Sn-9Zn/Cu无铅焊点ZnO须自发生长

张亮; 杨帆; 郭永环; 钟素娟; 马佳; 鲍丽

Sn-9Zn/Cu无铅焊点ZnO须自发生长

1.
江苏师范大学机电工程学院, 徐州 221116
2.
郑州机械研究所新型钎焊材料与技术国家重点实验室, 郑州 450001

基金项目: 国家自然科学基金项目（51475220）；新型钎焊材料与技术国家重点实验室开放课题（SKLABFMT-2015-03）

计量
- 文章访问数: 458
- HTML全文浏览量: 7
- PDF下载量: 239
出版历程
- 收稿日期: 2015-12-28

Spontaneous growth of ZnO whiskers in Sn-9Zn/Cu lead-free solder joints

1.
School of Mechanical & Electrical Engineering, Jiangsu Normal University, Xuzhou 221116, China
2.
State Key Laboratory of Advanced Brazing Filler Metals & Technology, Zhengzhou Research Institute of Mechanical Engineering, Zhengzhou 450001, China

摘要

摘要: 研究了Sn-9Zn/Cu无铅焊点ZnO须自发生长行为.结果表明，在室温条件下Sn-9Zn/Cu无铅焊点因为富锌相的氧化，在富锌相表面自发生长出大量的ZnO须，ZnO须呈现针状、块状、花朵状等不同形态；对ZnO须进行FIB测试，发现在富锌相中出现明显的空洞，主要是因为Zn元素扩散导致的.另外，证实在Zn元素扩散与氧发生反应的过程中，富锌相发生体积收缩，诱使结构中出现明显的拉应力，拉应力为ZnO须生长提供驱动力.
- 无铅焊点 /
- 富锌相 /
- ZnO须 /
- 拉应力
Abstract: Spontaneous growth of ZnO whiskers in Sn-9Zn/Cu lead-free solder joints was investigated. The results indicate that due to the oxidation of rich-Zn phases at room temperature, ZnO whisker will spontaneously grow on the surface of Zn-rich phase in Sn-9Zn/Cu lead-free solder joints, and these whiskers showed different morphologies like needle-type, bulk-type and flower-type, etc. Based on FIB test of ZnO whisker, it was found that voids appeared in the Zn-rich phase, which was induced by the diffusion of Zn atoms. In addition, during reaction between Zn and O, volume shrinkage of Zn-rich phase might happen, and the tensile stress could be generated in the structure which was the driving force of ZnO whisker growth.
- lead-free solder joints /
- rich-Zn phases /
- ZnO whiskers /
- tensile stress

HTML全文

参考文献(15)

[1]	张亮,孙磊,郭永环,等.低银Sn1.0Ag0.5Cu焊点疲劳寿命预测[J].东南大学学报(自然科学版),2015,45(4):668-672.Zhang Liang,Sun Lei,Guo Yonghuan,et al.Fatigue life prediction of low-silver Sn1.0Ag0.5Cu solder joints[J].Journal of Southeast University (Natural Science Edition),2015,45(4):668-672.
[2]	Zhang L,Tu K N.Structure and properties of lead-free solders bearing micro and nano particles[J].Materials Science&Engineering:R:Reports,2014,82:1-32.
[3]	薛鹏,薛松柏,沈以赴,等.温度与镀层对Sn-Zn-Ga-Nd钎料润湿性能的影响[J].焊接学报,2013,34(8):31-34.Xue Peng,Xue Songbai,Shen Yifu,et al.Effect of temperature and coatings on the wettabilityof Sn-Zn-Ga-Nd lead-free solder[J].Transactions of the China Welding Institution,2013,34(8):31-34.
[4]	Zhang L,Sun L,Guo Y H,et al.Reliability of lead-free solder joints in CSP device under thermal cycling[J].Journal of Materials Science:Materials in Electronics,2014,25(3):1209-1213.
[5]	Zhou J,Huang D,Fang Y L,et al.Investigation on properties of Sn-8Zn-3Bi lead-free solder by Nd addition[J].Journal of Alloys and Compounds,2009,480:903-907.
[6]	肖正香.稀土Pr对Sn-9Zn无铅钎料组织和性能[D].南京:南京航空航天大学,2011.
[7]	Zhang L,Han J G,He C W,et al.Microstructures and properties of SnZn lead-free solder joints bearing La for electronic packaging[J].IEEE Transactions on Electron Devices,2012,59(12):3269-3272.
[8]	Ye H,Xue S B,Pecht M.Evaluation of the microstructure and whisker growth in Sn-Zn-Ga solder with Pr content[J].Journal of Materials Research,2012,27(14):1887-1894.
[9]	Zhang L,Xue S B,Gao L L,et al.Development of Sn-Zn lead-free solders bearing alloying elements[J].Journal of Materials Science:Materials in Electronics,2010,21(1):1-15.
[10]	Jiang J X,Lee J E,Kim K S,et al.Oxidation behavior of Sn-Zn solders under high-temperature and high-humidity conditions[J].Journal of Alloys and Compounds,2008,462:244-251.
[11]	Kim K S,Matsuura T,Suganuma K.Effects of Bi and Pb on oxidation in humidity for low-temperature lead-free solder systems[J].Journal of Electronic Materials,2006,35(1):41-47.
[12]	Tu K N,Hsiao H Y,Chen C.Transition from flip chip solder joint to 3D IC microbump:its effect on microstructure anisotropy[J].Microelectronics Reliability,2013,53(1):2-6.
[13]	魏秀琴,周浪,黄惠珍.氧化对Sn-Zn系无铅焊料润湿性的影响[J].中国有色金属学报,2009,19(1):174-178.Wei Xiuqin,Zhou Liang,Huang Huizhen.Effects of oxidation on wettability of Sn-Zn alloys[J].The Chinese Journal of Nonferrous Metals,2009,19(1):174-178.
[14]	Zhang L,Sun L,Han J G,et al.Sizes effect of CeSn₃ on the whiskers growth of SnAgCuCe solder joints in electronic packaging[J].Journal of Materials Science:Materials in Electronics,2015,26(8):6194-6197.
[15]	Kim K S,Kim J H,Han S W.The effect of postbake treatment on whisker growth under high temperature and humidity conditions on tin-plated Cu substrates[J].Materials Letters,2008,62:1867-1870.
