基于体壳耦合模型的钛合金薄板激光焊接变形分析

陈中革, 郭涛, 张建勋

陈中革, 郭涛, 张建勋. 基于体壳耦合模型的钛合金薄板激光焊接变形分析[J]. 焊接学报, 2016, 37(5): 45-48.
引用本文: 陈中革, 郭涛, 张建勋. 基于体壳耦合模型的钛合金薄板激光焊接变形分析[J]. 焊接学报, 2016, 37(5): 45-48.
CHEN Zhongge, GUO Tao, ZHANG Jianxun. Analysis on laser welding deformation of titanium alloy thin plate based on solid-shell coupling model[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(5): 45-48.
Citation: CHEN Zhongge, GUO Tao, ZHANG Jianxun. Analysis on laser welding deformation of titanium alloy thin plate based on solid-shell coupling model[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(5): 45-48.

基于体壳耦合模型的钛合金薄板激光焊接变形分析

基金项目: 国家自然科学基金资助项目(51375370)

Analysis on laser welding deformation of titanium alloy thin plate based on solid-shell coupling model

  • 摘要: 针对钛合金薄板激光焊接变形的数值模拟提出了一种高效体壳耦合模型,即在近缝区采用实体单元以充分表征焊接过程中板材厚度方向的热/力学不均匀性,在远离焊缝区采用壳单元建模以减小单元数量,在两种单元的界面建立接触并采用MPC算法进行焊接变形计算. 采用体壳耦合模型与三维实体模型分别计算了0.8 mm厚TC1钛合金激光焊接变形. 结果表明,两种模型的计算值均与试验测量值相近,但体壳耦合模型耗时仅为三维实体模型的30%左右,表明体壳耦合模型在保证计算精度的前提下能显著提高计算效率.
    Abstract: An efficient solid-shell coupling model was proposed to simulate laser welding deformation of titanium alloy thin plate. The elements used in the region near the weld seam were solid elements to characterize the thermal/mechanical nonuniformity along plate thickness during welding process, while the elements used in the region away from the weld zone were shell elements to reduce the number of the elements. Contacts were established at the interface of solid and shell elements, and welding deformation was calculated using MPC algorithm. Laser welding deformation of TC1 titanium alloy with 0.8 mm in thickness was simulated by solid-shell coupling model and three-dimensional solid model, respectively. The simulated results indicate that the calculation results of the two models both match well with the experimental deformation. The calculation time of solid-shell coupling model is about 30% of the three-dimensional solid model. So it can be concluded that the solid-shell coupling model can not only predict the welding deformation accurately in the welding process, but also improve the computational efficiency.
  • [1] Gao Xiaolong, Zhang Linjie, Liu Jing, et al. A comparative study of pulsed Nd YAG laser welding and TIG welding of thin Ti6Al4V titanium alloy plate[J]. Materials Science & Engineering A, 2013, 559(1): 14-21.
    [2] 方修洋, 刘 宏, 郭 涛, 等. 激光焊工艺对Ti-2Al-1.5Mn钛合金薄板焊接变形的影响[J]. 焊接, 2013(6): 26-29. Fang Xiuyang, Liu Hong, Guo Tao, et al. Effect of laser welding process on welding deformation of thin plate of Ti-2Al-1.5Mn titanium alloy[J]. Welding Joining, 2013(6): 26-29.
    [3] 陆 皓, 陈俊梅, 陈家本. 薄板结构焊接变形数值模拟及其应用[J]. 电焊机, 2007, 37(6): 71-74. Lu Hao, Chen Junmei, Chen Jiaben. Bucking distortion prediction model and application in welded thin plate[J]. Electric Welding Machine, 2007, 37(6): 71-74.
    [4] 刘 川, 张建勋. 基于动态子结构的三维焊接残余应力变形数值计算[J]. 焊接学报, 2008, 29(4): 21-24. Liu Chuan, Zhang Jianxun.Numerical simulation of welding stresses and distortions based on 3D dynamic substructure method[J]. Transactions of the China Welding Institution, 2008, 29(4): 21-24.
    [5] 蔡志鹏, 赵海燕, 鹿安理, 等. 焊接数值模拟中分段移动热源模型的建立及应用[J]. 机械工程学报, 2002, 13(3): 208-210. Cai Zhipeng, Zhao Haiyan, Lu Anli, et al. Establishment of line-Gauss heat source model and application in welding numerical simulation[J]. China Mechanical Engineering, 2002, 13(3): 208-210.
    [6] Tsirkas SA, Papanikos P, Pericleous K, et al. Evaluation of distortions in laser welded shipbuilding parts using local-global finite element approach[J]. Science and Technology of Welding Joining,2003, 8(2): 79-88.
    [7] Ferro P,Bonollo F, Tiziani A. Laser welding of copper-nickel alloys: a numerical and experimental analysis[J]. Science and Technology of Welding & Joining, 2005, 10(3): 299-310.
    [8] 祝金丹, 陈 虎, 巩建鸣, 等. 壳单元应用于薄板多道焊焊接数值模拟的方法探讨[J]. 焊接学报, 2008, 29(11): 105-109. Zhu Jindan, Chen Hu, Gong Jianming, et al. Discussion on numerical simulation of multi-pass welding of thin-plate based on shell element[J]. Transactions of the China Welding Institution, 2008, 29(11): 105-109.
    [9] 吴东江, 杨义彬, 马广义, 等. HastelloyC-276超薄板激光焊接变形的数值模拟[J]. 光学学报, 2011, 31(sl): sl00414. Wu Dongjiang, Yang Yibin, Ma Guangyi, et al. Numerical simulation of welding distortion in pulsed laser welding of hastelloy C-276 thin sheet[J]. Acta Optica Sinica, 2011, 31(s1): sl00414.
    [10] Wahab M A, Painter M J. Numerical models of gas metal arc welds using experimentally determined weld pool shapes as the representation of the welding heat source[J]. International Journal of Pressure Vessels and Piping, 1997, 73(2):153-159.
    [11] 宋小龙, 安继儒. 新编中外金属材料手册[M]. 北京: 化学工业出版社, 2012.
计量
  • 文章访问数:  442
  • HTML全文浏览量:  20
  • PDF下载量:  508
  • 被引次数: 0
出版历程
  • 收稿日期:  2014-07-19
