多场耦合条件下SnAgCu/Cu界面化合物生长行为

许媛媛, 闫焉服, 李帅, 赵永猛

许媛媛, 闫焉服, 李帅, 赵永猛. 多场耦合条件下SnAgCu/Cu界面化合物生长行为[J]. 焊接学报, 2015, 36(10): 44-48.
引用本文: 许媛媛, 闫焉服, 李帅, 赵永猛. 多场耦合条件下SnAgCu/Cu界面化合物生长行为[J]. 焊接学报, 2015, 36(10): 44-48.
XU Yuanyuan, YAN Yanfu, LI Shuai, ZHAO Yongmeng. Growth behavior of intermetallic compounds between SnAgCu and Cu substrate under multiphysics field coupling[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(10): 44-48.
Citation: XU Yuanyuan, YAN Yanfu, LI Shuai, ZHAO Yongmeng. Growth behavior of intermetallic compounds between SnAgCu and Cu substrate under multiphysics field coupling[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(10): 44-48.

多场耦合条件下SnAgCu/Cu界面化合物生长行为

基金项目: 国家自然科学基金资助项目(51175151)

Growth behavior of intermetallic compounds between SnAgCu and Cu substrate under multiphysics field coupling

  • 摘要: 基于自制的多场耦合热循环装置,研究了Sn-3.0Ag-0.5Cu/Cu钎焊接头热循环过程中界面金属间化合物(IMC)微观组织变化和断裂行为. 结果表明,在多场耦合及30~150 ℃热疲劳循环下,随着循环周期的增加,界面IMC厚度越来越厚,且在较短循环时间内IMC的形貌由扇贝状转变为层状,400周期后界面化合物的厚度增长变缓;当循环周期达到600时,界面上空洞聚集长大,产生界面开裂,进而导致疲劳失效. 同时随着循环周期增加,接头的抗剪强度也逐渐下降,也有脆性断裂的趋势.
    Abstract: Based on the home-made multiphysics field coupling device, investigation was carried on the fracture behavior and the growth of intermetallic compounds (IMC) at the interface between Sn-3.0Ag-0.5Cu lead-free solder and Cu substrate. The results show that in the multiphysics field and 30-150 ℃ thermal fatigue cycles,the more the thermal fatigue cycles, the faster the IMC grows in the same aging temperature. The morphology of IMC changes from the scallop shape into the layered shape in a shorter cycle time. The growth of IMC is slowing down after 400 cycles. When the cycles are 600, the void gathered and grow up, resulting in interface cracks and fatigure failure. With the increasing thermal cycles, the shear strength of joint drops quickly and it also has a tendency to brittle fracture.
  • [1] 于大全, 段莉蕾, 赵 杰. Sn-3.5Ag/Cu界面金属间化合物的生长行为研究[J]. 材料科学与工艺, 2005, 13(5): 533-536. Yu Daquan, Duan Lilei, Zhao Jie. The growth behaviors of intermetallic compounds between Sn-3.5Ag and Cu substrate[J]. Materials Science and Technology, 2005, 13(5): 533-536.
    [2] Frear D R. The mechanical behavior of interconnect materials for electronic packaging[J]. JOM, 1996, 48(5): 49-53.
    [3] Shang J K, Yao D. Effect of interface roughness on fatigue crack growth in Sn-Pb solder joints[J]. Joumal of Electronic Packaging, 1996, 118(3): 170-173.
    [4] Li X Y, Li F H, Guo F. Effect of isothermal aging and thermal cycling on interfacial IMC growth and fracture behavior of SnAgCu/Cu joints[J]. Journal of Electronic Materials, 2011, 40(1): 51-57.
    [5] Xu L H, John H.L.Pang, F X Che. Impact of thermal cycling on Sn-Ag-Cu solder joints and board-level drop reliability[J]. Journal of Electronic Materials, 2008, 37(6): 881-886.
