热输入对C300接头温度场及焊缝胞晶组织的影响

杨帅; 彭云; 张晓牧; 董华利; 田志凌

热输入对C300接头温度场及焊缝胞晶组织的影响

1.
中铁物总技术有限公司, 北京 100036
2.
钢铁研究总院先进钢铁流程及材料国家重点实验室, 北京 100081

基金项目: 国家重点基础研究发展计划资助项目(973计划,2010-CB630800)

计量
- 文章访问数: 365
- HTML全文浏览量: 2
- PDF下载量: 184
出版历程
- 收稿日期: 2015-03-18

Influence of heat input on welding temperature fields and cellular microstructure of C300 welded joints

1.
China Railway Materials Technologies Company Limited, Beijing 100036, China
2.
State Key Laboratory of Advanced Steel Processes and Products, Central Iron and Steel Research Institute, Beijing 100081, China

摘要

摘要: 通过数值计算和组织观察,分析了热输入对马氏体时效钢(C300)钨极氩弧焊焊接接头温度场及焊缝胞晶组织的影响. 结果表明,试验条件下,随着热输入的增大,熔深和熔宽均增大,深色腐蚀区(HAZ2,heat affected zone 2)逐渐变宽并远离焊缝中心,上窄下宽的差异也将随之增大,760 ℃等温线距热源中心的距离基本符合r=0.465E+0.987 (mm)关系式;胞晶尺寸随着热输入的增大而增大,基本符合λ₂=3.324×E^2/3 (μm)关系式,小热输入情况下适用性高. 最佳热输入不仅可以得到成形良好的焊缝,而且计算值与实测值吻合程度较高.
- 马氏体时效钢 /
- 铁路辙叉 /
- 热输入 /
- 焊接温度场 /
- 胞晶
Abstract: In this paper, the influence of heat input on welding temperature field and microstructure of maraging steel C300 TIG (Tungsten Inter Gas Welding, TIG) welded joints were carried out preliminarily. The results indicate that, under these experimental conditions, as the heat input increased, the weld penetration and weld width both increased. The dark band zone (HAZ 2, Heat affected zone 2) widened and was further away from the weld center line, as well as that the difference between the top and bottom of dark band zones was also increased. The distance between 760 ℃ isotherm and the heat source basically satisfies the relationship of r=0.465E+0.987 (mm). The cellular grain size also increased with the increase of the heat input and basically satisfies the relationship λ₂=3.324×E^2/3 (μm), and with high applicability in the case of small heat input. Under best welding heat input, not only a good weld shape can be obtained but also a higher degree of agreement between the calculated value and the measured one.
- maraging steel /
- railway crossing /
- heat input /
- welding temperature field /
- cellular

HTML全文

参考文献(13)

[1]	Hall A M, Slunder C J. The metalllurgy, behavior, and application of the 18% Ni maraging steels[M]. SP-5051, NASA, Washington, DC, 1968.
[2]	Lang F H, Kenyon N. Welding of Maraging Steel[R]. WRC Bulletin, 159, 1971.
[3]	Tariq F, Baloch. R A, Ahmed B, et al. Investigation into microstructures of maraging steel 250 weldments and effect of post-weld heat treatments[J]. Journal of Materials Engineering and Performance, 2010, 19(2): 264-273.
[4]	尹钟大, 徐再成, 陈世忠. 13Ni马氏体时效钢显电子束焊接性能[J]. 焊接学报, 1990, 11(2): 65-72. Yin Zhongda, Xu Zaicheng, Chen Shizhong. Electron beam welding properties of 13Ni maraging steel[J]. Transactions of the China Welding Institution, 1990, 11(2): 65-72.
[5]	张福成. 辙叉钢及其热加工工艺[M]. 北京: 机械工业出版社, 2011.
[6]	彭云, 许良红, 田志凌, 等. 焊接热输入对高强铝合金接头组织和性能的影响[J]. 焊接学报, 2008, 29(2): 17-21. Peng Yun, Xu Lianghong, Tian Zhiling, et al. Effect of heat input on microstructure and mechanical properties of the high strength aluminum alloy welds[J]. Transactions of the China Welding Institution, 2008, 29(2): 17-21.
[7]	孟根巴根, 马成勇, 彭云, 等. 热输入对9Ni钢焊接接头组织及低温冲击性的影响[J]. 焊接学报, 2010, 31(6): 69-72. Menggenbagen, Ma Chengyong, Peng Yun, et al. Effect of heat input on microstructure and low temperature impact resistance of welded joint of 9Ni steel[J]. Transactions of the China Welding Institution, 2010, 31(6): 69-72.
[8]	杨帅, 彭云, 张晓牧, 等. C300马氏体时效钢等离子弧焊接接头的组织与硬度[J]. 机械工程材料, 2014, 38(10): 1-5. Yang Shuai, Peng Yun, Zhang Xiaomu, et al. Microstructure and hardness of plasma arc welded joint of C300 maraging steel[J]. Materials for Mechanical Engineering, 2014, 38(10): 1-5.
[9]	Blauel J G, Smith H R, Schulze G. Fracture toughness study of a grade 300 maraging steel weld joint[J]. Welding research supplement, 1974, 211s-218s.
[10]	穆波. 微量元素对18Ni系马氏体时效钢的力学性能和微观组织的影响[D]. 江苏: 江苏科技大学, 2011.
[11]	张文钺. 焊接传热学[M]. 北京: 机械工业出版社, 1989.
[12]	张文钺. 焊接冶金学[M]. 北京: 机械工业出版社, 1999.
[13]	余永宁. 金属学原理[M]. 北京: 冶金工业出版社, 2007.
