夹杂物对Ag-Cu-Zn钎料凝固组织和性能的影响

樊江磊, 龙伟民, 王星星, 郭艳红, 张冠星

樊江磊, 龙伟民, 王星星, 郭艳红, 张冠星. 夹杂物对Ag-Cu-Zn钎料凝固组织和性能的影响[J]. 焊接学报, 2015, 36(5): 1-4.
引用本文: 樊江磊, 龙伟民, 王星星, 郭艳红, 张冠星. 夹杂物对Ag-Cu-Zn钎料凝固组织和性能的影响[J]. 焊接学报, 2015, 36(5): 1-4.
shu
FAN Jianglei, LONG Weimin, WANG Xingxing, GUO Yanhong, ZHANG Guangxing. Effect of inclusions on microstructure and mechanical properties of Ag-Cu-Zn filler metal[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(5): 1-4.
Citation: FAN Jianglei, LONG Weimin, WANG Xingxing, GUO Yanhong, ZHANG Guangxing. Effect of inclusions on microstructure and mechanical properties of Ag-Cu-Zn filler metal[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(5): 1-4.
shu

夹杂物对Ag-Cu-Zn钎料凝固组织和性能的影响

  • 1.

    郑州轻工业学院 机电工程学院, 郑州 450002

  • 2.

    郑州机械研究所 新型钎焊材料与技术国家重点实验室, 郑州 450001

基金项目: 国家高技术研究发展计划项目(863计划,2012AA40208)

Effect of inclusions on microstructure and mechanical properties of Ag-Cu-Zn filler metal

  • 1.

    Mechanical and Electrical Engineering Institute, Zhengzhou University of Light Industry, Zhengzhou 450002, China

  • 2.

    State Key Laboratory of Advanced Brazing Filler Metals and Technology, Zhengzhou Research Institute of Mechanical Engineering, Zhengzhou 450001, China

