氩氮混合等离子焊接电弧的数值分析

雷玉成, 王健, 朱彬

雷玉成, 王健, 朱彬. 氩氮混合等离子焊接电弧的数值分析[J]. 焊接学报, 2008, (8): 17-20.
引用本文: 雷玉成, 王健, 朱彬. 氩氮混合等离子焊接电弧的数值分析[J]. 焊接学报, 2008, (8): 17-20.
LEI Yucheng, WANG Jian, ZHU Bin. Numerical analysis on N2-Ar plasma welding arc[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2008, (8): 17-20.
Citation: LEI Yucheng, WANG Jian, ZHU Bin. Numerical analysis on N2-Ar plasma welding arc[J]. TRANSACTIONS OF THE CHINA WELDING INSTITUTION, 2008, (8): 17-20.

氩氮混合等离子焊接电弧的数值分析

基金项目: 国家自然基金资助项目(50475126)

Numerical analysis on N2-Ar plasma welding arc

  • 摘要: 以直流正极性氩氮混合工作气体等离子焊接电弧为研究对象,依据磁流体动力学理论构建电弧的数学模型,运用有限元分析软件ANSYS建立了三维稳态下轴对称的、氩氮混合工作气体的1/2等离子焊接电弧的数学模型,得到了焊接电弧的温度场、电场、电磁场、速度场的形态分布特征。分析了氩氮混合工作气体等离子弧的特性,并与纯氩气时的等离子弧的温度场及阳极热流密度分布进行了对比。结果表明,采用混合离子气时,等离子电弧的弧心最高温度相对于纯氩气时有所提高,另外弧柱区的高温区向阳极偏移,阳极的热流密度相对增加。
    Abstract: Aimed at Ar-N2 plasma welding arc, a mathematic model was established according to the theory of magnetic fluid dynamics. PA welding arc was numerically analyzed by the 3D, static and axisymmetric model with ANSYS software.The temperature, electromagnetic force and velocity profiles of the Ar-N2 protecting arc have been simulated.The characteristic of the Ar-N2 protecting plasma welding arc was analyzed and compared with the Ar protecting plasma arc.The results show that with the mixed plasma gas the maximum temperature of the arc is higher than that of the Ar plasma arc.And the maximum temperature area leans to the anode.
  • 期刊类型引用(7)

    1. 崔莹,戴丽萍. 基于声发射信号特征的粮食库房钢结构建筑焊接裂纹识别研究. 粮食与饲料工业. 2025(02): 44-47 . 百度学术
    2. 张诚,袁慧铮,应之歌. 应用多传感器激光视觉的焊接机器人变质心补偿控制. 激光杂志. 2024(01): 236-241 . 百度学术
    3. 刘明宝,林庆伟. 基于超声波检测的钢板焊缝内部缺陷识别方法. 焊接技术. 2024(03): 128-132 . 百度学术
    4. 刘婷玉,李哲阳. 基于激光扫描成像的机械零件加工缺陷识别方法. 激光杂志. 2024(04): 259-264 . 百度学术
    5. 杨舒婷,杨青慧,张鼎,张元婧,俞靖彦,李涵,王峰,张怀武. 磁光成像技术及石榴石薄膜在无损检测中的应用. 磁性材料及器件. 2024(03): 90-101 . 百度学术
    6. 杨怀栋,张昕,李勋,邓华森,周丰. 电动汽车充电站钢结构停车棚焊接节点裂纹识别. 焊接技术. 2023(10): 136-140 . 百度学术
    7. 刘倩雯,张南峰,阮洁珊,叶广文,张艳喜,高向东. 电阻点焊质量检测技术研究现状. 精密成形工程. 2022(05): 83-93 . 百度学术

    其他类型引用(4)

计量
  • 文章访问数:  176
  • HTML全文浏览量:  2
  • PDF下载量:  136
  • 被引次数: 11
出版历程
  • 收稿日期:  2007-10-23
