Strengthing and toughening mechanism of weld metal of 690 MPa grade high strength steel
-
摘要:
制备了两个不同类型屈服强度为690 MPa级焊缝金属，开展了微观组织分析和力学性能测试，研究了焊缝金属的强韧化机理. 结果表明，传统690MPa级焊缝金属镍当量(Nieq)较小，枝晶间区域合金元素偏析不明显，焊缝金属形成以粗大的粒状贝氏体(grain bainite, GB)为主的相对均一组织，由于粗大的GB对裂纹扩展的阻力较小，其低温韧性较差. 通过提高Nieq的方法制备了新型690 MPa级焊缝金属，其Nieq较大，Mn，Ni在枝晶间区域显著偏析导致枝晶间过冷奥氏体的稳定性大于枝晶干，形成了枝晶干为针状铁素体(acicular ferrite, AF)，枝晶间为板条马氏体(lath martensite，LM)的复相组织. 在复相组织中AF为主要的韧化相，LM为主要的强化相，焊缝金属的屈服强度为738 MPa，−50 ℃冲击吸收能量为122 J，实现了良好的强韧性匹配.
-
关键词:
- 690 MPa级高强钢 /
- 焊缝金属 /
- 复相组织 /
- 合金偏析 /
- 强韧化机理
Abstract:Two different types of weld metals with yield strength of 690 MPa were prepared. The microstructure analysis and mechanical properties test were carried out and the mechanism of strengthen-tougheness was revealed. The results showed that the nickel equivalent ( Nieq ) of the traditional 690 MPa grade weld metal was small, and the segregation of alloy elements in the interdendritic region could be negligible. he weld metal formed a relatively uniform structure dominated by coarse granular bainite (GB). Because the coarse GB had little resistance to crack propagation, its low temperature toughness was poor. A new type of 690MPa grade weld metal was prepared by increasing Nieq. Due to the significant segregation of Mn and Ni in the inter-dendritic region, the stability of undercooled austenite in the interdendritic region was greater than that in the dendrite region, therefore the weld metal formed a complex phase structure with acicular ferrite (AF) in the dendrite and lath martensite (LM) in the interdendritic region. In this composite structure, AF was the main toughening phase and LM was the main strengthening phase. The yield strength of the weld metal was 738 MPa, and the impact absorption energy at −50 ℃ was 122 J, which achieved a good matching of strength and toughness.
-
-
![]()
图 2 TEM下焊缝金属的微观组织
Figure 2. Microstructure of weld metals under TEM. (a) TM of HT-01; (b) bright field phase of interdendritic retained austenite of HT-02; (c) dark field phase of interdendritic retained austenite of HT-02
![]()
图 3 焊缝金属−50 ℃夏比冲击断口形貌
Figure 3. Charpy impact fracture morphology of weld metals at −50 ℃. (a) HT-01; (b)fiber zone of HT-01; (c)radiation zone of HT-01; (d) HT-02; (e) fiber zone of HT-02; (f) Cleavage fracture plane of HT-02
![]()
图 4 焊缝金属−50 ℃夏比冲击断口一次裂纹
Figure 4. Charpy impact main crack of weld metals at −50 ℃. (a) HT-01; (b)Local amplification of Fig. 4(a); (c) HT-02; (d)Local amplification of Fig. 4(c)
![]()
图 5 焊缝金属彩色金相组织
Figure 5. Color Metallographic structure of weld metals. (a) HT-01; (b) HT-02
![]()
图 6 焊缝金属的强韧化机制
Figure 6. Strengthening and toughening mechanism of weld metals. (a) traditional weld metal; (b) new weld metal
表 1 焊缝金属化学成分(质量分数，%)
Table 1 Chemical composition of weld metals
焊条编号 C Si Cr + Mo Mn Ni Nieq HT-01 0.043 0.327 0.885 1.60 2.42 4.51 HT-02 0.037 0.302 0.312 0.88 4.88 6.43
下载: 导出CSV
表 2 焊缝金属力学性能
Table 2 Mechanical properties of weld metals
焊条编号 屈服强度ReL/MPa 抗拉强度Rm/MPa 断后伸长率A(%) 断面收缩率Z(%) −50 ℃冲击吸收能量AkV/J HT-01 736 797 20.0 66 59 HT-02 738 805 20.5 68 122
下载: 导出CSV
-
