外加横向磁场对高速GMAW焊缝成形的影响

王林, 高进强, 杨丰兆

王林, 高进强, 杨丰兆. 外加横向磁场对高速GMAW焊缝成形的影响[J]. 焊接学报, 2016, 37(10): 9-12.
引用本文: 王林, 高进强, 杨丰兆. 外加横向磁场对高速GMAW焊缝成形的影响[J]. 焊接学报, 2016, 37(10): 9-12.
shu
WANG Lin, GAO Jinqiang, YANG Fengzhao. Effect of external transverse magnetic field on weld appearance[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(10): 9-12.
Citation: WANG Lin, GAO Jinqiang, YANG Fengzhao. Effect of external transverse magnetic field on weld appearance[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(10): 9-12.
shu

外加横向磁场对高速GMAW焊缝成形的影响

  • 山东大学 材料液固结构演变及加工教育部重点实验室, 济南 250061

基金项目: 国家自然科学基金资助项目（51275276）

Effect of external transverse magnetic field on weld appearance

  • Key Laboratory for Liquid-Solid Structural Evolution & Processing of Materials, Ministry of Education, Shandong University, Jinan 250061, China

摘要

    摘要
  • 摘要: 对于高速熔化极气体保护焊接（GMAW）过程，当焊接速度超过临界值后，会出现驼峰焊道，焊缝成形变差.研究证明，熔池中动量很大的后向液体流是产生驼峰焊道的主要原因.研发了外加横向磁场发生装置，通过产生的电磁力来抑制后向液体流的动量，从而抑制驼峰焊道的形成.应用特斯拉计测试和考察了工件上磁感应强度大小及分布的影响因素.通过开展焊接工艺试验分析了不同强度的外加磁场作用下的焊缝成形规律.结果表明，外加横向磁场能明显调控熔池流态，有效抑制驼峰焊道和咬边等缺陷，显著改善焊缝成形，提高临界焊接速度.
    Abstract: In high speed gas metal arc welding (GMAW) process, severe geometric defects such as humping bead and undercutting will occur if the welding speed exceeds the critical value. The previous experiments had shown that the backward flowing molten jet with high momentum in the weld pool is responsible for the formation of humping bead. In this study, an external tranverse magnetic field generator is developed so that the welding current in the weld pool interacts with the magnetic field to produce an additional EMF pointing toward the front part of weld pool. And the EMF can control the backward flowing molten jet in the weld pool and adjust fluid flow field to suppress the occurrence of the humping bead. Bead-on plate welding experiments were performed and the influences of the exerted magnetic flux density on the weld bead formation, the arc and the fluid flow behavior inside the weld pool were investigated. The mechanism of the suppressing humping bead by the external electromagnetic field was revealed. The results show that the external magnetic field can remarkably adjust the fluid flow field in weld pool and prevent the occurance of the weld defects such as humping bead and undercutting, so the quality of weld bead is remarkably improved, and the critical welding speed is notably increased.
    • HTML全文
    • 参考文献(12)
  • [1] Naidu D S, Ozcelik S, Moore K L. Modeling, sensing and control of gas metal arc welding[M]. Oxford: Elsevier Science Ltd, 2003.
    [2] Nguyen T C, Weckman D C, Johnson D A, et al. High speed fusion weld bead defects[J]. Science and Technology of Welding & Joining, 2006, 11(6): 618-633.
    [3] Nguyen T C, Weckman D C, Johnson D A, et al. The humping phenomenon during high speed gas metal arc welding[J]. Science and Technology of Welding & Joining, 2005, 10(4): 447-459.
    [4] 胡志坤, 武传松. 高速MAG电弧焊驼峰焊道产生过程的试验研究[J]. 金属学报, 2008, 44(12): 1445-1449. Hu Zhikun, Wu Chuansong. Experimental investigation on forming process of humping bead in high speedmag arc welding[J]. Acta Metallurgica Sinica, 2008, 44(12): 1445-1449.
    [5] 陈姬, 武传松. 高速GMAW驼峰焊道形成过程的数值分析[J]. 金属学报, 2009, 45(9): 1070-1076. Chen Ji, Wu Chuansong. Numerical simulation of forming process of humping bead in high speed GMAW[J]. Acta Metallurgica Sinica, 2009, 45(9): 1070-1076.
    [6] Wu C S, Zhong L M, Gao J Q. Visualization of hump formation in high-speed gas metal arc welding[J]. Measurement Science and Technology, 2009, 20(11): 115700.
    [7] Michie K, Blackman S, Ogunbiyi T E B. Twin-wire GMAW: process characteristics and applications[J]. Welding Journal, 1999, 78(5): 31-34.
    [8] Li K H, Chen J S, Zhang Y M. Double-electrode GMAW process and control[J]. Welding Journal-New York,2007, 86(8): 231-237.
    [9] Choi H W, Farson D F, Cho M H. Using a hybrid laser plus GMAW process for controlling the bead humping defect[J]. Welding Journal, 2006, 85(8): 174-179.
    [10] 朱胜, 王启伟, 殷凤良, 等. 交变纵向磁场作用下MIG焊电弧行为研究[J]. 材料热处理学报, 2012, 32(11): 23-27. Zhu Sheng, Wang Qiwei, Yin Fengliang, et al. Study on behavior of MIG welding arc under alternating longitudinal magnetic field[J]. Transactions of Metal Heat Treatment, 2012, 32(11): 23-27.
    [11] 陈树君, 王军, 王会霞, 等. 纵向磁场作用下的旋转射流过渡的机理[J]. 焊接学报, 2005, 26(3): 45-49. Chen Shujun, Wang Jun, Wang Huixia, et al. Mechanism of rotating spray transfer mode under the longitudinal magnetic field[J]. Transactions of the China Welding Institution, 2005, 26(3): 45-49.
    [12] Bachmann M, Avilov V, Gumenyuk A, et al. About the influence of a steady magnetic field on weld pool dynamics in partial penetration high power laser beam welding of thick aluminium parts[J]. International Journal of Heat and Mass Transfer, 2013, 60: 309-321.
