残余应力对高速列车A7N01铝合金焊接接头疲劳行为的影响

丁叁叁, 李强, 苟国庆

丁叁叁, 李强, 苟国庆. 残余应力对高速列车A7N01铝合金焊接接头疲劳行为的影响[J]. 焊接学报, 2016, 37(9): 23-28.
引用本文: 丁叁叁, 李强, 苟国庆. 残余应力对高速列车A7N01铝合金焊接接头疲劳行为的影响[J]. 焊接学报, 2016, 37(9): 23-28.
shu
DING Sansan, LI Qiang, GOU Guoqing. Effect of residual stress on fatigue behavior of welded joint of A7N01 aluminum alloy for high-speed trcion[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(9): 23-28.
Citation: DING Sansan, LI Qiang, GOU Guoqing. Effect of residual stress on fatigue behavior of welded joint of A7N01 aluminum alloy for high-speed trcion[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(9): 23-28.
shu

残余应力对高速列车A7N01铝合金焊接接头疲劳行为的影响

  • 1.

    南车四方机车车辆股份有限公司, 青岛 266111;北京交通大学 机械与电子控制工程学院, 北京 100044

  • 2.

    北京交通大学 机械与电子控制工程学院, 北京 100044

  • 3.

    西南交通大学 材料科学与工程学院, 成都 610031

基金项目: 国家科技支撑计划资助项目（2015BAG12B01）；国家重点基础研究资助项目（2014CB660807）；中央高校基本科研经费资助项目（2682014CX003）

Effect of residual stress on fatigue behavior of welded joint of A7N01 aluminum alloy for high-speed trcion

  • 1.

    CSR Qingdao Sifang Co. Ltd., Qingdao 266000, China;School of Mechanical, Electronic and Control Engineering, Beijing Jiaotong University, Beijing 100044, China

  • 2.

    School of Mechanical, Electronic and Control Engineering, Beijing Jiaotong University, Beijing 100044, China

  • 3.

    School of Materials Science and Technology, Southwest Jiaotong University, Chengdu 610031, China

摘要

    摘要
  • 摘要: 研究了残余应力在疲劳加载过程中的应力松弛行为，采用预拉伸、表面喷丸等表面预制残余应力的方法预制了表面残余应力，并研究了焊接接头的疲劳性能. 结果表明，在经过1×105周次循环载荷后，各个部位残余应力发生较大松弛，在经过2×105周次后，应力松弛较1×105周次时松弛幅度降低. 在2×105周次后，应力松弛不再明显，最终残余应力分布在拉应力20～40 MPa之间. 当引入残余应力后，各种条件下的实际应力循环比发生了明显的变化，当应力比R≥0时，随着R的增大，平均应力增大，试样的疲劳周次显著下降. 残余压应力会使裂纹萌生的周期缩短，同时加快疲劳裂纹扩展速率.
    Abstract: Residual stress relaxation behaviors of A7N01 aluminum alloy structures of underframes were investigated. The A7N01 aluminum alloy welded joints was treated by pre tension treatment and surface shot peening technology for obtaining the preset residual stress. Then the fatigue behaviors of different welded joints were investigated. The results showed that the residual stress had undergone larger relaxation after 1×105 cyclic loading. The residual stress relaxation extent had undergone gently after 2×105 cyclic loading and finally became to stable with the value at 20~40 MPa. The real cyclic stress ratio was changed different preset residual stress treatment. When R≥0, the fatigue cycles decreased with the increase of stress ration. The residual stress decreased the origin period of cracks and changed the propagation velocity of cracks.
    • HTML全文
    • 参考文献(10)
  • [1] Smith R A. 疲劳裂纹扩展-30年来的发展[M]. 顾海澄, 译. 西安交通大学出版社, 1988.
    [2] JUN HyunKyu, JUNG Hyunseung, LEE Donghyung, et al. Fatigue crack evaluation on the underframe of EMU carbody[J]. Procedia Engineering, 2010, 2(1): 893-900.
    [3] Clormann U H. Seeger T. Local stresses and strains in weldments as a basis of the proof of fatigue strength[M]//Low Cycle Fatigue and Elasto-Plastic Behaviour of Materials. Springer Netherlands, 1987.
    [4] Diaye AN', Hariri S, Pluvinage G. Stress concentration factor analysis for notched welded tubular T-joints[J]. International Journal of Fatigue. 2007, 29(8): 1554-1570.
    [5] 苟国庆, 黄楠, 陈辉, 等. 高速列车A7N01S-T5铝合金焊接接头盐雾腐蚀行为分析[J]. 焊接学报, 2011, 32(10): 17-20. Gou Guoqing, Huang Nan, Chen Hui, et al. Analysis on corrosion behavior of welded joint of A6N01-T5 aluminum alloy for high-speed train[J].Transactions of the China Welding Institution, 2011, 32(10): 17-20.
    [6] 路浩, 马子奇, 刘雪松, 等. 300 km/h高速列车车体残余应力超声波法无损测量[J]. 焊接学报, 2010, 31(8): 29-32. Lu Hao, Ma Ziqi, Liu Xuesong, et al. Ultrasonic residual stress measurement of 300 km/h high speed train body[J].Transactions of the China Welding Institution, 2010, 31(8): 29-32.
    [7] 路浩, 刘雪松, 孟立春, 等. 高速列车车体服役状态残余应力超声波法无损测量及验证[J]. 焊接学报, 2009, 30(4): 81-83. Lu Hao, Liu Xuesong, Meng Lichun, et al. Residual stress evaluation of high speed train body structure by ultrasonic method and verification[J]. Transactions of the China Welding Institution, 2009, 30(4): 81-83.
    [8] 苟国庆, 黄楠, 陈辉, 等. X射线衍射法测试高速列车车体铝合金残余应力[J]. 西南交通大学学报, 2012, 47(4): 618-622. Gou Guoqing, Huang Nan, Chen Hui, et al. Detection of residual stress in aluminum alloy carbody of high speed train using X-ray diffraction technology[J]. Journal of Southwest Jiaotong University, 2012, 47(4): 618-622.
    [9] European Committee for Standardization(CEN). DD ENV 1999-2:2000. Design of aluminum structures: part 2: structures susceptible to fatigue. brussels[S]. Brussels, Belgium. European Standards(ES), 1998.
    [10] 闫德俊. 高速列车底架用铝合金焊接接头疲劳裂纹扩展特性[D]. 哈尔滨: 哈尔滨工业大学博士学位论文, 2011.
