激光液态填充焊的填材熔化与过渡稳定性

彭进; 李俐群; 林尚扬; 邓洲; 张芙蓉

激光液态填充焊的填材熔化与过渡稳定性

1.
哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001
2.
哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001;机械科学研究院哈尔滨焊接研究所, 哈尔滨 150080

基金项目: 国家自然科学基金资助课题（51175115）

计量
- 文章访问数: 408
- HTML全文浏览量: 6
- PDF下载量: 274
出版历程
- 收稿日期: 2014-10-17

Melting of filler metal and transfer stability in laser welding with pre-melting liquid filler

1.
State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China
2.
State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China;Harbin Welding Institute, Harbin 150080, China

摘要

摘要: 针对激光填丝焊过程中焊丝对入射激光能量的反射、匙孔不稳定等问题，提出了激光液态填充焊方法，采用电弧提前预熔焊丝，让填材以液态方式流入熔池中.分析了激光液态填充焊的熔化、过渡模式，以及工艺参数对过渡模式的影响规律.结果表明，在电弧热作用下焊丝有液桥过渡和滴状过渡两种模式，焊接电流较小时，焊丝的上部熔化，下部依然保持固态，形成稳定的液桥过渡；焊接电流较大时，焊丝端部全部熔化易回缩成球为滴状过渡，过渡稳定性变差.为改善滴状过渡的稳定性，可依靠间隙的毛细作用稳定流入熔池中.激光液态填充焊可降低对匙孔的冲击，提高匙孔的稳定性.
- 激光焊接 /
- 液态填充焊 /
- 熔化与过渡 /
- 铝合金
Abstract: Laser welding with pre-melting liquid filler was developed to suppress the energy reflectivity of laser by filler wire and fluctuation of keyhole during welding process. The liquid filler was pre-melted by arc and then flowed into molten pool. The melting and transfer mode of laser welding with pre-melting liquid filler and the melting and filling characteristics under different process parameters was investigated. The results show that two kinds of transition modes occurred, i.e. liquid bridge transfer and droplet transfer. During laser welding, the upper filler wire was melted and the bottom part remained unchanged at small welding current. On the contrary, droplets formed at the filler wire tip at large welding current, the transfer stability became worse. To improve the stability of droplet transfer, the liquid filler could flow into the molten pool with the help of capillary. The stability of keyhole was improved because the impact of liquid filler on the keyhole was suppressed during laser welding with pre-melting filler wire.
- laser welding /
- welding with pre-melting liquid filler /
- melting and transfer /
- aluminum alloy

HTML全文

参考文献(8)

[1]	何恩光,巩水利,杨涛,等.5A90铝锂合金T形接头激光填丝焊接头组织性能分析[J].焊接学报,2013,34(9):99-102.He Enguang,Gong Shuili,Yang Tao,et al. Microstructure and properties of 5A90 Al-Li alloy T-joints by laser welding with filler wire[J].Transactions of the China Welding Institution,2013,34(9):99-102.
[2]	彭进,李俐群,林尚扬,等.铝合金液态填充焊的工业特性分析[J].焊接学报,2014,35(10):45-48.Peng Jin,Li Liqun,Lin Shangyang,et al.Welding characteristics of aluminum alloy with pre-melting liquid filler[J].Transactions of the China Welding Institution,2014,35(10):45-48.
[3]	蔡华,林凯莉,肖荣诗.薄板2524铝合金激光填丝焊接工艺及组织性能[J].焊接学报,2014,35(4):24-28.Cai Hua,Lin Kaili,Xiao Rongshi.Process and microstructure properties of laser beam welding of thin 2524 aluminum alloy sheet with filler wire[J].Transactions of the China Welding Institution,2014,35(4):24-28.
[4]	Salminen A.The filler wire-laser beam Interaction during laser welding with low alloyed steel filler wire[J].Mechanika,2010,4(84):67-74.
[5]	Salminen A S,Kujanpää VP.Effect of wire feed position on laser welding with filler wire[J].Journal of Laser Applications,2003,15(1):2-10.
[6]	Salminen A S,Kujanpää V P,Moisio T JI.Interactions between laser beam and filler metal[J].Welding Journal,1996,75(1):9-13.
[7]	刘雅静,宋丙新,范光辉.激光热丝焊焊接工艺参数的优化分析与实验研究[J].应用激光,2013,33(6):606-611.Liu Yajing,Song Bingxin,Fan Guanghui.Optimization analysis and experimental study of laser hot wire welding technology parameters[J].Applied Laser,2013,33(6):606-611.
[8]	Masoud Harooni,Blair Carlson,Radovan Kovacevic.Dual-beam laser welding of AZ31B magnesium alloy in zero-gap lap joint configuration[J].Optics and Laser Technology,2014,56:247-255.
