layer containing TiO2 and Al2O3 was formed at the Al2O3/Au-Ni/Al2O3 joint interface close to Al2O3 side. In Al2O3/Au-Cu/Al2O3 joint, besides Ti-O compound, Ti-Au compound existed in the diffusion layer. The test results at room temperature showed that the shear strength of two ceramic joints were 95.5 MPa and 102.3 MPa, respectively.
-
Keywords:
- Al2O3 ceramic /
- brazing /
- AgCuTi /
- metallization /
- Au-based brazing filler
-
-
[1] 任家烈, 吴爱萍. 先进材料的连接[M]. 北京:机械工业出版社, 2000. [2] 张启运, 庄鸿寿. 钎焊手册[M]. 北京:机械工业出版社, 2008. [3] Iman F, Rasoul S M, Navid H. Alumina-copper joining by the sintered metal powder process[J]. Ceramics International, with Industrial Ceramics, 2010, 36(2):741-747. [4] Liu G W, Qiao G J, Wang H J, et al. Bonding mechanisms and shear properties of alumina ceramic/stainless steel brazed joint[J]. Journal of Materials Engineering and Performance, 2011, 20(9):1563-1568. [5] Do Nascimento R M, Martinelli A E, Buschinelli A J De A, et al. Brazing Al2O3 to sintered Fe-Ni-Co alloys[J]. Journal of Materials Science, 1999, 34(23):5839-5845. [6] Kozlova O, Braccini M, Voytovych R, et al. Brazing copper to alumina using reactive CuAgTi alloys[J]. Acta Materialia, 2010, 58(4):1252-1260. [7] Mohammed J K, Hashim F A, Yousif R H, et al. Actively brazed alumina to alumina joints using CuTi, CuZr and eutectic AgCuTi filler alloys[J]. Ceramics International, with Industrial Ceramics, 2010, 36(8):2287-2295. [8] Mandal S, Ray A K, Ray A K. Correlation between the mechanical properties and the microstructural behaviour of Al2O3-(Ag-Cu-Ti) brazed joints[J]. Materials Science and Engineering:A, 2014, 383(2):235-244. [9] Miedema A R, De Boer F R, Boom R. Model predictions for the enthalpy of formation of transition metal alloys[J]. Calphad, 1977, 1(4):341-359. [10] 陈波, 熊华平, 毛唯, 等. Ti3Al基合金的高温钎焊探索研究[C]//第十七届全国钎焊及特种连接技术交流会论文集, 2009:281-284. Chen Bo, Xiong Huaping, Mao Wei, et al. Reseach on brazing of Ti3Al-based alloy[C]//Proceedings of the 18th Annual Meeting of Soldering, Brazing and Special Joining Technologies, China, 2009:281-284. -
