高速GMAW驼峰形成过程的数值分析

吴东升, 华学明, 叶定剑, 张菁

吴东升, 华学明, 叶定剑, 张菁. 高速GMAW驼峰形成过程的数值分析[J]. 焊接学报, 2016, 37(10): 5-8.
引用本文: 吴东升, 华学明, 叶定剑, 张菁. 高速GMAW驼峰形成过程的数值分析[J]. 焊接学报, 2016, 37(10): 5-8.
shu
WU Dongsheng, HUA Xueming, YE Dingjian, ZHANG Jing. Numerical analysis of humping formation in high speed GMAW process[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(10): 5-8.
Citation: WU Dongsheng, HUA Xueming, YE Dingjian, ZHANG Jing. Numerical analysis of humping formation in high speed GMAW process[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(10): 5-8.
shu

高速GMAW驼峰形成过程的数值分析

  • 1.

    上海交通大学 上海市激光制造与材料改性重点试验室, 上海 200240;高新船舶与深海开发装备协同创新中心, 上海 200240;上海发电设备成套设计研究院, 上海 200240

  • 2.

    上海交通大学 上海市激光制造与材料改性重点试验室, 上海 200240;高新船舶与深海开发装备协同创新中心, 上海 200240

基金项目: 国家自然科学基金资助项目（51275299和51504152）

Numerical analysis of humping formation in high speed GMAW process

  • 1.

    Shanghai Key Laboratory of Material Laser Processing and Modification, Shanghai Jiaotong University, Shanghai 200240, China;Collaborative Innovation Center for Advanced Ship and Deep-Sea Exploration, Shanghai 200240, China;Shanghai Power Equipment Research Institute, Shanghai 200240, China

  • 2.

    Shanghai Key Laboratory of Material Laser Processing and Modification, Shanghai Jiaotong University, Shanghai 200240, China;Collaborative Innovation Center for Advanced Ship and Deep-Sea Exploration, Shanghai 200240, China

摘要

    摘要
  • 摘要: 文中通过数值模拟来研究常速、高速熔化极气体保护焊的温度场和流场，并利用高速摄影观察熔池流动，分析了驼峰形成过程.结果表明，常速焊接熔池纵截面同时存在逆时针向内和顺时针向外两种流动方式，但随着焊接速度的提高，熔池纵截面仅存在逆时针向内单一流动方式.高速焊接时，较大动量的后向液体流和足够大的表面张力促进液态金属在熔池尾部不断堆积、变大.沿焊接方向，熔池受到不均匀的表面张力法向力作用而收缩，这是驼峰形成的两个重要因素.任何能降低表面张力的措施，都能抑制驼峰的形成.
    Abstract: The convection difference between normal speed and high speed GMAW processes was investigated using the numerical simulation, a high speed photography system was used to capture the transient images of the weld pool, and the humping formation in high speed GMAW process was also discussed. The results show that at the longitudinal sectional view of the weld pool behind the arc, both counterclockwise circulation and outward fluid flow pattern exist in normal speed GMAW process, only counterclockwise circulation exists in high speed GMAW process. Two main factors are responsible for the humping formation, one is that the high momentum of the backward fluid flow causes the initiation and growth of swelling, and the other is that the unbalance of normal surface tension force in the welding direction promotes the shrinkage of liquid channel. Any measures that help reduce the surface tension can inhibit the formation of humping.
    • HTML全文
    • 参考文献(11)
  • [1] Bradstreet B J. Effect of surface tension and metal flow on weld bead formation[J]. Welding Journal, 1968, 47(7): 314s-322s.
    [2] Mills K C, Keene B J. Factors affecting variable weld penetration[J]. International Materials Reviews, 1990, 35(1): 185-216.
    [3] Nguyen T C, Weckman D C, Johnson D A, et al. The humping phenomenon during high speed gas metal arc welding[J]. Science and Technology of Welding & Joining, 2005, 10(4): 447-459.
    [4] Nguyen T C, Weckman D C, Johnson D A. Predicting onset of high speed gas metal arc weld bead defects using dimensional analysis techniques[J]. Science and Technology of Welding & Joining, 2007, 12(7): 634-648.
    [5] Cho M H, Farson D F. Understanding bead hump formation in gas metal arc welding using a numerical simulation[J]. Metallurgical and materials transactions B, 2007, 38(2): 305-319.
    [6] Chen M J, Wu C S. Numerical analysis of forming mechanism of hump bead in high speed GMAW[J]. Welding in the World, 2010, 54(9): 286-291.
    [7] 杨战利, 张善保, 杨永波, 等. 粗丝高速MAG焊驼峰焊道形成机理分析[J]. 焊接学报, 2013, 34(1): 61-64. Yang Zhanli, Zhang Shanbao, Yang Yongbo, et al. Study on humping bead formation mechanism in thick-wire high-speed MAG welding[J]. Transactions of the China Welding Institution, 2013, 34(1): 61-64.
    [8] 常云龙, 路林, 李英民, 等. 磁控TIG高速焊焊缝成形机理[J]. 焊接学报, 2013, 34(6): 1-4. Chang Yunlong, Lu Lin, Li Yingming, et al. Mechanism of weld formation during high speed TIG welding with external magnetic fields[J]. Transactions of the China Welding Institution, 2013, 34(6): 1-4.
    [9] 娄小飞, 陈茂爱, 武传松, 等. 高速TIG-MIG复合焊焊缝驼峰及咬边消除机理[J]. 焊接学报, 2014, 35(8): 87-90. Lou Xiaofei, Chen Maoai, Wu Chuansong, et al. Humping and undercutting suppression mechanism for high speed TIG-MIG hybrid welding[J]. Transactions of the China Welding Institution, 2014, 35(8): 87-90.
    [10] Goldak J, Chakravarti A, Bibby M. A new finite element model for welding heat sources[J]. Metallurgical & Materials Transactions B, 1984, 15(2): 299-305.
    [11] 吴东升, 华学明, 叶定剑, 等. MIG焊接熔池形成与凝固过程数值模拟[J]. 焊接, 2015(9): 6-11. Wu Dongsheng, Hua Xueming, Ye Dingjian, et al. Numerical analysis of weld pool formation and solidification in MIG process[J]. Welding & Joining, 2015(9): 6-11.
