高频脉冲耦合铝合金激光-MIG复合焊接熔滴过渡及其熔覆特性

朱宗涛, 王雪飞, 杨晓益, 高健

朱宗涛, 王雪飞, 杨晓益, 高健. 高频脉冲耦合铝合金激光-MIG复合焊接熔滴过渡及其熔覆特性[J]. 焊接学报, 2016, 37(8): 39-44.
引用本文: 朱宗涛, 王雪飞, 杨晓益, 高健. 高频脉冲耦合铝合金激光-MIG复合焊接熔滴过渡及其熔覆特性[J]. 焊接学报, 2016, 37(8): 39-44.
ZHU Zongtao, WANG Xuefei, YANG Xiaoyi, GAO Jian. Droplet transfer in aluminum alloy laser-MIG hybrid welding coupled by high frequency pulses and its cladding characteristics[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(8): 39-44.
Citation: ZHU Zongtao, WANG Xuefei, YANG Xiaoyi, GAO Jian. Droplet transfer in aluminum alloy laser-MIG hybrid welding coupled by high frequency pulses and its cladding characteristics[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(8): 39-44.

高频脉冲耦合铝合金激光-MIG复合焊接熔滴过渡及其熔覆特性

基金项目: 国家自然科学基金资助项目(51405398);中央高校基本科研业务费专项资金资助项目(2682015CX007)

Droplet transfer in aluminum alloy laser-MIG hybrid welding coupled by high frequency pulses and its cladding characteristics

  • 摘要: 文中采用高频脉冲电源与单脉冲MIG焊电源并联叠加的方式与激光热源复合,形成高频脉冲耦合激光-MIG复合焊接方法.在A7N01铝合金板材上进行堆焊试验,用高速摄像研究高频脉冲耦合后电弧及熔滴过渡行为的变化,并通过金相观察研究高频脉冲耦合对熔覆层成形及组织的影响.结果表明,高频脉冲耦合后弧长增大,电弧电压增大、基值电流减小,峰值电流变化不大;熔滴由部分亚射流过渡转变成完全射流过渡;熔覆金属表面光滑,“鱼鳞纹”特征消失,无“指状”熔深问题;熔覆层晶粒大小变化不明显,但晶粒内部强化相颗粒变小,分布更加均匀.
    Abstract: High frequency pulses (HFPs) power source were parallelly connected with the power source of single-pulse mode MIG arc, which are applied to laser-MIG hybrid welding. The cladding on A7N01 aluminum alloy was executed to investigate the dynamics of droplet transfer and arc with the effects of coupled HFPs through high speed camera observation. The shaping-characteristic and microstructure of cladding layer were also studied by metallographic analysis. The results show that the arc length and voltage increase after HFPs being coupled. The base current of single pulse MIG arc decreases, while the peak current has little changes compared with that without HFPs coupling. In conventional laser-MIG hybrid welding, the droplets are partly transferred as meso-spray mode. The finger-penetration weld can be obtained, which probably causing defects in the weld root. After HFPs being coupled, partly meso-spray transfer changes to completely spray transfer. The surface of cladding layer becomes smoother with the disappearance of fish-scale pattern and finger-penetration depth. Although the grain size has no significant changes, the size of second phase particles becomes smaller and more uniformly distributed in grains as strengthened phase.
  • [1] 许良红, 田志凌, 彭云, 等. 高强铝合金的MIG以及激光-MIG焊接工艺对比[J]. 焊接学报, 2007, 28(2):38-43. Xu Lianghong, Tian Zhiling, Peng Yun, et al. Comparison of MIG welding and laser-MIG welding of high strength aluminum alloy[J]. Transactions of the China Welding Institution, 2007, 28(2):38-43.
    [2] Yan S H, Chen H, Ma C P, et al. Local corrosion behaviour of hybrid laser-MIG welded Al-Zn-Mg alloy joints[J]. Materials and Design, 2015, 88:1353-1365.
    [3] Ascari A, Fortunato A, Orazi L, et al. The influence of process parameters on porosity formation in hybrid LASER-GMA welding of AA6082 aluminum alloy[J]. Optics & Laser Technology, 2012, 44:1485-1490.
    [4] Campana G, Ascari A, Fortunato A, et al. Hybrid laser-MIG welding of aluminum alloys:The influence of shielding gases[J]. Applied Surface Science, 2009, 255:5588-5590.
    [5] 吴敏生, 段向阳, 李路明, 等. 电弧超声的激发及其特性研究[J]. 清华大学学报(自然科学版), 1999, 39(6):110-112. Wu Minsheng, Duan Xiangyang, Li Luming, et al. Study of arc-ultrasonic excitation and its characteristics[J]. Journal of Tsinghua University (Science and Technology). 1999, 39(6):110-112.
    [6] 吴敏生, 何龙标, 李路明, 等. 电弧超声焊接技术[J]. 焊接学报, 2005, 26(6):40-45. Wu Minsheng, He Longbiao, Li Luming, et al. Study of arc-ultrasonic welding technology[J]. Transactions of the China Welding Institution, 2005, 26(6):40-45.
    [7] 范成磊, 谢伟峰, 杨春利, 等. 超声-MAG复合焊接熔滴过渡受CO2含量的影响[J]. 焊接学报, 2015, 36(3):18-23. Fan Chenglei, Xie Weifeng, Yang Chunli, et al. Effect of CO2 content for droplet transfer in ultrasound-MAG hybrid welding[J]. Transactions of the China Welding Institution, 2015, 36(3):18-23.
    [8] 范成磊, 谢伟峰, 杨春利, 等. 铝合金超声-MIG焊接电弧行为[J]. 焊接学报, 2015, 35(1):5-9. Fan Chenglei, Xie Weifeng, Yang Chunli, et al. Characteristics of welding arc during ultrasound-MIG hybrid welding of aluminum alloy[J]. Transactions of the China Welding Institution, 2015, 35(1):5-9.
    [9] 朱宗涛, 陈辉, 李远星, 等. 一种超声场耦合激光-MIG共熔池铝合金焊接技术:中国, 2015101736623[P]. 2015-04-14.
    [10] 马少龙. MIG-超声复合焊接系统研究[D]. 南昌:南昌大学, 2014.
计量
  • 文章访问数:  464
  • HTML全文浏览量:  12
  • PDF下载量:  172
  • 被引次数: 0
出版历程
  • 收稿日期:  2015-06-03
