金属互连结构的电迁移仿真分析

邓登, 崔海坡

邓登, 崔海坡. 金属互连结构的电迁移仿真分析[J]. 焊接学报, 2015, 36(1): 75-78.
引用本文: 邓登, 崔海坡. 金属互连结构的电迁移仿真分析[J]. 焊接学报, 2015, 36(1): 75-78.
DENG Deng, CUI Haipo. Electromigration simulation analysis of metal interconnects[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(1): 75-78.
Citation: DENG Deng, CUI Haipo. Electromigration simulation analysis of metal interconnects[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2015, 36(1): 75-78.

金属互连结构的电迁移仿真分析

基金项目: 国家自然科学基金资助项目(51305268);航空科学基金资助项目(20110247001)

Electromigration simulation analysis of metal interconnects

  • 摘要: 针对集成电路中金属互连线的电迁移现象,应用有限元分析软件ABAQUS,对铝硅合金互连线的电迁移过程进行了电热耦合研究,分析了不同电流密度与电势梯度、热通量、互连线内部总能量之间的相互关系,比较了不同结构尺寸对铝互连线电迁移失效的影响规律.结果表明,在互连线的狭窄部位,电势梯度和热通量达到最大值并具有集中性;电势梯度和热通量与通电时间及电流密度均成正比例关系;随着通电时间的延长,互连线内部总能量的变化趋势为先急剧下降再上升并达到某一平衡值;随着铝互连线宽度的增加,互连线内部的热通量逐渐减小.对于文中分析的结构模型,当互连线宽度低于2μm后,互连线失效的概率将大幅度增加.
    Abstract: In accordance with the electromigration of alloy interconnect in integrated circuits, the electric-thermal coupling analysis was performed for the electromigration process of Al-Si alloy interconnect with finite element analysis software ABAQUS. The relationship of the current density with the potential gradient, heat flux, and the total energy of interconnect was analyzed. The influence rule of the different dimensions on the electromigration failure of Al-Si interconnect was researched. The results indicated that both the maximums of potential gradient and heat flux concentrate on the narrow position of the interconnect. With the increasing current density and testing time, the potential gradient and heat flux increases. The changing trend of the total energy of interconnect sharp by drops firstly, and then rises to an equilibrium value with the time increases. The heat flux decreases with the width of interconnect increasing. If the width of interconnect is lower than 2μm, the failure possibility will increase dramatically for the SWEAT model in this paper.
  • [1] Chawla N. Thermal fatigue behavior of Sn-rich (Pb-free) solders[J]. Metallurgical and Materials Transactions A, 2008, 39A:799-810.
    [2] JEDEC Solid State Technology Association.JESD61 JEDEC standard:standard method for calculating electro migration model parameters for current density and temperature[S].USA:JEDEC Solid State Technology Association, 2007.
    [3] Hiroyuki A, Mikio M, Kazuhiko S, et al. A comparison of electromigration failure of metal lines with fracture mechanics[J]. Acta Mechanica Sinica, 2012, 28(3):774-781.
    [4] 王家兵,孙凤莲,刘洋.微量元素对无铅焊点电迁移性能的改善[J].焊接学报, 2012, 33(2):29-32. Wang Jiabing, Sun Fenglian, Liu Yang. Improvement electromigration resistance of Pb-free solder joints with element addition[J]. Transactions of the China Welding Institution, 2012, 33(2):29-32.
    [5] Zhang J S, Xi J, Wu Y P, et al. Thermomechanical stress and strain in solder joints during electromigration[J]. Journal of Electronic Materials, 2009, 38(5):678-684.
    [6] Fu C M, Tan C M, Wu S H, et al. Width dependence of the effectiveness of reservoir length in improving electromigration for Cu/low-k interconnects[J]. Microelectronics Reliability, 2010, 50:1332-1335.
    [7] 梁利华,张元祥,刘勇,等.金属互连结构的电迁移失效分析新算法[J].固体力学学报,2010, 31(2):164-172. Liang Lihua, Zhang Yuanxiang, Liu Yong, et al. A new Al gorithm for electromigration failure analysis of metal interconnects[J]. Chinese Journall of Solid Mechanics, 2010, 31(2):164-172.
    [8] Dalleau D. 3D time-depending simulation of void formation in metallization structures[D]. Hannover:Hannover University, 2003.
    [9] Ogawa E T, Lee K D, Blaschke V A, et al. Electromigration reliability issues in dual-damascene Cu interconnections[J]. IEEE Transactions on Reliability, 2002, 51(4):403-419.
    [10] He H W, Cao L Q, Hao H, et al. Thermoelectric coupling effect on the interfacial IMC growth in lead-free solder joint[J]. IEEE International Symposium on Advanced Packaging Materials, 2013, 2:223-229.
    [11] Jeon I, Park Y B. Analysis of the reservoir effect on electromigration reliability[J]. Microelectronics Reliability, 2004, 44(6):917-928.
    [12] Singh N, Bower A F, Shankar S. A three-dimensional model of electromigration and stress induced void nucleation in interconnect structures[J]. Modelling and Simulation in Materals Science and Engineering, 2010, 18:1-20.
    [13] Dandu P, Fan X J, Liu Y, et al. Finite element modeling on electromigration of solder joints in wafer level packages[J]. Microelectronics Reliability, 2010, 50:547-555.
