SiC<sub>P</sub>/Al复合材料的真空扩散钎焊

刘世艳; 张丽霞; 亓钧雷; 冯吉才

SiC_P/Al复合材料的真空扩散钎焊

哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001

计量
- 文章访问数: 514
- HTML全文浏览量: 11
- PDF下载量: 351
出版历程
- 收稿日期: 2014-11-18

Vacuum diffusion brazing of SiCp/Al composites

State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 文中采用Al/Cu/Al复合箔扩散钎焊SiC_P/Al复合材料，采用SEM，EDS，XRD分析接头界面组织，研究了钎焊温度对接头界面组织及力学性能的影响，并结合Al-Cu二元相图分析接头形成机制.结果表明，固定连接压力为1 MPa，保温时间为10 min，当钎焊温度从590℃升至640℃，接头界面产物由Al₂Cu+αAl共晶组织转变为断续的Al₂Cu金属间化合物，Al-Cu液相向两侧母材扩散的距离增加，接头的抗剪强度呈现先增大后减小的变化趋势.当钎焊温度为620℃，保温时间为10 min，连接压力为1 MPa时，接头的抗剪强度达到最大值69 MPa.
- SiC_P/Al复合材料 /
- 扩散钎焊 /
- 界面组织 /
- 抗剪强度
Abstract: Vacuum diffusion brazing of SiC particle reinforced aluminum matrix was performed with Al/Cu/Al composite foils. The microstructure of the joint was investigated by SEM, EDS and XRD. The formation mechanism of the joints was analyzed according to Al-Cu binary phase diagram. The effects of brazing temperature on the interfacial microstructure and shear strength were studied. The results shows that as the brazing temperature rise from 590℃ to 640℃, the interfacial products change from Al₂Cu+αAl eutectic structure to discontinuous Al₂Cu intermetallic compound. The diffusion distance of liquid into base materials increase and the shear strength of joints increases and then decreases with brazing parameters. When the brazing temperature is 620℃, the holding time is 10 min and the bonding pressure is 1 MPa, the shear strength of the joints is up to the maximum value of 69 MPa.
- SiC particle reinforced aluminum matrix /
- diffusion brazing /
- interface structure /
- shear strength

HTML全文

参考文献(9)

[1]	武高辉, 修子扬, 孙东立, 等. 环保型电子封装用SiCp/Al复合材料性能研究[J]. 材料科学与工艺, 2006, 3(14): 244-246. Wu Gaohui, Xiu Ziyang, Sun dongli, et al. Study on properties of the environmental-friendly SiC_P/Al composites for electronic packaging applications[J]. Materials Science & Technology, 2006, 3(14): 224-246.
[2]	Huang R Y, Chen S C, Huang J C. Electron and laser beam welding of high strain rate super plastic Al-6061/SiC Composites[J]. Metallurgical and Materials Transactions A, 2001, 32(10): 2575-2584.
[3]	Chen M A, Wu C S, Zou Z D. Electron Beam Welding of SiC_P/LD2 composites[J]. Transactions of Nonferrous Metals Society of China, 2006, 16(4): 818-823.
[4]	雷玉成, 王志伟, 陈希章, 等. 电弧超声对SiC_p/Al MMCs焊缝组织与性能的影响[J]. 焊接学报, 2010, 31(10): 17-21. Lei Yucheng, Wang Zhiwei, Chen Xizhang, et al. Investments on influences of the arc ultrasonic on the microstructure and performance of SiCp/Al MMCs joints[J]. Transactions of the China Welding Institution, 2010, 31(10): 17-21.
[5]	陈铮, 金朝阳, 顾晓波, 等. 用Cu箔中间层瞬间液相连接SiC_P/Al复合材料的界面现象与连接强度[J]. 焊接学报, 2001, 22(5): 27-30. Chen Zheng, Jin Chaoyang, Gu Xiaobo, et al. Interfacial Phenomena and Joint strength in transient liquid-phase bonding of SiC_P/Al metal matrix composite using cu foil interlayer[J]. Transactions of the China Welding Institution, 2001, 22(5): 27-30.
[6]	Kavian O C, Tahir I K, Gossett D, et al. Transient liquid phase diffusion bonding Al-6061 using nano-dispersed ni coatings[J]. Materials and Design, 2012, 7(33): 469-475.
[7]	张洋, 闫久春. 高体积分数SiC颗粒增强铝基复合材料的超声波钎焊[J]. 焊接, 2008(8): 29-31. Zhang Yang, Yan Jiuchun. Ultrasonic brazing of SiC particles reinforced aluminum matrix composite with a high fraction volume[J]. Welding & Joining, 2008(8): 29-31.
[8]	Ellis M, Gittos M, Threadgill P L. Joining of aluminum base metal matrix composites[J]. International Materials Reviews, 1996(2): 41-58.
[9]	南水平, 黄继华, 陈树海, 等. Al-Si-Cu合金粉末扩散钎焊Al/Cu接头组织及性能[J]. 焊接学报, 2014, 35(1): 79-82. Nan Shuiping, Huang Jihua, Chen Shuhai, et al. Microstructure and properties of diffusion brazed aluminum/copper joint with Al-Si-Cu alloy powder[J]. Transactions of the China Welding Institution, 2014, 31(1): 79-82.