    [6] 齐丽华, 黄继华, 张建纲, 等. 热-剪切循环条件下Sn-3.5Ag-0.5Cu/Cu(Ni)界面化合物生长行为研究[J]. 稀有金属材料与工程, 2007, 36(2): 241-244. Qi Lihua, Hua Jihua, Zhang Jiangang, et al. Growth behaviors of intermetallic compounds on Sn-3.5Ag-0.5Cu/Cu(Ni) interface under thermal-shearing cycling condition[J]. Rare Metal Metals and Engineering, 2007, 36(2): 241-244.
    [7] 赵 杰, 朱 凤, 尹德国, 等. 强磁场下Sn-3Ag-0.5Cu/Cu界面金属间化合物生长行为[J]. 大连理工学报, 2006, 46(2): 203-206. Zhao Jie, Zhu Feng, Yin Deguo, et al. Growth behavior of intermetallic compound layer at Sn-3Ag-0.5Cu/Cu interface under high magnetic field[J]. Journal of Dalian University of Technology, 2006,46(2): 203-206.
    [8] 姚 健, 卫国强, 石永华, 等.电迁移极性效应及其对Sn-3.0Ag-0.5Cu无铅焊点拉伸性能的影响[J]. 中国有色金属学报, 2011, 21(12): 3094-3099. Yao Jian, Wei Guoqiang, Shi Yonghua, et al. Polarity effect of electromigration and its influence on tensile properties of Sn-3.0Ag-0.5Cu lead-free solder joint[J]. The Chinese Journal of Nonferrous Metals, 2011, 21(12): 3094-3099.
    [9] Chiu T C, Zeng K, Stierman R, Edwards D, Ano K. Effect of thermal aging on board level drop reliability for Pb-free BGA packages[C]// Proceeding of Electronic Components and Technology Conference(ECTC2004), USA, Institute of Electrical and Electronics Inc, 2004, 1257-1262.
    [10] 张柯柯, 韩丽娟, 王要利, 等. Sn2.5Ag0.7CuxRE钎料时效焊点界面IMC研究[J]. 材料工程, 2010, 37(10): 18-21. Zhang Keke, Han Lijuan, Wang Yaoli, et al. Research of intermetallic compounds at interface of Sn2.5Ag0.7CuxRE solder joints during aging[J]. Journal of Matreials Engineering. 2010, 37(10): 18-21.
    [11] 刁 慧, 王春青, 赵振清, 等. SnCu钎料镀层与Cu/Ni镀层钎焊接头的界面反应[J]. 中国有色金属学报, 2007, 17(3): 410-416. Diao Hui, Wang Chunqing, Zhao Zhenqing, et al. Interfacial reactions between Sn-Cu solder alloy and Cu/Ni coatings during reflow soldering[J]. The Chinese Journal of Nonferrous Metals, 2007, 17(3): 410-416.
    [12] 田艳红, 杨世华, 王春青, 等. Sn3.0Ag0.5Cu/Cu无铅焊点剪切断裂行为的体积效应[J]. 金属学报, 2010, 46(3): 366-371. Tian Yanhong, Yang Shihua, Wang Chunqing, et al. Volume effect of shear fracture behavior of Sn3.0Ag0.5Cu/Cu lead-free solder joints[J]. Acta Metallurgica Sinica, 2010, 46(3): 366-371.
    [13] Yang Shihua, Lin Pengrong, Tian Yanhong, et al. Effect of solder volume on shear strength between Sn-3.0Ag-0.5Cu solder and Cu metallization[C]// 2007 International Conference on Electronics Packaging Technology, USA, Institute of Electrical and Electronics Inc, 2007, 756-758.
    [14] 韦习成, 鞠国魁, 孙 鹏, 等. 高温、高湿环境中时效时Sn-Zn基无铅焊点的显微组织演化[J]. 中国有色金属学报, 2006, 16(7): 1177-1183. Wei Xicheng, Ju Guokui, Sun Peng, et al. Microstructureevolution of Sn-Zn based lead-free solder joints aged in humid atmosphere at high temperature[J]. The Chinese Journal of Nonferrous Metals, 2006, 16(7): 1177-1183.
