硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物 层演变及剪切行为的影响

邱希亮, 王倩, 林铁松, 何鹏, 陆凤娇

邱希亮, 王倩, 林铁松, 何鹏, 陆凤娇. 硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物 层演变及剪切行为的影响[J]. 焊接学报, 2015, 36(8): 35-38.
引用本文: 邱希亮, 王倩, 林铁松, 何鹏, 陆凤娇. 硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物 层演变及剪切行为的影响[J]. 焊接学报, 2015, 36(8): 35-38.
shu
QIU Xiliang, WANG Qian, LIN Tiesong, HE Peng, LU Fengjiao. Effect of Al18B4O33 whiskers on microstructure evolution of intermetallic compound layer and shear behavior of soldered joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(8): 35-38.
Citation: QIU Xiliang, WANG Qian, LIN Tiesong, HE Peng, LU Fengjiao. Effect of Al18B4O33 whiskers on microstructure evolution of intermetallic compound layer and shear behavior of soldered joint[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(8): 35-38.
shu

硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物 层演变及剪切行为的影响

  • 1.

    哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001

  • 2.

    江苏双良新能源装备有限公司, 江阴 214444

基金项目: 国家自然科学基金资助项目(51275135,51474081)

Effect of Al18B4O33 whiskers on microstructure evolution of intermetallic compound layer and shear behavior of soldered joint

  • 1.

    State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

  • 2.

    Jiangsu Shuangliang New Energy Equipment[HJ1. 25mm]Corporation Limited, Jiangyin 214444, China

摘要

    摘要
  • 摘要: 研究了硼酸铝晶须对Sn-58Bi/Cu界面金属间化合物(IMC)层组织演变的影响.结合钎焊接头显微组织、剪切性能以及断口形貌,分析了Sn-58Bi-1.2%Al18B4O33钎焊接头的断裂机理.结果表明,硼酸铝晶须的加入可以细化钎料组织,抑制大块富铋相的出现;钎料/基板界面IMC层厚度和晶粒粒径均随着重熔次数的增加而增大,但硼酸铝晶须的加入能够阻碍界面IMC层的增厚和晶粒粗化,提高钎焊接头的性能;不同重熔次数下Sn-58Bi-1.2% Al18B4O33/Cu钎焊焊点比Sn-58Bi/Cu钎料焊点能承受更高的剪切载荷,且经过多次重熔后接头强度保持稳定.
    Abstract: The effect of Al18B4O33 whiskers on the microstructure evolution of the intermetallic compound(IMC) layer on the Sn-58Bi/Cu interface was investigated, and the fracture mechanism of the Sn-58Bi-1.2% Al18B4O33 soldered joint was analyzed. The results show that, the addition of Al18B4O33 whiskers to the solder refines the solder microstructure, inhibits the formation of large pieces of Bi-rich phase. The thickness and grain size of the interfacial IMC layer are increased with the increase of the remelting cycles, but the addition of Al18B4O33 whiskers to the solder hinders the interfacial IMC layer thickening and grain coarsening, which improves the mechanical property of the brazing joint. The Sn-58Bi-1.2% A118B4O33/Cu soldered joint can bear higher shear stress than the Sn-58Bi/Cu soldered joint after multi-remelting, and its strength remains stable after multi-remelting.
    • HTML全文
    • 参考文献(10)
  • [1] 刘平,龙郑易,顾小龙,等.低温无铅焊料[J].电子工艺技术, 2014, 35(4):198-200. Liu Ping, Long Zhengyi, Gu Xiaolong, et al. Low temperature lead-free solders[J]. Electronics Process Technology, 2014, 35(4):198-200.
    [2] Miao H W, Duh J G. Microstructure evolution in Sn-Bi and Sn-Bi-Cu solder joints under thermal aging[J]. Materials Chemistry and Physics, 2001, 71(3):255-271.
    [3] 何洪文,徐广臣,郭福.电迁移促进Cu/Sn-58Bi/Cu焊点阳极界面Bi层形成的机理分析[J].焊接学报, 2010, 31(10):35-38. He Hongwen, Xu Guangchen, Guo Fu. Mechanism investigation of Bi layer formation at anode interface in Cu/Sn-58Bi/Cu solder joint induced by electromigration[J]. Transactions of the China Welding Institution, 2010, 31(10):35-38.
    [4] 何鹏,安晶,马鑫,等.含碳纳米管的Sn-58Bi钎料的制备及其钎焊性[J].焊接学报, 2011, 32(9):9-12. He Peng, An Jing, Ma Xin, et al. Investigation preparation method and soldering behaviors of Sn-58Bi lead-free solder with carbon nanotubes[J]. Transactions of the China Welding Institution, 2011, 32(9):9-12.
    [5] Ning N Y, Luo F, Wang K, et al. Interfacial enhancement by shish-calabash crystal structure in polypropylene/inorganic whisker composites[J]. Polymer, 2009, 50(15):3851-3856.
    [6] 吕世雄,于治水,许志武,等. SiCw/6061Al复合材料无钎剂加压钎焊[J].焊接学报, 2001, 22(4):73-76. Lü Shixiong, Yu Zhishui, Xu Zhiwu, et al. Fluxless pressure soldering for SiCw/6061Al composites[J]. Transactions of the China Welding Institution, 2001, 22(4):73-76.
    [7] Sudheer M, Prabhu R, Raju K, et al. Optimization of dry sliding wear performance of ceramic whisker filled epoxy composites using taguchi approach[J]. Advances in Tribology, 2012(8):1-9.
    [8] 孙新华.硼酸铝晶须的应用与制备[J].化工新型材料, 1998, 26(4):33-35. Sun Xinhua. Application and preparation of Al18B4O33 whisker[J]. New Chemical Materials, 1998, 26(4):33-35.
    [9] Nai S M L, Wei J, Gupta M. Influence of ceramic reinforcements on the wettability and mechanical properties of novel lead-free solder composites[J]. Thin Solid Films, 2006, 504(1):401-404.
    [10] 金培鹏,周文胜,丁雨田,等.晶须在复合材料中的应用及其作用机理[J].盐湖研究, 2005, 13(2):1-6. Jin Peipeng, Zhou Wensheng, Ding Yutian, et al. Application of whiskers in composites and their reinforcement mechanism[J]. Journal of Salt Lake Research, 2005, 13(2):1-6.
