表面毛化不锈钢与纯铝的真空扩散连接

刘海, 张丽霞, 任伟, 冯吉才

刘海, 张丽霞, 任伟, 冯吉才. 表面毛化不锈钢与纯铝的真空扩散连接[J]. 焊接学报, 2016, 37(5): 41-44.
引用本文: 刘海, 张丽霞, 任伟, 冯吉才. 表面毛化不锈钢与纯铝的真空扩散连接[J]. 焊接学报, 2016, 37(5): 41-44.
shu
LIU Hai, ZHANG Lixia, REN Wei, FENG Jicai. Vacuum diffusion bonding of surface textured stainless steel and aluminum[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(5): 41-44.
Citation: LIU Hai, ZHANG Lixia, REN Wei, FENG Jicai. Vacuum diffusion bonding of surface textured stainless steel and aluminum[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2016, 37(5): 41-44.
shu

表面毛化不锈钢与纯铝的真空扩散连接

  • 哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001

基金项目: 教育部新世纪优秀人才资助项目(NCET-12-0155);哈尔滨工业大学科研创新基金资助项目(HIT. NSRIF. 2010115)

Vacuum diffusion bonding of surface textured stainless steel and aluminum

  • State Key Lab of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要

    摘要
  • 摘要: 采用冷金属过渡技术(CMT)对不锈钢表面进行毛化,在其表面制备高度为3 mm、分布密度为9个/cm2的毛刺,毛刺中心横向及纵向间距均为3 mm. 研究其与纯铝进行真空扩散连接接头的界面组织和性能,分析不同保温时间对接头组织和性能的变化规律. 结果表明,在扩散连接温度为600 ℃,保温时间为60 min,压力为3 MPa的工艺条件下,表面毛刺刺入铝母材内部,使得表面氧化膜有效去除,接头形成连续的Fe2Al5+FeAl3界面反应层,相比不锈钢与纯铝的直接真空扩散连接,接头拉剪强度显著提高. 此外,在扩散连接温度一定时,随保温时间的增加,反应层厚度增加,接头拉剪强度呈现先增大后减小的变化趋势.
    Abstract: Using cold metal transfer (CMT) technology to achieve stainless steel surface texturing, a 3mm-high burr on the surface, whose distribution density is 9/cm2, is obtained. Horizontal and vertical spacing of the burr centers are both 3 mm. vacuum diffusion bonding interface structure with aluminum under different holding time and studied changes in the organization and strength performance of the joint is analyzed. The results show that when the diffusion bonding temperature is 600 ℃, holding time is 60min, pressure is 3 MPa, the burrs penetrate inside the aluminum, which effectively remove the surface oxide film and help form a continuous joint Fe2Al5/FeAl3 interface reaction layer. Compared to direct vacuum diffusion bonded stainless steel and aluminum, the tensile shear strength improved significantly. It found that when diffusion bonding temperature is constant, with increasing holding time, the reaction layer thickness increases. But when the holding time is too long, there is macroscopic deformation in the aluminum and therefore joint strength had a trend of first increasing and then decreasing with the increase of holding time.
    • HTML全文
    • 参考文献(11)
  • [1] 张丽娜, 刘 敏, 蒋继英, 等. 铝及铝合金与钢的连接技术研究现状[J]. 航天制造技术, 2013(2): 5-8. Zhang Lina, Liu Min, Jiang Jiying, et al. The development of welding of aluminum alloy and steel[J]. Aerospace Manufacturing Technology, 2013(2): 5-8.
    [2] 肖亚庆. 铝加工技术实用手册[M]. 北京: 冶金工业出版社, 2005.
    [3] 李亚江. 轻金属焊接技术[M]. 北京: 国防工业出版社, 2011.
    [4] 李 红, 韩静涛. 不锈钢与铝蜂窝夹芯板的液相扩散连接[J]. 北京科技大学学报, 2006, 28(2): 138-142. Li Hong, Han Jingtao. Interlayer design and its effect on the liquid diffusion of steel-Al honeycomb sandwich panels[J]. Journal of University of Science and Technology Beijing, 2006, 28(2): 138-142.
    [5] Larsson J K. Overview of joining technologies in the automotive industry[J]. Welding Research Abroad. 2003, 49(6-7): 29-45.
    [6] 林三宝, 马广超, 宋建岭, 等. 铝合金/镀锌钢TIG熔钎焊接头界面组织及力学性能[J]. 焊接, 2009(2): 34-37. Lin Sanbao, Ma Guangchao, Song Jianling, et al. Microstructure and mechanical properties on dissimilar metals TIG welding-brazing joint of aluminum alloy to galvanized steel[J]. Welding&Joining, 2009(2): 34-37.
    [7] 黄鹏飞, 卢振洋, 高文宁, 等. 钢铝异种金属的低能量焊接法[J]. 机械工程学报, 2009, 45(11): 295-298. Huang Pengfei, Lu Zhenyang, Gao Wenning, et al. Low energy welding technology in bonding steel with aluminum[J]. Journal of Mechanical Engineering, 2009, 45(11): 295-298.
    [8] 钱乙余, 董占贵, 石素勤, 等. 铝接触反应钎焊的成缝行为[J]. 焊接学报, 2001, 22(5): 13-16. Qian Yiyu, Dong Zhanggui, Shi Suqin, et al. Behavior of aluminum contact reactive brazing[J]. Transactions of the China Welding Institution, 2001, 22(5): 13-16.
    [9] 何 鹏, 冯吉才, 钱乙余, 等. 接触反应法解决铝/不锈钢钎焊的缺陷及脆性[J]. 材料科学与工艺, 2005, 13(1): 82-85. He Peng, Feng Jicai, Qian Yiyu, et al. Resolve of fragile and defect problem for a new contact reaction brazing aluminum to stainless steel[J]. Material Science and Technology, 2005, 13(1): 82-85.
    [10] 李妙珍. 关于铝及铝合金的焊接工艺浅析[J]. 轻金属. 2007, (9): 66-69. Li Miaozhen. Analysis of aluminum and aluminum alloy welding technology[J]. Light Metals, 2007(9): 66-69.
    [11] 王 敬. Fe/Al异种金属扩散焊界面形成机理研究[D]. 镇江: 江苏科技大学硕士学位论文, 2012.
