磁场作用下镁合金焊接接头力学性能的变化

Forming characteristics,microstructure and properties of magnesium alloy during TIG welding under magnetic field

  • 摘要: 采用钨极氩弧焊(GTAW)方法焊接AZ31镁合金,并在焊接过程引入纵向交流磁场.焊后,检测不同参数下焊接接头的成形系数、拉伸性能和硬度,并对显微组织进行分析,研究磁场参数对焊接接头成形特点及组织性能的作用规律.结果表明,外加纵向交流磁场通过改变电弧和熔池的运动状态,使熔池的散热及结晶条件得到改变,使焊缝的成形系数变大,焊缝的显微组织得到细化,力学性能得到提高.当磁场电流为2.0A,磁场频率为20 Hz时,焊接接头的力学性能达到最佳值,其中抗拉强度为231 MPa,断后伸长率为11.5%,断面收缩率为14.8%,硬度(HV)为14.40 MPa,焊缝成形系数为4.06,强硬比为16.04.



    Abstract: Tungsten inert gas (TIG) welding of AZ31 magnesium alloy sheets under AC longitudinal magnetic field was conducted.After welding,the forming factor,tensile strength and hardness of the resultant joints under different welding parameters were tested,and the microstructure was examined,to investigate the effects of magnetic field on the forming characteristics, microstructure and mechanical properties of the joints.The results show that the AC longitudinal magnetic field changed the moving form of the welding arc and welding pool to control the heat dissipation and crystallization in the welding pool,increase the forming factor of the weld,refine the weld grains and improve the mechanical properties of the joint.When magnetic field current Im was 2 A,magnetic field frequency f was 20 Hz, the mechanical properties of the welded joint were optimized with tensile strength σb equal to 231 MPa,elongation percentage δ 11.5%,ratio of shrinkage φ 14.8%,hardness 76.2 HV and forming factor 4.06.



/