摘要

    摘要
  • 摘要: 分析了夹杂物对Ag-Cu-Zn基钎料BAg40CuZn(Mn,Ni,Co)组织与性能的影响. 在大气条件下熔炼,BAg40CuZn钎料中的Mn,Co元素易形成Mn2O3,Co3O4,MnN等夹杂物. 由于氧化物和氮化物的硬度高于BAg40CuZn钎料基体的硬度,且自身的变形能力差,降低了钎料的塑性变形能力. 在塑性加工前期,拉拔力较大,变形过程中产生的挤压力使夹杂物发生碎裂,并沿拉伸变形方向分布. 在塑性加工后期,拉拔力变小,在变形过程中产生的挤压力不足以使夹杂物发生碎裂,造成局部应力增大,当其超过钎料基体的抗拉强度后,在夹杂物周围形成裂纹源并扩展,导致钎料在变形过程中发生断裂.
    Abstract: The influence of the inclusion formed in solidification process on the microstructure and mechanical properties of BAg40CuZn(Mn, Ni, Co) Ag-based filler metal was investigated. When the filler metal was melted under air condition, some inclusions (Mn2O3, Co3O4, MnN) were formed owing to the reaction between element Mn and Co with oxygen and nitrogen in air. The plastic deformation ability of the BAg40CuZn filler metal was decreased because of the higher hardness and lower deformability of inclusions. At the earlier stage of the deformation, the extrusion force is sufficient to break the inclusion in matrix. The broken inclusions distributed along the direction of extruding. At the later stage of deformation, the extrusion force was decreased that is not sufficient to break the small inclusions. These inclusions decreased the stress bearing area of the filler metal, resulting in stress concentration nearby. When the stress is greater than the yield limit of the matrix, crack would initiate around the inclusion. With the increase of stress, the crack propagates that causes the damage of filler metal finally.
    • HTML全文
    • 参考文献(11)
  • [1] 卢方焱, 薛松柏, 张 亮, 等. Ag-Cu-Zn系钎料的研究现状及发展趋势[J]. 焊接, 2008(10): 13-19. Lu Fangyan, Xue Songbai, Zhang Liang, et al. Research status and prospect of Ag-Cu-Zn series brazing filler metals[J]. Welding & Joining, 2008(10): 13-19.
    [2] 杨 静, 李长香, 朱金霞, 等. Ag95CuNiLi钎料钎焊钛合金与不锈钢异种金属的性能分析Ⅰ.钎料腐蚀性能[J]. 焊接学报, 2003, 24(6): 60-62. Yang Jing, Li Changxiang, Zhu Jinxia, et al. Properties of Ag95CuNi filler metal brazing titanium alloy and stainless steel I: Corrosion of filler metal[J]. Transactions of the China Welding Institution, 2003, 24(6): 60-62.
    [3] 杨 静, 王 飞, 朱金霞, 等. Ag95CuNiLi钎料钎焊钛合金与不锈钢异种金属的性能分析Ⅱ.钎焊性分析[J]. 焊接学报, 2004(1): 48-51. Yang Jing, Wang Fei, Zhu Jinxia, et al. Properties of Ag95CuNi filler metal brazing titanium alloy and stainless steel II: Analysis of brazing properties[J]. Transactions of the China Welding Institution, 2004(1): 48-51.
    [4] 何 鹏, 曹 健, 徐富家, 等. Ag-28Cu钎焊TA2/BT20接头组织分析[J]. 焊接学报, 2009, 30(12): 9-12. He Peng, Cao Jian, Xu Jiafu, et al. Structure of brazed joints of TA2/BT20 with Ag-28Cu filler metal[J]. Transactions of the China Welding Institution, 2009, 30(12): 9-12.
    [5] 雷 敏, 张丽霞, 李宏伟, 等. Zn元素含量对AgCuZn钎料在TiC金属陶瓷表面润湿性的影响[J]. 焊接学报, 2012, 33(7): 41-44. Lei Min, Zhang Lixia, Li Hongwei, et al. Influence of Zn content on wettability of TiC cermet by AgVuZn alloy[J]. Transactions of the China Welding Institution, 2012, 33(7): 41-44.
    [6] 李卓然, 矫 宁, 冯吉才, 等. 合金元素对AgCuZn系钎料合金组织与性能的影响[J]. 焊接学报, 2008, 29(3): 65-68. Li Zhuoran, Jiao Ni, Feng Jicai, et al. Effect of alloying elements on microstructure and property of AgCuZnSn brazing alloy[J]. Transactions of the China Welding Institution, 2008, 29(3): 65-68.
    [7] 韩宪鹏, 薛松柏, 顾立勇, 等. 镓对Ag-Cu-Zn钎料组织和力学性能的影响[J]. 焊接学报, 2008, 29(2): 45-48. Han Xianpeng, Xue Songbai, Gu Liyong, et al. Effect of gallium on microstructure and mechanical properties of Ag-Cu-Zn filler metals[J]. Transactions of the China Welding Institution. 2008, 29(2): 45-48.
    [8] 赖忠民, 王俭辛, 卢方焱. 稀土铈对Ag30CuZnSn-3Ga-2In钎料显微组织的影响[J]. 焊接学报, 2011, 32(1): 9-12. Lai Zhongmin, Wang Jianxin, Lu Fangyan. Effect of rare earth Ce on microstructure of Ag30CuZnZn-3Ga-2In[J]. Transactions of the China Welding Institution. 2011, 32(1): 9-12.
    [9] 李卓然, 刘 彬, 冯吉才. 镍对Ag20CuZnSnP钎料铺展润湿性和接头抗剪强度的影响[J]. 焊接学报, 2008, 29(9): 19-22. Li Zhuoran, Liu Bin, Feng Jicai. Effect of Ni on wettability and shear strength of joints of Ag20CuZnP filler metal[J]. Transactions of the China Welding Institution, 2008, 29(9): 19-22.
    [10] 龙伟民. 国内硬钎焊材料的发展与技术展望[C]// 第十九届全国钎焊及特种连接技术交流会. 长沙, 2012: 8-13.
    [11] 那顺桑, 李 杰, 艾立群. 金属材料力学性能[M]. 北京: 冶金工业出版社, 2011.
