基于ANSYS优化设计求解双椭球热源模型参数

顾颖, 李亚东, 强斌, 揭志羽, 陈小松

顾颖, 李亚东, 强斌, 揭志羽, 陈小松. 基于ANSYS优化设计求解双椭球热源模型参数[J]. 焊接学报, 2016, 37(11): 15-18.
引用本文: 顾颖, 李亚东, 强斌, 揭志羽, 陈小松. 基于ANSYS优化设计求解双椭球热源模型参数[J]. 焊接学报, 2016, 37(11): 15-18.
shu
GU Ying, LI Yadong, QIANG Bin, JIE Zhiyu, CHEN Xiaosong. Parameter optimization of double ellipsoidal heat source model by ANSYS[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(11): 15-18.
Citation: GU Ying, LI Yadong, QIANG Bin, JIE Zhiyu, CHEN Xiaosong. Parameter optimization of double ellipsoidal heat source model by ANSYS[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(11): 15-18.
shu

基于ANSYS优化设计求解双椭球热源模型参数

  • 1.

    西南交通大学 土木工程学院, 成都 610031

  • 2.

    江苏中泰桥梁钢构股份有限公司, 靖江 214521

基金项目: 国家自然科学基金资助项目（51378430）

Parameter optimization of double ellipsoidal heat source model by ANSYS

  • 1.

    School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China

  • 2.

    Jiangsu Zhongtai Bridge Steel Structure Co., Ltd, Jingjiang 214521, China

摘要

    摘要
  • 摘要: 为实现双椭球热源模型（double ellipsoidal heat Source model，DEHSM）参数自动化求解，基于ANSYS优化设计，提出一种新的DEHSM参数求解方法.根据提出的方法，利用VB语言开发了DEHSM参数求解程序，分析了程序失效原因，给出了处理对策；对四种不同的焊接工艺参数，采用开发的程序求解了DEHSM参数，并比较了熔宽、熔深的计算值与实测值的差异.经实例验证表明，在保证求解精度的前提下，提出的方法和开发的程序能够有效地求解DEHSM参数；提出的基于ANSYS优化设计求解热源模型参数的方法及相关优化变量的设置，还可适用于高斯热源、3D锥形热源等其它热源参数的求解.
    Abstract: To automatically solve the parameter of double ellipsoidal heat source model (double ellipsoidal heat source model, DEHSM), a new method for solving the parameters of DEHSM was proposed based on ANSYS. Then, a program was developed for solving the DEHSM parameter, and then the program failure were analyzed, the strategy to solve the problem was listed. Finally the DEHSM parameters in four different process were solved with the program, and the difference between calculated values and measured values of penetration and width of welding pool was compared. Theoretical analysis and example results indicate that, in the premise of accuracy assurance, the proposed method and the program can effectively solve the DEHSM parameters. The proposed method and the pattern for setting the related optimization variables can be also suitable to Gauss heat source model and 3D conical heat source,etc.
    • HTML全文
    • 参考文献(12)
  • [1] Goldak J, Chakravarti A, Bibby M. A New Finite Element Model for Welding Heat Sources[J]. Metallurgical Transactions B, 1984, 15(2):299-305.
    [2] 牟取晗, 韩永全, 赵鹏, 等. 铝合金变极性等离子弧焊应力场数值分析[J]. 焊接学报, 2015, 36(11):97-100+118. Mou Quhan, HanYongquan, Zhao Peng, et al. Numerical simulation of stress field in variable polarity plasma arc welding of aluminum alloys[J]. Transactions of the China Welding Institution, 2015, 36(11):97-100.
    [3] 董文超, 陆善平, 李殿中. 焊接顺序对大型薄板装甲钢结构焊接变形的影响[J]. 焊接学报, 2015, 36(7):43-46, 50. Dong Wenchao, Lu Shanping, Li Dianzhong. Effect of welding sequence on welding distortion of large-sized thin armor steel structure[J]. Transactions of the China Welding Institution, 2015, 36(7):43-46, 50.
    [4] Abhay Sharma, Ajay Kumar Chaudhary. Estimation of heat source model parameters for twin-wire submerged arc welding[J]. The International Journal of Advanced Manufacturing Technology, 2009, 45(11-12):1096-1103.
    [5] Gery D, Long H, Maropoulos P. Effects of welding speed, energy input and heat source distribution on temperature variations in butt joint welding[J]. Journal of Materials Processing Technology, 2005, 167(2-3):393-401.
    [6] 李培麟, 陆皓. 双椭球热源参数的敏感性分析及预测[J]. 焊接学报, 2011, 31(11):89-91. Li Peilin, Lu Hao. Sensitivity analysis and prediction of double ellipsoid heatsource parameters[J]. Transactions of the China Welding Institution, 2011, 31(11):89-91, 95.
    [7] Li Peilin, Lu Hao. Hybrid heat source model designing and parameter prediction on tandem submerged arc welding[J]. The International Journal of Advanced Manufacturing Technology. 2012, 62(5-8):577-585.
    [8] Argyris J H, Szimmat J, Willam K. Finite element analysis of arc-welding process. numerical methods in thermal problems[C]//Proceedings of the Third International Conference, Seattle WA, USA, Pineridge Press, Swansea UK. 1983, 249-258.
    [9] Jia Xiaolei, Xu Jie, Liu Zhaoheng, et al. A New method to estimate heat source parameters in gas metal arc welding simulation process[J]. Fusion Engineering and Design, 2014, 89:40-48.
    [10] Shoichi Kiyoshima, Dean Deng, Kazuo Ogawa, et al. Influences of heat source model on welding residual stress and distortion in a multi-pass J-groove joint[J]. Computational Materials Science, 2009, 46:987-995.
    [11] D.拉达伊. 焊接热效应[M]. 北京:机械工业出版社, 1997.
    [12] 李培麟. 多丝埋弧焊热源模型与焊缝成形的模拟研究[D]. 上海:上海交通大学, 2012.
