基于HHT和Cohen核的磁控焊缝跟踪信号分析

洪波; 徐爱军; 柳健; 李湘文

基于HHT和Cohen核的磁控焊缝跟踪信号分析

1.
湘潭大学复杂轨迹加工工艺及装备教育部工程研究中心, 湘潭 411105
2.
中国人民解放军76117部队, 衡阳 421002

基金项目: 国家自然科学基金资助项目(51405414);湖南省自然科学省市联合基金资助项目(2015JJ5013);湖南高校科技创新团队项目资助

计量
- 文章访问数: 342
- HTML全文浏览量: 16
- PDF下载量: 235
出版历程
- 收稿日期: 2014-02-24

Signal analysis of magnetic control seam tracking based on HHT and Cohen nuclear

1.
Institute of Mechanical Engineering, Xiangtan University, Xiangtan 411105, China

摘要

摘要: 针对磁控焊缝跟踪信号的非线性不平稳特点,提出了一种基于Hilbert-Huang变换和Cohen核的磁控电弧传感器焊缝跟踪系统的信号提取分析方法;运用经验模态分解,把周期激励下磁控跟踪信号分解成多个从高频到低频的本征模态函数分量,依据各分量的Hilbert边际谱,采用Cohen核分布的时频变换,能有效抑制交叉项,提取出磁控焊缝跟踪实时信号动态规律. 结果表明,利用此方法有助于更深入地揭示焊缝自动跟踪系统内各种干扰源的时频和频谱特征,为建立有激励源的焊接信号新的非线性模型提供了理论依据.
- 磁控电弧传感器 /
- 信号分析 /
- 希尔伯特-黄变换 /
- 经验模态分解
Abstract: Since to the feature of the magnetic control seam tracking signal is nonlinearly and not smooth, A signal extraction and analytical method of the system based on Hilbert Huang transform and Cohen nuclear magnetic control arc seam tracking sensor is propesed. The magnetic control to track the signal motivated by cycle is decomposed into several intrinsic mode functions from high frequency to low frequency component by using the empirical mode decomposition. On the basis of the Hilbert marginal spectrum of each component, using Cohen nuclear distribution of time-frequency transform to each component can effectively restrain cross terms and extract the real-time signal dynamic law reflecting magnetic control seam tracking. The test result manifest this method is contribute to reveal the time-frequency of interference source and frequency spectrum.
- magnetic control arc seam tracking sensor /
- signal analysis /
- Hilbert Huang transform /
- the empirical mode decomposition

HTML全文

参考文献(6)

[1]	罗怡, 伍光凤, 李春天. Choi-Williams时频分布在CO₂焊接电信号检测中的应用[J]. 焊接学报, 2008, 29(2): 101-104. Luo Yi, Wu Guangfeng, Li Chuntian. Application of Choi-Williams distribution to electrical signals detection in CO₂ arc welding[J]. Transactions of the China Welding Institution, 2008, 29(2): 101-104.
[2]	沈毅, 沈志远. 一种非线性非平稳自适应信号处理方法-希尔伯特-黄变换综述: 发展与应用[J]. 自动化技术与应用, 2010, 29(5): 1-5. Shen Yi, Shen Zhiyuan. A review of the nonlinear nonstationary adaptive signal processing method-hilbert-huang transform: its development and applications[J]. Techniques of Automation and Applications, 2010, 29(5): 1-5.
[3]	洪波, 魏复理, 来鑫, 等. 一种用于焊缝跟踪的磁控电弧传感器[J]. 焊接学报, 2008, 29(5): 1-4. Hong Bo, Wei Fuli, Lai Xin, et al. A magnetic control arc sensor for seam-tracking[J]. Transactions of the China Welding Institution, 2008, 29(5): 1-4.
[4]	Huang N E, Shen Z, Long S R. The empirical mode decomposition and the Hilbert spectrum for nonlinear andnonstationary time series analysis[J]. Proceedings of the Royal Society of London A, 1998, 454: 903-995.
[5]	Zhao H W, Huang N E.Ensemble empirical mode decomposition: a noise assisted data analysis method[J]. Advances in Adaptive Data Analysis, 2009, 1(1): 1-41.
[6]	Yang J N, Lei Y. Identification of natural frequencies and damping ratios of linear structures via Hilbert transform and empirical mode decomposition[C]// Proceedings of International Conference on Intelligent Systems and Control, IASTED/Acta Press, Anaheim, CA, 1999: 310-315.
