熔融金属填充焊接工艺试验系统设计

Research on experimental system of welding process with molten metal filler

State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要: 为了解决目前弧焊工艺中热输入难以控制的问题,适应高效化生产的需求,提出了一种熔融金属填充焊接新工艺. 重点介绍了方法的试验系统构成原理及各组成部分的设计. 利用锡铅合金为试验材料,对系统进行堆焊验证试验. 试验证明系统能够很好的控制液流的温度和直径、焊接速度以及气体压力,实现对焊接过程中焊接热输入的精确控制. 结果表明,该装置能够实现熔融金属填充焊接工艺的试验要求,利用该系统得到的焊缝深宽比最大能够达到6.
- 熔融金属填充 /
- 高频电源 /
- 石墨坩埚 /
- 锡铅合金 /
- 深宽比
Abstract: A novel welding process with molten metal filler is invented to solve the problem of controlling the welding heat input and to suit the require of high-efficient manufacture. The design and principle of welding system and its elements are mainly introduced. Meanwhile, testing the system by overlaying weld using tin-lead alloy. The results show that the system accurately control welding heat input by output steady flow with required temperature and diameter, welding speed and air pressure. Therefore, the system could meet the requirement of welding process with molten metal filler, and the depth-to-width ratio of bead can reach 6 by using it.
- molten metal filler /
- high-frequency power supply /
- graphite crucible /
- tin-lead alloy /
- depth-to-width ratio

[1]	李陈宾, 刘黎明. 激光-电弧复合热源焊接钛合金薄板T形结构件[J]. 焊接学报, 2012, 33(1): 29-32. Li Chenbin, Liu Liming. Laser-arc hybrid welding of T-type structure of titanium sheet[J]. Transactions of the China Welding Institution, 2012, 33(1): 29-32.
[2]	Li K H, Chen J, Zhang Y M. Double-electrode GMAW process and control[J]. Welding Journal, 2007, 86(8): 231-237.
[3]	Li K H, Zhang Y M. Metal transfer in double-electrode gas metal arc welding[J]. Journal of Manufacturing Science and Engineering Transactions of the ASME, 2007, 129(6): 991-999.
[4]	曹梅青. 双丝间接电弧气体保护焊研究[D]. 济南: 山东大学, 2006.
[5]	Lytle A R, Frost E L. Submerged-melt welding with multiple electrodes in series[J]. Welding Journal, 1951, 30(2): 103-110.
[6]	彭云, 许良红, 田志凌, 等. 焊接热输入对高强铝合金接头组织和性能的影响[J]. 焊接学报, 2008, 29(2): 17-21. Peng Yun, Xu Lianghong, Tian Zhiling, et al. Effect of heat input on microstructure and mechanical properties of the high strength aluminum alloy welds[J]. Transactions of the China Welding Institution, 2008, 29(2): 17-21.
[7]	张传臣, 陈芙蓉, 高云喜. 7A52铝合金单双丝焊工艺对比分析[J]. 焊接学报, 2008, 29(9): 67-70. Zhang Chuanchen, Chen Furong, Gao Yunxi. Analysis on single and double wire welding technology of 7A52 aluminum alloy[J]. Transactions of the China Welding Institution, 2008, 29(9): 67-70.
