厚板双TIG打底焊缝根部熔合的数值模拟

杨东青; 李大用; 张广军

厚板双TIG打底焊缝根部熔合的数值模拟

哈尔滨工业大学先进焊接与连接国家重点实验室, 哈尔滨 150001

基金项目: 国家自然科学基金资助项目(51175119)

计量
- 文章访问数: 263
- HTML全文浏览量: 10
- PDF下载量: 95
出版历程
- 收稿日期: 2013-09-10

Numeral simulation of root fusion in double-sided TIG backing welding of thick plate

State Key Laboratory of Advanced Welding and Joining, Harbin Institute of Technology, Harbin 150001, China

摘要

摘要: 建立了厚板双面双TIG打底焊有限元模型,并通过焊接试验验证该模型的合理性及准确性.在此基础上分别对不同错边及钝边的坡口形式下厚板打底焊温度场进行了模拟.结果表明,随着预留间隙的增大,双弧打底焊可熔化的钝边量增大,可允许的错边范围先增大后减小;在厚板打底焊时,当钝边及错边之和不超过4 mm时预留2~4 mm的间隙能够得到根部熔合良好的焊缝;存在的错边及钝边量之和超过6 mm将产生未焊透缺陷;当钝边及错边之和在4~6 mm之间时打底焊缝根部熔合情况随着间隙改变而变化.
- 双面双TIG打底焊 /
- 根部熔合 /
- 温度场数值模拟
Abstract: A finite element model for double-sided TIG backing welding of thick plate was established, and the reasonableness and accuracy of the model were verified by welding experiments. Then, the temperature fields in backing welding thick plate were simulated for different groove designs with different sizes of misalignment and root face, respectively. The results show that, with the increase of the reserved groove gap, the allowable range of root face increased using double-sided TIG backing welding, and the allowable range of misalignment increased first and then decreased. In backing welding of thick plate, when the sum of root face and misalignment was less than 4 mm, the weld with good root fusion could be obtained with reserved 2-4 mm groove gap. When the sum of root face and misalignment was more than 6 mm, incomplete penetration occurred. When the sum was between 4 mm and 6 mm, the root fusion changed with the reserved groove gap.
- double-sided TIG backing welding /
- root fusion /
- numerical simulation of temperature field

HTML全文

参考文献(7)

[1]	Pocock G. High strength use in australia, japan and the US[J]. Journal of The Structural Engineer, 2006, 84(21):27-30.
[2]	邹增大,李亚江,尹士科.低合金调质高强钢焊接及工程应用[M].北京:化学工业出版社, 2004.
[3]	张华军,张广军,王俊恒,等.低合金高强钢双面双弧焊热循环对组织性能的影响[J].焊接学报, 2007, 28(10):81-84. Zhang Huajun, Zhang Guangjun, Wang Junheng, et al. Effect of thermal cycles of DSAW on microstructure in low alloy high strength steel[J]. Transactions of the China Welding Institution, 2007, 28(10):81-84.
[4]	刘殿宝,李福泉,谭财旺,等. EH36钢厚板双面双弧打底焊焊缝组织及性能[J].焊接学报, 2011, 32(1):81-84. Liu Dianbao, Li Fuquan, Tan Caiwang, et al. Microstructure and performance of backing weld joint of EH36 steel thick plate bu double-side arc welding[J]. Transactions of the China Welding Institution, 2011, 32(1):81-84.
[5]	刘殿宝,张广军,吴林.大厚板双面双TIG打底焊熔池成形特性[J].焊接学报, 2012, 32(3):37-40. Liu Dianbao, Zhang Guangjun, Wu Lin. Characteristics of pool formation in backing weld for large and thick plates using double-sided double TIG arc welding[J]. Transactions of the China Welding Institution, 2012, 32(3):37-40.
[6]	Chin H L, Kyong H C. Finite element simulation of the residual stresses in high strength carbon steel butt weld incorporating solid-state phase transformation[J]. Computational Materials Science, 2009, 46:1014-1022.
[7]	武传松.焊接热过程与熔池形态[M].北京:机械工业出版社, 2007.
